Masterbuilt 710 Instruction Manual page 9

Parts List
1
2
4
5
NO QTY
1 4
2 1
3 1
4 1
5 1
6 1
7 1
8 1
9 1
10 1
11 1
8
20
3
10
7
21
6
DESCRIPTION
Rack
Water Bowl
Wood Chip Tray
Left Rear Leg
Left Front Leg
Right Front Leg
Right Rear Leg
Smoker Body
Wood Chip Housing
Element
Door Handle
11
9
13
22
NO
12
13
14
15
16
17
18
19
20
21
22
14
15
12
16
DESCRIPTION
QTY
Door (pre-assembled)
1
Drip Pan
1
Digital Control Panel
1
Grease Tray
1
Wood Chip Loader
1
Side Brace
2
Rear Cross Brace
1
Front Panel
1
Temperature Probe
1
Door Switch
1
Antenna
1
TIME TEMP MP 1 MP 2 MP 3 MP 4
1 2 34
17
18
19
9
