90° MULTI BENDER KIT
USER MANUAL
We continue to be committed to provide you tools with competitive price. "Save Half", "Half
Price" or any other similar expressions used by us only represents an estimate of savings
you might benefit from buying certain tools with us compared to the major top brands and
doses not necessarily mean to cover all categories of tools offered by us. You are kindly
reminded to verify carefully when you are placing an order with us if you are actually saving
half in comparison with the top major brands.
Advertisement
Table of Contents
Related Manuals for VEVOR CT-999RF
Summary of Contents for VEVOR CT-999RF
- Page 1 90° MULTI BENDER KIT USER MANUAL We continue to be committed to provide you tools with competitive price. "Save Half", "Half Price" or any other similar expressions used by us only represents an estimate of savings you might benefit from buying certain tools with us compared to the major top brands and doses not necessarily mean to cover all categories of tools offered by us.
- Page 2 CustomerService@vevor.com This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won't inform you again if...
-
Page 3: Product Overview
Product Overview The VEVOR 90° TUBE BENDER is used to Bend 1/4", 5/16", 3/8", 1/2", 5/8", 3/4" and 7/8" tubing. For bending soft copper,aluminum, brass, thin wall steel, thin wall stainless steel and other tubing. Makes smooth, tight-radius 90° bends. -
Page 4: Personal Safety
and free of distractions. 2. Keep anyone not wearing the appropriate safety equipment away from the work area. 3. Store unused tools properly in a safe and dry location to prevent rust or damage. Lock tools away and keep out of the reach of children. PERSONAL SAFE TY WARNING! Always Wear personal protective equipment. - Page 5 function. Do not modify or alter this tool or use it for an unintended purpose. 2. Keep bender bearings and form handle grooves lubricated.Keep oil away from wheel grooves. Keep body parts away from pinch/bend areas while using. Ensure tubing is secure in tool before bending. 3.
- Page 6 (2) Prepare before bending-placing a tube Upright the bender housing and pull out the feed lever. former with dented rod will retract back under the effect of gravity,turn the sliding pieces with correct size slots and face them to the former slot. Then place the tube between former and sliding pieces.(figure) (3) Bending-push the feed lever repeatedly Push the feed lever repeatedly until the tube is bended to a certain angle...
- Page 7 (4) Bending finished-take the bended tube out Upright the bender and pull out the feed lever.former with dented rod with retract back under the effect of gravity.take the bended tube out, if the bended tube get stuck in the former slot, remove them from housing together.
- Page 8 Notice: don't strike the tube. CT-999F/ CT-999N / CT-999RF (1) Prepare before bending-fix former holder and Universal crossbar on Housing Insert universal crossbar in dented rod and tighten it by a wing screw,Fix former holder in housing slot and tighten it by a wing screw.(figure)
- Page 9 (2) Prepare before bending - universal crossbar and former install Insert correct size former in former holder, the place correct size universal crossbar on universal crossbar holder and tightened by a wing screw. Notice: there are 2 pairs of sliding pieces with sized slots on universal crossbar.
- Page 10 (4) Bending-push the feed lever repeatedly Push the feed lever repeatedly until the tube is bended to a certain angle you need. Notice: maximum angle is 90°. (5) Bending finished-take the bended tube out Upright the bender and pull out the feed lever. Universal crossbar holder with dented rod retract back will under the effect of gravity.
-
Page 11: Maintenance & Service
If you are unsure how to proceed, contact your local authority. Warranty Your VEVOR 180° TUBE BENDER is warranted against defects in materials and workmanship for a 12 month period from the date of purchase. Faulty goods will be repaired or replaced at Vevor’s discretion. - Page 12 EUREP UK LTD UNIT 2264, 100 OCK STREET, ABINGDON OXFORDSHIRE ENGLAND OX14 5DH EUREP GmbH Unterlettenweg 1a, 85051 Ingolstadt, Germany Importer: WAITCHX Address: 250 bis boulevard Saint-Germain 75007 Paris Importer: FREE MOOD LTD Address: 2 Holywell Lane, London, England, EC2A 3ET Manufacturer：Wujiang Dunnex Tools Co., Ltd Address：No.460 Yangang Road, Qiushe District,Tongli Town, Wujiang City, Suzhou, Jiangsu Province,China...
- Page 13 Technical Support and E-Warranty Certificate www.vevor.com/support...
