  • Page 2 Contact your distributor when such cases happen. Contact your distributor when such cases happen. EN - 1...
  • Page 3 EN - 2...
  • Page 4 Lens Tilt screw Built-in MIC PIR sensor Indented reset button Image adjustment screw MIC in Pan screw White-light LEDs Status LED Power cord socket Ethernet 10/100 RJ45 socket 1 2 3 4 Audio Out Mic. In Ext. Int. Audio out Drill holes Dome cover EN - 3...

  • Page 5: Installation Tips

    First, use the supplied screwdriver to detach the dome cover from the camera base. Then, follow the steps below to install the camera; either to a ceiling or to a wall. Installation Tips Before installing the camera, look for a spot that best suits your needs. The built-in PIR sensor is designed to be triggered when a person enters its detection range.

  • Page 6: General Connection (Without Poe)

    General Connection (without PoE) 1. If you have external devices such as sensors and alarms, make connections from gen- eral I/O terminal block. 2. Connect the camera to a switch via a Ethernet cable. 3. Connect the supplied power cable from the camera to a power outlet. 1 2 3 4 Ethernet switch Audio Out Mic.

  • Page 7: Power Over Ethernet (Poe)

    Power over Ethernet (PoE) The camera is PoE-compliant, allowing transmission of power and data via single Ether- net cable. See the following illustration to connect the camera to a PoE-enabled switch via Ethernet cable. PoE switch Use a PoE power injector (optional) to connect between the camera and a non-PoE switch.
  • Page 8 "Next" button to continue the program. Installation Wizard 2 3. The program will search the VIVOTEK Video Receivers, Video Servers or Network Cam- eras on the same LAN. 4. After searching, the main installer window will pop up. Click on the MAC that matches the one labeled on the bottom of your device to connect the Internet Explorer to the Network Camera.
  • Page 9 1. Access to the Network Camera from the Internet. 2. Retrieve live video through web browsers or recording software. For further setup, please refer to user's manual on the software CD. EN - 8...

  • Page 10: To Adjust The Zoom Factor And Focus Range

    Based on the live image retrieved from the camera, adjust the camera lens by doing the following: To adjust the viewing angle 1. Loosen the pan screw and then turn the lens module left and right. Upon completion, tighten the pan screw. 2.
  • Page 11 Attach the dome cover to camera. Secure the two dome screws with a screwdriver. Finally, make sure all parts of the camera are securely installed. The supplied screwdriver is exclusively designed to match the dome screws. In case you will need to adjust the lens at a later time, do not discard the screwdriver.
