  • Page 2: Table Of Contents

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions Table of Contents Overview3 Read before use ��������������������������������������������������������������������������������������������������������������������������������������3 Package contents ������������������������������������������������������������������������������������������������������������������������������������3 Physical description ���������������������������������������������������������������������������������������������������������������������������������4 Installation 8 Hardware installation �������������������������������������������������������������������������������������������������������������������������������8 Network deployment ������������������������������������������������������������������������������������������������������������������������������10 Software installation ������������������������������������������������������������������������������������������������������������������������������13 Ready to use �����������������������������������������������������������������������������������������������������������������������������������������14 Adjusting the Lens ���������������������������������������������������������������������������������������������������������������������������������14 Completion �������������������������������������������������������������������������������������������������������������������������������������������15...

  • Page 3: Overview3

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions Overview VIVOTEK FD7141(V) is a professional vandal- and weather-proof fixed dome network camera, integrating all elements needed for outdoor security into a discreet, compact package. FD7141(V) is not only able to be shielded from dust and water with the IP-66 rated housing, but also fitted in high-risk environment by the structure of vandal resistant�...

  • Page 4: Physical Description

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions Physical description Inner View SD card Tilt screw Status LED Image adjustment screw 4 - User's Manual slot Focus controller Zoom controller Earth The fan will start working once the temparature inside the Network Camera is over 50°C�...
  • Page 5 VIVOTEK - A Leading Provider of Multimedia Communication Solutions Outer View Camera base Keep a note of the MAC address under the camera base before installing the camera� Hole a~c: Holes for ceiling mount or for attaching the bottom base�...
  • Page 6 VIVOTEK - A Leading Provider of Multimedia Communication Solutions General I/O Terminal Block This Network Camera provides a general I/O terminal block which is used to connect external input / output devices. The pin definitions are described below. Name N�C�...
  • Page 7 VIVOTEK - A Leading Provider of Multimedia Communication Solutions Hardware Reset Reset button Status LED The reset button is used to reset the system or restore the factory default settings� Sometimes resetting the system could set the system back to normal state� If the system problems remain after reset, restore the factory settings and install again.

  • Page 8: Installation 8

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions Installation Hardware installation First, use a screwdriver to loose three screws and detach the dome cover from the camera base. Then, follow the steps below to install the camera; either to a ceiling or to a wall.
  • Page 9 4. Feed the cables through hole A or B. If you want to use hole B, remove the rubber with a screwdriver� 5� Secure the camera base to the bottom base with supplied three screws� VIVOTEK - A Leading Provider of Multimedia Communication Solutions User's Manual - 9...

  • Page 10: Network Deployment

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions Ceiling mount without the bottom base (Embedded) 1� Attach the supplied Ceiling Hole Template Sticker to the wall� 2� Dig a hole along the inner circle of the sticker� 3. Through the 3 circles on the sticker, drill 3 pilot holes into the ceiling. Then hammer the sup- plied three plastic anchors into the holes�...

  • Page 11: Internet Connection Via A Router

    Choose this connection type if you are required to use a static IP for the Network Camera� Please refer to LAN on page 36 for details� VIVOTEK - A Leading Provider of Multimedia Communication Solutions router� The second way is to utilize a static...
  • Page 12 VIVOTEK - A Leading Provider of Multimedia Communication Solutions Internet connection via PPPoE (Point-to-Point over Ethernet) Choose this connection type if you are connected to the Internet via a DSL Line� Please refer to PPPoE on page 37 for details�...

  • Page 13: Software Installation

    After your network environment is analyzed, please click Next to continue the program. 3� The program will search all VIVOTEK devices in the same LAN� 4. After searching, the main installer window will pop up. Click on the MAC and model name which match the product label on your device to connect to the Network Camera via the Internet Explorer.

  • Page 14: Ready To Use

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions Ready to use 1� Access to the Network Camera from the Internet� 2� Retrieve live video through web browsers or recording software� Please refer to page 16 for detailed information� http://192.168.5.109/index.html...

  • Page 15: Completion

    Completion Attach the dome cover to camera. Secure the three dome screws with a screwdriver.Finally, make sure all parts of the camera are securely installed� VIVOTEK - A Leading Provider of Multimedia Communication Solutions Loosen Tighten DO NOT over tighten the controllers�...

  • Page 16: Accessing The Network Camera 16

    3� The live video will be displayed in your web browser� 4. If it is the first time for you to install VIVOTEK’s network camera, some information bar will pop up as below� Follow the instruction to install required plug-in on your computer�...
  • Page 17 1� Choose Tools > Internet Options > Security > Custom Level� 2. Look for Download signed ActiveX 3. Refresh your web browser, and then install the Active X installation� VIVOTEK - A Leading Provider of Multimedia Communication Solutions ® Controls for your browser� ®...

  • Page 18: Using Rtsp Players

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions Using RTSP players To view the MPEG-4 streaming media using RTSP players, you can use one of the following players that support RTSP streaming� Quick Time Player Real Player VLC media player 1�...

  • Page 19: Using 3Gpp-Compatible Mobile Devices

    5� Type the URL commands in the player� The format is rtsp://<public ip address of your camera>:<rtsp port>/<RTSP streaming access name for stream1 or stream2>� For example: VIVOTEK - A Leading Provider of Multimedia Communication Solutions MPEG-4 176 x 144 5 fps 40kbps 12.2kbps...

  • Page 20: Using Vivotek Recording Software

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions Using VIVOTEK recording software The product software CD also contains recording software, allowing simultaneous monitoring and video recording for multiple Network Cameras� Please install the recording software; then launch the program to add the Network Camera to the Channel list� For detailed information about how to use the recording software, please refer to the user’s manual of the software or...

  • Page 21: Main Page 21

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions Main Page This chapter explains the layout of the main page. It is composed of the following sections: Logo of VIVOTEK INC., Host name, Camera control panel, Menu, and Live video window. Logo of VIVOTEK INC. Host name...
  • Page 22 VIVOTEK - A Leading Provider of Multimedia Communication Solutions Live Video Window ■ The following window is displayed when the video mode is set to MPEG-4: Video title Title and time Video title: The video title can be configured. For more information, please refer to Video settings on page 52�...
  • Page 23 To control the zoom level, drag the slider bar. To move to a different area you want to magnify, drag the navigation screen. VIVOTEK - A Leading Provider of Multimedia Communication Solutions Mute function is not activated, move the slider bar to adjust the...
  • Page 24 VIVOTEK - A Leading Provider of Multimedia Communication Solutions Start MP4 recording: Click this button to record video clips in MP4 file format to your computer. Press Stop MP4 recording button to end recording. When you quit the web browser, video recording stops accordingly.

  • Page 25: Client Settings 25

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions Client Settings This chapter explains how to select the stream transmission mode and saving options at local computer. When completed with the settings on this page, click Save on the page bottom to take effect�...

  • Page 26: Mp4 Saving Options

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions MP4 Saving Options Users can record the live video as they are watching it by clicking page. Here, you can specify the storage destination and file name. Folder: Specify a storage destination for the recorded video files.

  • Page 27: Configuration 27

    Click Configuration on the main page will enter the camera setting pages� Note that only Administrators can access the configuration page. VIVOTEK offers an easy-to-use user interface that helps you setup your network camera without much efforts. To simplify the setting procedure, VIVOTEK designs two kinds of user inferface- -advanced mode for professional users and basic mode for entry-level users�...

  • Page 28: System

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions Advanced mode Configuration list Click to switch to Basic mode Each function on the configuration list will be explained in the following sections. Those functions that only show in Advanced mode are marked with up advanced functions, please click quickly switch to Advanced mode�...
  • Page 29 VIVOTEK - A Leading Provider of Multimedia Communication Solutions System Time Keep current date and time: Select this option to reserve the current date and time of the Network Camera. The Network Camera’s internal real-time clock maintains the date and time even when the power of the system is turned off�...

  • Page 30: Security

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions Security This section explains how to enable password protection and create multiple accounts. Root Password The administrator account name is “root”, which is permanent and can not be deleted. If you want to add more accounts in Manage User column, please apply a password for the “root”...

  • Page 31: Https

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions HTTPS Advanced mode This section explains how to enable authentication and encrypted communication over SSL� It helps protect streaming data transmission over the Internet� Enable HTTPS Check this item to enable HTTPS communication, and then select a connection option: "HTTP & HTTPS"...
  • Page 32 VIVOTEK - A Leading Provider of Multimedia Communication Solutions 4. The Certificate Information will automatically show up in the third column as below. You can click Property to see the detailed information of the certificate. 5� Click Home to return to the main page� Change the address from “http://” to “https://“ on the Address bar and press Enter on your keyboard�...
  • Page 33 VIVOTEK - A Leading Provider of Multimedia Communication Solutions Create self-signed certificate manually 1� Select this option� 2� Click Create to open a Create Certificate page, and then click Save to generate the certificate. 3. The Certificate Information will automatically show up in the third column as below. You can click Property to see the detailed information of the certificate.
  • Page 34 VIVOTEK - A Leading Provider of Multimedia Communication Solutions 3. If you see the following Information Bar, click OK and the menu bar on the top of the page to allow the Pop-ups� 4. The Pop-up window shows an example of a certificate request.
  • Page 35 ► If you want to create and install other certificate, please remove the existing one. To remove the signed certificated, uncheck the Enable HTTPS secure connection in the first column and click Save� Then click Remove to erase the certificate. VIVOTEK - A Leading Provider of Multimedia Communication Solutions User's Manual - 35...

  • Page 36: Network

    Use fixed IP address: Select this option to manually assign a static IP address to the Network Camera� 1. You can make use of VIVOTEK installation wizard II on the software CD to easily set up the Network Camera in LAN� Please refer to Software installation on page 13 for details�...
  • Page 37 Note that you must log on to the computer as a system administrator to install the UPnP components� VIVOTEK - A Leading Provider of Multimedia Communication Solutions Network Camera (192.168.5.151) and it is activated� User's Manual - 37...
  • Page 38 VIVOTEK - A Leading Provider of Multimedia Communication Solutions 1. Go to Start, click Control Panel, and then click Add or Remove Programs� 2. In the Add or Remove Programs dialog box, click Add/Remove Windows Components� 3� In the Windows Components Wizard dialog box, select Networking Services and then click Details�...
  • Page 39 Network Camera to factory default; please refer to Restore on page 85 for details� After the Network Camera is reset to factory default, it is accessible in LAN. VIVOTEK - A Leading Provider of Multimedia Communication Solutions In LAN http://192.168.4.160 or http://192.168.4.160:8080...
  • Page 40 VIVOTEK - A Leading Provider of Multimedia Communication Solutions Enable IPv6 Select this option and then click Save to enable IPv6 settings� Please note that it only works if your network environment and hardware equipment support IPv6� As for ®...
  • Page 41 DHCPv6 server and router advertisements enabled routers� If you check this item, the following blanks will be displayed for you to enter corresponding information: VIVOTEK - A Leading Provider of Multimedia Communication Solutions IPv6 address IPv6 address...
  • Page 42 VIVOTEK - A Leading Provider of Multimedia Communication Solutions Advanced mode HTTP To utilize the HTTP authentication, make sure that your have set a password for the Network Camera first; please refer to Security on page 30 for details� Authentication: Depending on your network security requirements, the Network Camera provides two types of security settings for a HTTP transaction: basic and digest�...
  • Page 43 The Network Camera supports two way audio communication so that operators can transmit and receive audio simultaneously. By using the Network Camera’s built-in or external microphone and an external speaker, you can communicate with people around the Network Camera. VIVOTEK - A Leading Provider of Multimedia Communication Solutions stream 2 is set to video2�mjpg: will fail to access the Network Camera�...
  • Page 44 FTP server allows the user to save recorded video clips. And you can utilize VIVOTEK Installation Wizard 2 to upgrade firmware via FTP server. By default, the FTP port is set to 21. It also can be assigned with another port number between 1025 and 65535�...

  • Page 45: Rtsp Streaming

    3. Type the URL command in the text box. For example: 4� The live video will be displayed in your player as below� Video 16:38:01 2008/01/03 VIVOTEK - A Leading Provider of Multimedia Communication Solutions Quick Time player Real Player...
  • Page 46 VIVOTEK - A Leading Provider of Multimedia Communication Solutions RTSP port /RTP port for video, audio/ RTCP port for video, audio The RTSP (Real-Time Streaming Protocol) controls the delivery of streaming media. By default, the port number is set to 554�...

  • Page 47: Ddns

    Enable DDNS: Select this option to enable the DDNS setting� Provider: Select a DDNS provider from the Provider drop-down list� VIVOTEK offers Safe100.net, a free dynamic domain name service to VIVOTEK customers. It is recommended that you register Additionally, we offer other DDNS providers, such as Dyndns.org (Dynamic), Dyndns.org (Custom), TZO.
  • Page 48 4� Select Enable DDNS and then click Save to take effect� ■ CustomSafe100 VIVOTEK offers documents to establish CustomSafe100 DDNS server for distributors and system integrators. You can use CustomSafe100 to register a dynamic domain name if your distributor or system integrators offer such services�...

  • Page 49: Access List

    3. The administrator has setup root password, but allows anonymous viewing. So clients can link to the live video without user name and password� For more information about Allow Anonymous Viewing, please refer to Security on page 30� VIVOTEK - A Leading Provider of Multimedia Communication Solutions IP address Elapsed time 192.168.1.147...
  • Page 50 VIVOTEK - A Leading Provider of Multimedia Communication Solutions ■ Refresh: Click this button will refresh all current connections. ■ Add to deny list: You can check some items on the connection status list, and then click this button to add them to the denied list� Please note that those checked connections will only be disconnected temporarily, but will automatically try to re-link again (IE Explore or Quick Time Player).

  • Page 51: Administrator Ip Address

    Always allow the IP address to access this device: You can check this item and add the Administrator’s IP address in this field to make sure the Administrator can always connect to the device. VIVOTEK - A Leading Provider of Multimedia Communication Solutions IP address 192.168.2.x will be bolcked.

  • Page 52: Audio And Video

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions Audio and video This section explains how to configure audio and video performances of the Network Camera. It is composed of the following two columns: Video settings and Audio settings� Video Settings Video title: Enter a name that will be displayed on the title bar of the live video�...
  • Page 53 VIVOTEK - A Leading Provider of Multimedia Communication Solutions 17:08:56 2008/06/25 Advanced mode Image Settings Click Image settings to open the Image Settings page. In this page, you can tune White balance, Brightness, Saturation, Contrast, and Sharpness for video compensation.
  • Page 54 VIVOTEK - A Leading Provider of Multimedia Communication Solutions Image Adjustment ■ Brightness: Adjust the image brightness level, which ranges from -5 to +5. The default value is set to 0. ■ Saturation: Adjust the image saturation level, which ranges from -5 to +5. The default value is set to 0.
  • Page 55 You can click Preview to fine-tune the image, or click Restore to recall the original settings without incorporating the changes. When completed with the settings on this page, click Save to take effect and click Close to quit the page� VIVOTEK - A Leading Provider of Multimedia Communication Solutions Sensor Setting 1: for normal situation...
  • Page 56 VIVOTEK - A Leading Provider of Multimedia Communication Solutions If you want to configure another sensor setting for day/night/schedule mode, please click Profile to open Sensor Settings Profile Settings page as below. Please follow the steps beolw to setup a profile: 1�...
  • Page 57 1fps, 2fps, 3fps, 5fps, 8fps, 10fps, 15fps, 20fps, 25fps and 30fps. You can also select Customize, and manually enter a value. VIVOTEK - A Leading Provider of Multimedia Communication Solutions Advanced mode...
  • Page 58 VIVOTEK - A Leading Provider of Multimedia Communication Solutions ■ Intra frame period Determine how often to plant an I frame. The shorter the duration, the more likely you will get a better video quality, but at the cost of higher network bandwidth consumption. Select the intra frame period from the following duration: 1/4 second, 1/2 second, 1 second, 2 seconds, 3 seconds and 4 seconds.

  • Page 59: Audio Settings

    4.75Kbps, 5.15Kbps, 5.90Kbps, 6.7Kbps, 7.4Kbps, 7.95Kbps, 10�2Kbps and 12�2Kbps� When completed with the settings on this page, click Save to take effect� VIVOTEK - A Leading Provider of Multimedia Communication Solutions User's Manual - 59...

  • Page 60: Motion Detection

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions Motion detection This section explains how to configure the Network Camera to enable motion detection. A total of three motion detection windows can be configured. Video(TCP-AV) Follow the steps below to enable motion detection: 1�...
  • Page 61 VIVOTEK - A Leading Provider of Multimedia Communication Solutions A green bar indicates that even though motions are detected, the event will not be triggered because the image variations are still falling under the defined threshold. Percentage = 30% If you want to configure another motion detection setting for day/night/schedule mode, please click Profile to open Motion Detection Profile Settings page as below�...
  • Page 62 VIVOTEK - A Leading Provider of Multimedia Communication Solutions NOTE ► How does motion detection work? There are two parameters for setting the motion detection: Sensitivity and Percentage� In the illustration above, frame A and frame B are two sequential images. Pixel differences between the two frames are detected and highlighted in gray (frame C), and will be compared with the sensitivity setting.

  • Page 63: Camera Tampering Detection

    3� Set up the event source as camera tampering detection on Application page > Event Settings / Server Settings (how to send alarm message) / Media Settings (send what kind of alarm message)� Please refer to page 76 for detailed information� VIVOTEK - A Leading Provider of Multimedia Communication Solutions User's Manual - 63...
  • Page 64 VIVOTEK - A Leading Provider of Multimedia Communication Solutions Homepage layout Advanced mode This section explains how to set up your own customized homepage layout. Preview This column shows the settings of your homepage layout. You can manually setup the background and font colors in Theme Options, the third column on this page.
  • Page 65 Font color Bk color of control area Font color of configuration area Bk color of configuration area VIVOTEK - A Leading Provider of Multimedia Communication Solutions Font color of video title Bk color of video area Frame color User's Manual - 65...
  • Page 66 VIVOTEK - A Leading Provider of Multimedia Communication Solutions ■ Follow the steps below to set up customized homepage: 1� Click Custom on the left column� 2� Click a blank you want to change color on the right column� customed pattern 3�...

  • Page 67: Application

    Please note that there is limited number of customized scripts you can upload, if current amount of customized scripts has reached the limitation, an alert message will pop up to remind the user. If you need more information, please ask for VIVOTEK technical support. Click to upload a file.
  • Page 68 VIVOTEK - A Leading Provider of Multimedia Communication Solutions Event Settings In the Event Settings column, click Add to open the Event Settings page. In this page, you can arrange three elements -- Trigger, Schedule and Action to plot an event. A total of 3 event settings can be configured.
  • Page 69 This option allows the Network Camera to trigger when the recording storage file is full or begin cycle reording� If you want receive Recording notify message, please refer to page 78 for detailed information� VIVOTEK - A Leading Provider of Multimedia Communication Solutions User's Manual - 69...
  • Page 70 VIVOTEK - A Leading Provider of Multimedia Communication Solutions ■ Camera tampering detection This option allows the Network Camera to trigger during camera tampering detection� To enable this function, you need to configure Camera tampering detection first. Please refer to page 63 for detailed information�...
  • Page 71 73� Click Add Media to configure page 76� Here is an example of Event Settings page: VIVOTEK - A Leading Provider of Multimedia Communication Solutions Server Settings. For more information, please refer to Server Settings Media Settings� For more information, please refer to Media Settings on...
  • Page 72 VIVOTEK - A Leading Provider of Multimedia Communication Solutions When completed, click Save to take effect and then click Close to quit Event Settings page� The new event settings / server settings / media settings will appear in the event drop-down list on the Application page�...

  • Page 73: Server Settings

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions Server Settings Click Add Server on Event Settings page to open the server setting page. In this page, you can specify where the notification messages will be send when a trigger is activated. A total of 5 server settings can be configured.
  • Page 74 VIVOTEK - A Leading Provider of Multimedia Communication Solutions FTP: Select to send the media files to a FTP server when a trigger is activated. ■ Server address: Enter the domain name or IP address of the FTP server. ■ Server port By default, the FTP port server is set to 21.
  • Page 75 VIVOTEK - A Leading Provider of Multimedia Communication Solutions HTTP: Select to send the media files to a HTTP server when a trigger is activated. ■ URL: Enter the URL of the HTTP server. ■ User name: Enter the user name if necessary.

  • Page 76: Media Settings

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions Media Settings Click Add Media on Event Settings page to open the media settings page. In this page, you can specify what kind of media to send when a trigger is activated. A total of 5 media settings can be configured.
  • Page 77 System log: Select to send a system log when a trigger is activated� Click Save to enable the settings, and then click Close to quit the page� VIVOTEK - A Leading Provider of Multimedia Communication Solutions 2 sec. 3 sec. 4 sec. 5 sec.
  • Page 78 VIVOTEK - A Leading Provider of Multimedia Communication Solutions Recording notify message: Select to send a recording notify message when a trigger is activated� Following is an example of recording notify message (.txt file), which shows a list of deleted recorded data due to cycle recording�...
  • Page 79 The format is: File name prefix + Minute (mm) You can set up the File name prefix on Media Settings page. Please refer to page 76 for detailed information� VIVOTEK - A Leading Provider of Multimedia Communication Solutions Click to do back to upper layer of the directory...

  • Page 80: Recording

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions Recording Advanced mode This section explains how to configure the recording settings for the Network Camera. Recording Settings Insert your SD card and click to test if it works. NOTE ► Before setting up this page, please set up the Network Storage on the Server Settings page first.
  • Page 81 VIVOTEK - A Leading Provider of Multimedia Communication Solutions If it works, you will also receive a test.txt file on the network storage server. 3� Enter a descriptive server name� 4� Click Save to finish the setting and click Close to quit the page�...
  • Page 82 VIVOTEK - A Leading Provider of Multimedia Communication Solutions Source: Select the recording source (stream 1 or stream 2)� Recording Schedule: Specify the recording duration� ■ Select the days on weekly basis. ■ Select the time for recording in 24-hr time format.

  • Page 83: System Log

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions System log Advanced mode This section explains how to configure the Network Camera to send system log to the remote server as a backup� Remote Log You can configure the Network Camera to send the system log file to a remote server as a log backup.

  • Page 84: View Parameters

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions View parameters Advanced mode The View parameters page lists the entire system’s parameters in alphabetical order. If you need technical assistance, please provide the information listed in this page. 84 - User's Manual...

  • Page 85: Maintenance

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions Maintenance This chapter explains how to restore the Network Camera to factory default, upgrade firmware version, etc. Reboot This feature allows you to reboot the Network Camera, which takes about one minute to complete. When completed, the live video page will be displayed in your browser.
  • Page 86 VIVOTEK - A Leading Provider of Multimedia Communication Solutions Export / Upload Files Advanced mode This feature allows you to Export / Upload daylight saving time rules, custom language files, and setting backup files. Export daylight saving time configuration file: Click to set the starting time and ending time of DST�...
  • Page 87 Note that do not power off the Network Camera during the upgrade� Follow the steps below to upgrade firmware: 1. Download a new firmware file from VIVOTEK website. The file is in .pkg file format. 2� Click Browse… and specify the firmware file.
  • Page 88 VIVOTEK - A Leading Provider of Multimedia Communication Solutions The following message is displayed when the upgrade is succeeded� The following message is displayed when you have selected an incorrect firmware file. Starting firmware upgrade... Do not power down the server during the upgrade.

  • Page 89: Url Commands Of The Network Camera

    URL syntax examples are written with "Example:" in bold face followed by a short description and a light grey box with the example. Example: request a single snapshot image http://mywebserver/cgi-bin/viewer/video.jpg VIVOTEK - A Leading Provider of Multimedia Communication Solutions User's Manual - 89...

  • Page 90: Technical Specifications

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions General CGI URL syntax and parameters CGI parameters are written in lower-case and as one word without any underscores or other separators. When the CGI request includes internal camera parameters, the internal parameters must be written exactly as they are named in the camera or video server.
  • Page 91 VIVOTEK - A Leading Provider of Multimedia Communication Solutions http://<servername>/cgi-bin/viewer/getparam.cgi?[<parameter>] [&<parameter>…] http://<servername>/cgi-bin/operator/getparam.cgi?[<parameter>] [&<parameter>…] http://<servername>/cgi-bin/admin/getparam.cgi?[<parameter>] [&<parameter>…] where the <parameter> should be <group>[_<name>] or <group>[.<name>] If you do not specify the any parameters, all the parameters on the server will be returned. If you specify only <group>, the parameters of related group will be returned.

  • Page 92: Set Server Parameter Values

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions Set server parameter values Note: The access right depends on the URL directory. Method: GET/POST Syntax: http://<servername>/cgi-bin/anonymous/setparam.cgi? <parameter>=<value> [&<parameter>=<value>…][&update=<value>][&return=<return page>] http://<servername>/cgi-bin/viewer/setparam.cgi? <parameter>=<value> [&<parameter>=<value>…][&update=<value>] [&return=<return page>] http://<servername>/cgi-bin/operator/setparam.cgi? <parameter>=<value> [&<parameter>=<value>…][&update=<value>] [&return=<return page>] http://<servername>/cgi-bin/admin/setparam.cgi? <parameter>=<value>...

  • Page 93: Available Parameters On The Server

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions \r\n <parameter pair> where <parameter pair> is <parameter>=<value>\r\n [<parameter pair>] Only the parameters that you set and readable will be returned. Example: Set the IP address of server to 192.168.0.123 Request: http://myserver/cgi-bin/admin/setparam.cgi?network_ipaddress=192.168.0.123...
  • Page 94 VIVOTEK - A Leading Provider of Multimedia Communication Solutions <value3>, … blank A blank string everything inside <> As description NOTE: The camera should prevent to restart when parameter changed. Group: system NAME VALUE hostname string[40] ledoff <boolean> lowlight <boolean>...
  • Page 95 VIVOTEK - A Leading Provider of Multimedia Communication Solutions Central Time, Mexico City, Saskatchewan -200: GMT-05:00 Eastern Time, New York, Toronto -201: GMT-05:00 Bogota, Lima, Quito, Indiana -160: GMT-04:00 Atlantic Time, Canada, Caracas, La Paz, Santiago -140: GMT-03:30 Newfoundland -120: GMT-03:00 Brasilia, Buenos Aires,...
  • Page 96 VIVOTEK - A Leading Provider of Multimedia Communication Solutions daylight_enable <boolean> daylight_dstactualmode <boolean> daylight_auto_begintime string[19] daylight_auto_endtime string[19] updateinterval 3600, 86400, 604800, 2592000 restore <positive integer> reset <positive integer> restoreexceptnet <Any value> 96 - User's Manual Krasnoyarsk 320: GMT 08:00 Beijing, Chongging,...
  • Page 97 VIVOTEK - A Leading Provider of Multimedia Communication Solutions restoreexceptdst <Any value> restoreexceptlang <Any Value> SubGroup of system: info (The fields in this group are unchangeable.) NAME VALUE modelname string[40] extendedmodelname string[40] serialnumber <mac address> firmwareversion string[40] language_count <integer> language_i<0~(count-1)>...
  • Page 98 VIVOTEK - A Leading Provider of Multimedia Communication Solutions Group: status NAME VALUE videoactualmodulation ntsc, di_i<0~(ndi-1)> <boolean> do_i<0~ndi-1)> <boolean> daynight day, night onlinenum_rtsp integer onlinenum_httppush integer string Group: di_i<0~(ndi-1)> (capability.ndi > 0) NAME VALUE normalstate high, Group: do_i<0~(ndo-1)> (capability.ndo > 0)
  • Page 99 VIVOTEK - A Leading Provider of Multimedia Communication Solutions operator, admin user_i<1~20>_ viewer, privilege operator, admin Group: network NAME VALUE type lan, pppoe resetip <boolean> ipaddress <ip address> subnet <ip address> router <ip address> dns1 <ip address> dns2 <ip address>...
  • Page 100 VIVOTEK - A Leading Provider of Multimedia Communication Solutions Subgroup of network: http NAME VALUE port 1025 ~ 65535 alternateport 1025~65535 authmode basic, digest s0_accessname string[32] s1_accessname string[32] anonymousviewing <boolean> Subgroup of network: https NAME VALUE port 443, 1025 ~ 65535...
  • Page 101 VIVOTEK - A Leading Provider of Multimedia Communication Solutions s1_audiotrack <integer> Subgroup of rtsp_s<0~(n-1)>: multicast, n is stream count NAME VALUE alwaysmulticast <boolean> ipaddress <ip address> videoport 1025 ~ 65535 audioport 1025 ~ 65535 1 ~ 255 Subgroup of network: sip...
  • Page 102 VIVOTEK - A Leading Provider of Multimedia Communication Solutions Group: ipfilter NAME VALUE enable <boolean> admin_enable <boolean> admin_ip 1.0.0.0 ~ 255.255.255.255 maxconnection 0~10 allow_i<0~9>_start 1.0.0.0 ~ 255.255.255.255 allow_i<0~9>_end 1.0.0.0 ~ 255.255.255.255 deny_i<0~9>_start 1.0.0.0 ~ 255.255.255.255 deny_i<0~9>_end 1.0.0.0 ~ 255.255.255.255 ipv6_allow_i<0~9>...
  • Page 103 VIVOTEK - A Leading Provider of Multimedia Communication Solutions atwbvalue1 999999999 atwbvalue2 999999999 exposurelevel 1 ~ 8 autoiris <boolean> enablewdr <boolean> color 0, 1 flip <boolean> mirror <boolean> ptzstatus <integer> text string[16] imprinttimestamp <boolean> The auto white balance value. The auto white balance value.
  • Page 104 VIVOTEK - A Leading Provider of Multimedia Communication Solutions maxexposure options enablepreview profile_<0~(k-1)>_enable profile_<0~(k-1)>_policy profile_<0~(k-1)>_begintime profile_<0~(k-1)>_endtime profile_<0~(k-1)>_maxexpos profile_<0~(k-1)>_exposurel evel profile_<0~(k-1)>_agc profile_<0~(k-1)>_autoiris profile_<0~(k-1)>_enablewdr s<0~(m-1)>_codectype s<0~(m-1)>_resolution 104 - User's Manual 1~120 Maximum exposure time quality, To customize video quality first or video framerate frame rate first.
  • Page 105 VIVOTEK - A Leading Provider of Multimedia Communication Solutions 720x480 s<0~(m-1)>_field2frame <boolean> s<0~(m-1)>_mpeg4_intraper 250, 500, 1000, 2000, 3000, 4000 s<0~(m-1)>_mpeg4_ratecon cbr, vbr trolmode s<0~(m-1)>_mpeg4_quant 1~5, 99 s<0~(m-1)>_mpeg4_qvalue 1~31 s<0~(m-1)>_mpeg4_bitrate 1000~400 0000 s<0~(m-1)>_mpeg4_maxfra 1~25, 26~30 (only for NTSC or 60Hz CMOS) s<0~(m-1)>_mjpeg_quant...
  • Page 106 VIVOTEK - A Leading Provider of Multimedia Communication Solutions Group: videoinpreview NAME VALUE maxexposure 1~120 exposurelevel 1 ~ 8 enableblc <boolean> enablewdr <boolean> autoiris <boolean> Group: audioin_c<0~(n-1)> for n channel products NAME VALUE source micin, linein mute 0, 1 gain <product...
  • Page 107 VIVOTEK - A Leading Provider of Multimedia Communication Solutions 6700, 7400, 7950, 10200, 12200 Group: image_c<0~(n-1)> for n channel products NAME VALUE SECURITY (get/set) brightness -5 ~ 5 saturation -5 ~ 5 contrast -5 ~ 5 sharpness -3 ~ 3 Group: imagepreview_c<0~(n-1)>...
  • Page 108 VIVOTEK - A Leading Provider of Multimedia Communication Solutions win_i <0~2>_top 0 ~ 240 win_i <0~2>_width 0 ~ 320 win_i<0~2>_height 0 ~ 240 win_i<0~2>_objsize 0 ~ 100 win_i<0~2>_sensitivity 0 ~ 100 Group: motion_ c<0~(n-1)>_profile_i<0~(m-1)> for n channel, m motion profile product (capability_nmotionprofile >...
  • Page 109 VIVOTEK - A Leading Provider of Multimedia Communication Solutions Group: ddns NAME VALUE enable <boolean> provider Safe100, DyndnsDynamic, DyndnsCustom, TZO, DHS, DynInterfree, CustomSafe100 <provider>_hostname string[128] <provider>_usernam string[64] eemail <provider>_password string[64] <provider>_serverna string[128] Group: upnppresentation NAME VALUE enable <boolean> Group: upnpportforwarding...
  • Page 110 VIVOTEK - A Leading Provider of Multimedia Communication Solutions serverip <IP address> serverport 514, 1025~65535 level Group: layout NAME logo_default logo_link theme_option theme_color_font theme_color_configfont theme_color_titlefont theme_color_controlbackground theme_color_configbackground theme_color_videobackground theme_color_case Group: privacymask_c<0~(n-1)> for n channel product NAME VALUE enable <boolean> win_i<0~4>_enable <boolean>...
  • Page 111 VIVOTEK - A Leading Provider of Multimedia Communication Solutions win_i<0~4>_name string[14] win_i<0~4>_left 0 ~ 320/352 win_i<0~4>_top 0 ~ 240/288 win_i<0~4>_width 0 ~ 320/352 win_i<0~4>_height 0 ~ 240/288 win_i<0~4>_color 0 ~ 13 Group: capability NAME VALUE api_httpversion 0200a bootuptime <positive integer>...
  • Page 112 VIVOTEK - A Leading Provider of Multimedia Communication Solutions ptzenabled <positive integer> evctrlchannel <boolean> protocol_https <boolean> protocol_rtsp <boolean> protocol_sip <boolean> protocol_maxconnection <positive integer> protocol_maxgenconnec <positive integer> tion protocol_maxmegaconn <positive integer> ection protocol_rtp_multicast_ <boolean> scalable protocol_rtp_multicast_ <boolean> backchannel protocol_rtp_tcp <boolean> protocol_rtp_http <boolean>...
  • Page 113 VIVOTEK - A Leading Provider of Multimedia Communication Solutions protocol_spush_mjpeg <boolean> protocol_snmp <boolean> protocol_ipv6 <boolean> videoin_type 0, 1, 2 videoin_resolution <a list of the available resolution separates by comma> videoin_maxframerate <a list of the available max frame rate separates by comma>...
  • Page 114 VIVOTEK - A Leading Provider of Multimedia Communication Solutions audioout_codec <a list of the available codec types separaters by comma) camctrl_httptunnel <boolean> uart_httptunnel <boolean> transmission_mode Both joystick <boolean> network_wire <boolean> network_wireless <boolean> wireless_802dot11b <boolean> wireless_802dot11g <boolean> wireless_encrypt_wep <boolean> wireless_encrypt_wpa <boolean>...
  • Page 115 VIVOTEK - A Leading Provider of Multimedia Communication Solutions enable 0, 1 priority 0, 1, 2 delay 1~999 trigger boot, motion, seq, visignal, recnotify, tampering <integer> mdwin <integer> mdwin0 <integer> inter 1~999 To enable or disable this event. Indicate the priority of this event.
  • Page 116 VIVOTEK - A Leading Provider of Multimedia Communication Solutions weekday <interger> begintime hh:mm endtime hh:mm lowlightcondition 0, 1 action_do_i<0~(ndo-1) 0, 1 >_enable action_do_i<0~(ndo-1) 1~999 >_duration action_cf_enable 0. 1 action_cf_folder string[128] action_cf_media NULL, 0~4 action_cf_datefolder <boolean> action_server_i<0~4>_e 0, 1 nable action_server_i<0~4>_...
  • Page 117 VIVOTEK - A Leading Provider of Multimedia Communication Solutions type email, ftp, http, http_url string[128] http_username string[64] http_passwd string[64] ftp_address string[128] ftp_username string[64] ftp_passwd string[64] ftp_port 0~65535 ftp_location string[128] ftp_passive 0, 1 email_address string[128] email_sslmode <boolean> email_username string[64] email_port 0~65535...
  • Page 118 VIVOTEK - A Leading Provider of Multimedia Communication Solutions type snapshot, systemlog videoclip snapshot_source <integer> snapshot_prefix string[16] snapshot_datesuffix 0, 1 snapshot_preevent 0 ~ 7 snapshot_postevent 0 ~ 7 videoclip_source <integer> videoclip_prefix string[16] videoclip_preevent 0 ~ 9 videoclip_maxduration 1 ~ 10...
  • Page 119 VIVOTEK - A Leading Provider of Multimedia Communication Solutions weekday <interger> begintime hh:mm endtime hh:mm prefix string[16] limitsize cyclesize cyclic notify notifyserver 0~31 reserveamount Indicate which weekday is scheduled. One bit represents one weekday. The bit0 (LSB) indicates Saturday. The bit1 indicates Friday.
  • Page 120 VIVOTEK - A Leading Provider of Multimedia Communication Solutions dest cffolder string[128] Group: custom_i<0~2> PARAMETER VALUE name string[40] Group: path NAME VALUE encoder1_start <boolean> encoder2_start <boolean> Group: https (product dependent) NAME VALUE connect 1025 ~ 65535 enable <boolean> policy <Boolean>...

  • Page 121: Drive The Digital Output

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions localityname string[128] organizationname string[64] unit string[32] commonname string[64] validdays 0 ~ 9999 Drive the digital output Note: This request requires the privilege of viewer. Method: GET/POST Syntax: http://<servername>/cgi-bin/dido/setdo.cgi?do0=<state>[&do1=<state>][&do2=<state>] [&do3=<state>][&return=<return page>] Where state is 0, 1. “0” means inactive or normal state while “1” means active or triggered state.

  • Page 122: Query Status Of The Digital Output

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions http://<servername>/cgi-bin/dido/getdi.cgi?[di0][&di1][&di2][&di3] If no parameter is specified, all the status of digital input will be returned. Return: HTTP/1.0 200 OK\r\n Content-Type: text/plain\r\n Content-Length: <length>\r\n \r\n [di0=<state>]\r\n [di1=<state>]\r\n [di2=<state>]\r\n [di3=<state>]\r\n where <state> can be 0 or 1.

  • Page 123: Capture Single Snapshot

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions Content-Type: text/plain\r\n Content-Length: <length>\r\n \r\n [do0=<state>]\r\n [do1=<state>]\r\n [do2=<state>]\r\n [do3=<state>]\r\n where <state> can be 0 or 1. Example: Query the status of digital output 1 Request: http://myserver/cgi-bin/dido/getdo.cgi?do0 Response: HTTP/1.0 200 OK\r\n Content-Type: text/plain\r\n...

  • Page 124: Account Management

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions Return: HTTP/1.0 200 OK\r\n Content-Type: image/jpeg\r\n [Content-Length: <image size>\r\n] <binary JPEG image data> Account management Note: This request requires administrator privilege Method: GET/POST Syntax: http://<servername>/cgi-bin/admin/editaccount.cgi? method=<value>&username=<name>[&userpass=<value>][&privilege=<value>] [&privilege=<value>][…][&return=<return page>] PARAMETER VALUE method...

  • Page 125: System Logs

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions return <return page> System logs Note: This request require administrator privilege Method: GET/POST Syntax: http://<servername>/cgi-bin/admin/syslog.cgi Server will return the up-to-date system log. Return: HTTP/1.0 200 OK\r\n Content-Type: text/plain\r\n Content-Length: <syslog length>\r\n \r\n <system log information>\r\n...

  • Page 126: Upgrade Firmware

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions HTTP/1.0 200 OK\r\n Content-Type: text/plain\r\n Content-Length: <configuration file length>\r\n \r\n <configuration data>\r\n Upgrade firmware Note: This request requires administrator privilege Method: POST Syntax: http://<servername>/cgi-bin/admin/upgrade.cgi Post data: fimage=<file name>[&return=<return page>]\r\n \r\n <multipart encoded form data>...
  • Page 127 VIVOTEK - A Leading Provider of Multimedia Communication Solutions Content-Length: <system information length>\r\n \r\n Model=<model name of server>\r\n CapVersion=0200\r\n PARAMETER(supported VALUE capability version) Model system.firmwareversion CapVersion MMmm, MM is major version from 00 ~ 99 mm is minor version from 00 ~ 99...
  • Page 128 VIVOTEK - A Leading Provider of Multimedia Communication Solutions deletedeny start <ip address> <ip address> index <value> return <return page> Event/Control HTTP tunnel channel Note: This request requires admin Method: GET and POST Syntax: http://<servername>/cgi-bin/admin/ctrlevent.cgi ------------------------------------------------------------------------- GET /cgi-bin/admin/ctrlevent.cgi x-sessioncookie: string[22]...
  • Page 129 VIVOTEK - A Leading Provider of Multimedia Communication Solutions User must use GET and POST to establish two channels for downstream and upstream. The x-sessioncookie in the GET and POST should be the same to be recognized as a pair for one session. The contents of upstream should be base64 encoded to be able to pass through some proxy server.

  • Page 130: Angle Of View

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions Tilt Screw SD Card Slot Status LED Technical Specifications Specifications Models ．FD7141 ．FD7141V System ．CPU: Bach SoC ．Flash: 8 MB ．RAM: 96 MB ．Embedded OS: Linux 2.6 Lens ．Board lens, vari-focal, f=3.3 ~ 12mm, F1.4 (wide), F2.9 (tele), focus range: 50cm to infinity (FD7141) ．Board lens, vari-focal, f=9 ~ 22mm, F1.4 (wide), F1.6 (tele),...

  • Page 131: Technology License Notice

    VIVOTEK - A Leading Provider of Multimedia Communication Solutions Technology License Notice MPEG-4 AAC Technology THIS PRODUCT IS LICENSED UNDER THE MPEG-4 AAC AUDIO PATENT LICENSE. THIS PRODUCT MAY NOT BE DECOMPILED, REVERSE-ENGINEERED OR COPIED, EXCEPT REGARD TO PC SOFTWARE, YOU MAY MAKE SINGLE COPIES FOR ARCHIVAL PURPOSES.

  • Page 132: Electromagnetic Compatibility (Emc)

    EN55022/1998, and the requirement for immunity according to EN50082-1/1992. Liability VIVOTEK Inc� cannot be held responsible for any technical or typographical errors and reserves the right to make changes to the product and manuals without prior notice� VIVOTEK Inc� makes no warranty of any kind with regard to the material contained within this document, including, but not limited to, the implied warranties of merchantability and fitness for any particular purpose�...

This manual is also suitable for:

Fd7141

Table of Contents
