- Page 1 L8087...
- Page 2 Dear customers, Very pleased that you will purchase and use the tire changer produced by our company. Warning This instruction manual is the important part of the product. Please read it carefully. Keep it properly in order to maintain and service. ...
- Page 3 If you want to move the tire changer, you should under the guidance of the professional service personnel. Safety Label Instruction Be sure to read all warning labels and instruction manual prior to operation of this machine. Keep hands clear of bead area when inflating. Always wear safety glasses when operating this machine.
- Page 4 When breaking bead, the bead breaking blade will quickly move leftwards. Note: when press the tire, the opened clamp cylinder may injury the hand of the operator. Remember, do not touch the sidewall of the tire. Do not reach any part of your body under the demount tool. When clamping the rim, do not reach your hand or other parts of the body in between the clamp&...
-
Page 5: Table Of Contents
Content ....................1 Chapter 1 Brief Introduction ................... 1 1.1 brief introduction ..................1 1.2 overall dimension ..................2 1.3 technical parameter ..................... 2 1.4 application ..................3 1.5 work environment ............4 Chapter 2 Basic Construction and Operational parts ................ -
Page 6: Chapter 1 Brief Introduction
Chapter 1 Brief Introduction 1.1 brief introduction This tire changer is the tire changer featured with tilt and horizontal arm, suitable to mount, demount and inflate all types of car tire with tube and tubeless. The operation is easy, convenient and safety. It is the necessary equipment for the auto service shop and tire shop. This equipment can be optional equipped with assist arm to mount and demount the low profile and stiff tire.Please kindly refer to the product brochure or consult the salesman to acquire the optional model of assist arm. -
Page 7: Technical Parameter
(outward clamp) (inward clamp) 355mm（14"） 1100mm（43.3"） 10″～22″ 12″～25" L8087 1.5 work environment Environment temperature:0℃～45℃（32℉~113℉） Relative humidity: 30～95% Max. Altitude: 1000M （304.58 ft） Without dust and without gas easy to explosive and rusty The space around machine is not less than indicated in Fig2. -
Page 8: Chapter 2 Basic Construction And Operational Parts
Chapter 2 Basic construction and operational part 1 —knob12—turntable turning pedal 2 —vertical shaft spring13—breaker blade 3 —handle valve 14—shift pin 4 —hexangular shaft15—bead breaker cylinder 5 —demounting head16—bead breaker arm 6 —clamping jaw17—vertical column 7 —turntable18—inflation gauge(GT model) 8 —clamping cylinder19—air tank(GT model) 9 —column tilt pedal20—exhaust valve (GT model) 10—clamp pedal21—air regulator 11—bead breaker pedal22—quick inflation pedal... -
Page 9: Chapter 3 Installation And Commission
Chapter 3 Installation and commission Carefully read the manual before installation and the change on the parts of the machine without the permission of the manufacturer can cause the damage to the machine; Installation and commission person must have some knowledge relating to electrical;... - Page 10 5# Allen key like FIG5. After installation air regulator, remove the straight connector which connect the two pcs ofφ8 PU hose like FIG6-1 & FIG6-2. (This connector can avoid the PU hose to back into the main body. Connect the PU hose into the connectors of air regulator like FIG6.
- Page 11 As shown in Fig9, plug cylinder rod (FIG9-1) into the hole of bead breaking arm slide bush (FIG9-2). Twist the adjusting device (FIG9-3) onto the end of cylinder rod. Hang the spring (FIG9-4)like the FIG9. 3.2.4 Installation of the column assembly ...
-
Page 12: Air Test
FIG11. Connect the column and the tilt cylinder then fix them using nuts (FIG11-3). 3.2.5 Connect the inflation gun or inflation gauge. Take out the inflation gun then connect it the open nut and tighten it. Hang the gun to the hook after installation. -
Page 13: Basic Principle
CHAPTER 4 DEMOUNT AND MOUNT TIRE Note: the operator must be trained and qualified then allow to operate the tire changer.Need to use the proper device and tools, wear the protective clothes, and use the proper safety precautions, like goggle, earplug, and safety shoe and so on. BASIC PRINCIPLE ... -
Page 14: Mount Tire
Press the lock handle press button(FIG3-3) to lock horizontal arm and hexangular shaft and the hexangular shaft will automatically move upwards. The quadric shaft will automatically backward a little to make the demount tool detached from the rim of the rim to avoid the damage on the rim(FIG16) NOTE: The angle of the demount tool has been calibrated according to the standard rim (14"). -
Page 15: Inflation
Press down the right side of the tire as hard as you can and step turntable pedal (FIG3-12) to rotate the turntable clockwise to guide the lip into the tire detach slot completely. If there is tube, raise up the demount tool and put in the tube and position the core. ... -
Page 16: Chapter 5Repair And Maintenance
manufacturer. In this machine, there is a pressure decrease valve to keep theinflation pressure not exceed 3.5bar. For tubeless wheel with lax tire, the common inflation is invalid and can use the quick inflation then common inflation. (The quick inflation function is not standard configuration and need to special order). - Page 17 Note:Only the professional personnel can repair. Before any operations of repair and maintenance, you should power off and the power plug should be monitored by the repair personnel, meanwhile switch the pneumatic source and deflate the residual gas. To correct use the tire changer and prolong its life,repair and maintenance in accordance with the operation manual is necessary.
-
Page 18: Chapter 6 Transportation
hexangular shaft downward by 16# spanner;If the clearance if too small we can adjust the nuts on the vertical hexangular shaft upward. Switch off the air source and detach the protective cover at the upper end of the horizontal arm.Use 5# spanner to loosen the lock nut (Fig21-C)on the M6 screw at the two end.Adjust the M6 screw,meanwhile use your hand to push the quadric shaft until it runs smooth and thenlock the nut.Use the spanner to adjust the screwin the middle and... - Page 19 CHAPTER 7 ELECTCTRICAL AND PENUMATIC DRAWING 220V ELECTRICAL PRINCIPLE DRAWING - 14 -/ 19...
- Page 20 7.4 PNEUMATIC PRINCIPLE DRAWING - 15 -/ 19...
- Page 21 CHAPTER 8 TROUBLESHOOTING ANALYZE AND SOLUTION CHAPTER REASON TROUBLESHOOTING Turntable rotates in one Universal switch contact Change Universal switch direction. burned Turntable does not rotate. Belt damage Change belt Belt too loose Adjust the tension of the belt Motor or power source have Check motor, power source and problems power source cable...
- Page 22 CHAPTER 9 EXPLODED VIEW OF MACHINE - 17 -/ 19...
- Page 23 - 18 -/ 19...
- Page 24 - 19 -/ 19...
