Vivotek IP7161 Technical Specifications

Technical Specifications
System
．CPU: Mozart 120 SoC
．Flash: 16MB
．RAM: 128MB + 128MB
．Embedded OS: Linux 2.6
Lens
．CS-mount, vari-focal, f = 4.5 ~ 10 mm, F1.6, auto-iris
．Removable IR-cut filter for day & night function
Angle of View
．37.1° ~ 77.6° (horizontal)
Shutter Time
．1/5 sec. to 1/40,000 sec.
Image Sensor
．1/3.2" CMOS sensor in 1600x1200 resolution
Minimum Illumination
．0.8 Lux / F1.6
Video
．Compression: MJPEG & MPEG-4
．Streaming:
Simultaneous multiple streams
MPEG-4 streaming over UDP, TCP, HTTP or HTTPS
MPEG-4 multicast streaming
MJPEG streaming over HTTP or HTTPS
．Supports activity adaptive streaming for dynamic frame rate control
．Supports video cropping for bandwidth saving
．Supports ePTZ for data efficiency
．Supports 3GPP mobile surveillance
．Frame rates:
MPEG-4:
Up to 20 fps at 1280x720Up to 10 fps at 1600x1200
MJPEG:
Up to 30 fps at 1280x720UP to 15 fps at 1600x1200
Image Settings
．Adjustable image size, quality, and bit rate
．Time stamp and text caption overlay
．Flip & mirror
．Configurable brightness, contrast, saturation, sharpness, white
balance and exposure
．AGC, AWB, AES
．Automatic, manual or scheduled day/night mode
．BLC (Backlight Compensation)
．Supports privacy masks
Audio
．Compression:
GSM-AMR speech encoding, bit rate: 4.75 kbps to 12.2 kbps
MPEG-4 AAC audio encoding, bit rate: 16 kbps to 128 kbps
．Interface:
Built-in microphone
External microphone input
Audio output
External/Internal microphone switch
．Supports two-way audio via SIP protocol
．Supports audio mute
Networking
．10/100 Mbps Ethernet, RJ-45
．Protocols: IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP,
RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS,
PPPoE, CoS, QoS, SNMP and 802.1X
All specifications are subject to change without notice. Copyright
VIVOTEK INC.
6F, No.192, Lien-Cheng Rd., Chung-Ho,Taipei County, Taiwan
|T: +886-2-82455282| F: +886-2-82455532| E: sales@vivotek.com
Alarm and Event Management
．Triple-window video motion detection
．Tamper detection
．One D/I and one D/O for external sensor and alarm
．Event notification using HTTP, SMTP or FTP
．Local recording of MP4 file
On-board Storage
．SD/SDHC card slot
．Stores snapshots and video clips
Security
．Multi-level user access with password protection
．IP address filtering
．HTTPS encrypted data transmission
．802.1X port-based authentication for network protection
Users
．Live viewing for up to 10 clients
Dimension
．154 mm (D) x 72 mm (W) x 62 mm (H)
Weight
．Net: 662 g
LED Indicator
．System power and status indicator
．System activity and network link indicator
Power
．12V DC
．24V AC
．Power consumption: Max. 8 W
．802.3af compliant Power-over-Ethernet
Approvals
．CE, LVD, FCC, VCCI, C-Tick
Operating Environments
．Temperature: 0 ~ 50 °C (32 ~ 122 °F )
．Humidity: 90% RH
Viewing System Requirements
．OS: Microsoft Windows 7/Vista/XP/2000
．Browser: Mozilla Firefox, Internet Explorer 6.x or above
．Cell phone: 3GPP player
．Real Player: 10.5 or above
．Quick Time: 6.5 or above
Installation, Management, and Maintenance
．RS-485 interface for scanners, pan/tilts
．Installation Wizard 2
．32-CH ST7501 recording software
．Supports firmware upgrade
Applications
．SDK available for application development and system integration
Warranty
．24 months
2009 VIVOTEK INC. All rights reserved.
VIVOTEK USA, INC.
470 Lakeside Drive Suite C, Sunnyvale, CA 94085 USA
|T: 408-773-8686| F: 408-773-8298| E: salesusa@vivotek.com
Fixed Network Camera
IP7161
2-megapixel Day & Night
•
VIVOTEK IP7161 is a high-end 2-megapixel network camera with true day and night functions ideally suited for wide, open spaces such
as building entrances and airports, or applications requiring accurate identification of individuals, objects, and vehicle license plates.
With high-definition 2-megapixel (1600 x 1200) resolution, the IP7161 can deliver extremely clear and detailed images and provide
coverage 6 times larger than a VGA camera. Its ePTZ function enables users to quickly move to a target area for close-up shots
without moving the camera physically. In addition, multiple video streams can be delivered simultaneously in different resolutions,
frame rates and image qualities for viewing on different platforms, so as to meet different needs or bandwidth constraints.
To consistently maintain superior image quality during 24-hour surveillance, the IP7161 comes with a built-in removable IR-cut filter
to accept IR illumination and an auto-iris lens to adapt to frequent light changes. For safe and secure monitoring, the IP7161 also
supports tamper detection so that security staff can be alerted immediately if the camera is blocked, redirected, defocused, or
spray-painted. The exceptional activity adaptive streaming can optimize bandwidth usage by allowing for a low frame rate in normal
monitoring and a high frame rate during event-triggered recording.
The IP7161 includes other advanced features such as a C/CS-mount adjustment ring, SD/SDHC card on-board storage, 802.3af
compliant PoE, two-way audio via SIP protocol, and HTTPS encrypted data transmission.
Ver 1.5
