- Page 1 FD7141(V)
-
Page 2: Warning Before Install
Warning Before Install Power off the Network Camera as Refer to your user's manual for the soon as it is found smoking or smelt operating temperature. unusual. Contact your distributor when such cases happen. Do not place the Network Camera on Do not touch the Network Camera unsteady surfaces. -
Page 3: Package Contents
Package Contents FD7141 (FD7141V) Bottom base Alignment sticker / Power adapter Ceiling hole template sticker Alignment Sticker Drill hole Drill hole At least drill 2 pilot holes symmetrically on each Ceiling Hole Template Sticker side to avoid falling. L-type hex key wrench /... -
Page 4: Physical Description
Physical Description Inner View f= 3.3~12 mm (FD7141 Lens) f= 9~22 mm (FD7141V Lens) Lens SD card Light sensor Tilt screw slot IR LEDs Pan screw Status LED Indented reset button Focus controller Image adjustment screw Zoom controller General I/O terminal... - Page 5 Network Camera RoHS Model No: FD7141 MAC:0002D1083236 This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
-
Page 6: Hardware Installation
Hardware Installation First, use the supplied screwdriver to loose three screws and detach the dome cover from the camera base. Then, follow the steps below to install the camera; either to a ceiling or to a wall. Ceiling mount with the bottom base 1. - Page 7 Wall mount with the bottom base 1. Attach the supplied Alignment Sticker to the wall. 2. Through the 10 circles on the sticker, drill 2 pilot holes symmetrically on each side into the wall. Then Hammer the supplied four plastic anchors into the holes. 3.
-
Page 8: Network Deployment
Ceiling mount without the bottom base (Embedded) 1. Attach the supplied Ceiling Hole Template Sticker to the wall. 2. Dig a hole along the inner circle of the sticker. 3. Through the 3 circles on the sticker, drill 3 pilot holes into the ceiling. Then hammer the supplied three plastic anchors into the holes. - Page 9 Power over Ethernet (PoE) When using a PoE-enabled switch The Network Camera is PoE-compliant, allowing transmission of power and data via single Ethernet cable. See the following illustration to connect the Network Camera to a PoE-enabled switch via Ethernet cable. PoE switch When using a non-PoE switch Use a PoE power injector (optional) to connect between the Network Camera and a...
-
Page 10: Assigning Ip Address
Installation Wizard 2 3. The program will search the VIVOTEK Network Devices in the same LAN. 4. After searching, the main installer window will pop up. Click on the MAC that matches the one labeled on the bottom of your device to connect the Internet Explorer to the Network Camera. -
Page 11: Ready To Use
Ready to Use 1. Access to the Network Camera from the Internet. 2. Retrieve live video through web browsers or recording software. For further setup, please refer to user's manual on the software CD. EN - 10... -
Page 12: Adjusting The Lens
Adjusting the Lens Based on the live image retrieved from the camera, adjust the camera lens by doing the following: To adjust the viewing angle 1. Loosen the pan screw and then turn the lens module left and right. Upon completion, tighten the pan screw. - Page 13 Note If you use FD7141V (f= 9~22 mm), please hold the supplied plastic cover in front of the lens while adjusting the focus controller, as the illustration below. axis of the lens Completion Attach the dome cover to camera. Secure the three dome screws with the supplied screwdriver.
