Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts,
which may have come loose inside the carton during shipment. Identify and count all items and compare with
the parts list and/or hardware list shown.
NO
COMPONENT
A
Headboard
B
Footboard
Headboard Leg LSF
C
Headboard Leg RSF
D
E
Slats
Slats Support Leg
F
G
Side Rail
H
Bottom Stretcher
STEP 1 :
Attach Head Board Leg ( C & D ) to Head Board ( A ) as shown using JCBC BOLT ( 1 ) with Spring Washer ( 2 ), Flat washer ( 3 )
and securing with Allen Key ( 4 ) .
A
C
NOTE : MUST TIGHTEN SCREWS PERIODCALLY WITH USE SCREW WILL BECOME LOOSE CHECK TIGHTNESS OF ALL SCREW EVERY 6-8 WEEKS.
ASSEMBLY INSTRUCTIONS
B1655-315 OBSIDIAN 5/0 Q HEADBOARD,FOOTBOARD & SLATS
B1655-335 OBSIDIAN 5/0-6/6 Q/EK SIDE RAILS
PARTS LIST
DRAWING
QTY
NO
COMPONENT
1
JCBC M6 x 1 3/16" Blk
1 pc
2
Spring Washer 1/4" Blk
1 pc
3
Flat Washer 1/4"IDx4/8"OD Blk
1 pc
4
Allen Key M4 x 2 9/16" Blk
5
Allen Key M5 x 2 9/16" Blk
1 pc
Flat Head Chipboard Screw
4 pcs
6
M4 x 1 2/8" Rbw
4 pcs
2 pcs
1 pc
D
HARDWARE LIST
DRAWING
x6
QTY
6 pcs
6 pcs
6 pcs
1 pc
1 pc
12 pcs
4
1
2
3
1 OF 2
Advertisement
Related Manuals for New Classic Furniture B1655-315
Summary of Contents for New Classic Furniture B1655-315
- Page 1 ASSEMBLY INSTRUCTIONS B1655-315 OBSIDIAN 5/0 Q HEADBOARD,FOOTBOARD & SLATS B1655-335 OBSIDIAN 5/0-6/6 Q/EK SIDE RAILS Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts, which may have come loose inside the carton during shipment. Identify and count all items and compare with the parts list and/or hardware list shown.
- Page 2 STEP 2 : Hook side rail ( G ) to Headboard ( A ) closely and push down to fit. repeat step 2 with other end of rail to hook onto Footboard ( B ). STEP 3 : Tighten the 4 Corner with Allen Key ( 5 ) . Fix the Bed Slat Support Leg ( F ), to Bed Slat ( E ) as shown . Install the bed slat ( E ) to side rail ( G ) and tighten with Csk Screw ( 6 ) as per diagram shown.
