Installation Instructions
Attention Installer:
Please read these instructions carefully to prevent missing important steps.
Improper installations may result in damage to the lock and void the factory warranty.
The accuracy of the door preparation is critical for proper functioning and security of this lock.
Misalignment can cause premature wear and a lessening of security.
For Technical Assistance call Corbin Russwin at 1-800-810-WIRE (9473)
Copyright © 2020-2023 ASSA ABLOY Access and Egress Hardware Group, Inc.
All rights reserved. Reproduction in whole or in part without the express written
permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
SN
Series
SN200 Wiegand
SN210 OSDP
FE6600 Series
Multi-Point Lockset
FM565 01/23
Advertisement
Related Manuals for Corbin Russwin ASSA ABLOY SN Series
Summary of Contents for Corbin Russwin ASSA ABLOY SN Series
- Page 1 The accuracy of the door preparation is critical for proper functioning and security of this lock. Misalignment can cause premature wear and a lessening of security. For Technical Assistance call Corbin Russwin at 1-800-810-WIRE (9473) Copyright © 2020-2023 ASSA ABLOY Access and Egress Hardware Group, Inc.
-
Page 2: Table Of Contents
Installation Instructions SN200/210 FE6600 Multi-Point Lockset Table of Contents 1) Regulatory Compliance ..........3 2) Warning ............... 3 3) Specifications .............. 4 4) Product Illustrations ..........5 5) Wiring Diagrams ............7 6) Installation Instructions .......... 11 7) Operational Check ........... 20 Copyright ©... -
Page 3: Regulatory Compliance
Pour plus d’informations, visitez: www.P65warnings.ca.gov. Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Corbin Russwin makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings. -
Page 4: Specifications
Installation Instructions SN200/210 FE6600 Multi-Point Lockset 3) Specifications • UL Listed* - UL 294 Indoor Use • UL 294 Access Control Ratings: • CUL Listed - S319: Class 1 Destructive Attack Level 1 • ANSI/BHMA A156.25 Listed Grade 1 Compliant Line Security Level 1 *UL294, S319, &... -
Page 5: Product Illustrations
Installation Instructions SN200/210 FE6600 Multi-Point Lockset 4) Product Illustrations ITEM DESCRIPTION Req. Reader & Harness Assembly Signo Reader Back Plate Mounting Packet Fire Plate Packet Inside Escutcheon See document FM643 for part numbers Copyright © 2020-2023 ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. - Page 6 Installation Instructions SN200/210 FE6600 Multi-Point Lockset 4) Product Illustrations (Continued) Tools Required: • #2 Phillips Screwdriver (Standard size) • Flat Blade Screwdriver (Standard size) • 1/8" Allen Wrench • TR10 Torx Security Screwdriver For mechanical parts listing refer to FE6600 Parts Manual 45499 Reference SN200/210 Catalog For Available Lever Styles Reference SN200/210 Catalog For Available Rose Styles Lock Body...
-
Page 7: Wiring Diagrams
Installation Instructions SN200/210 FE6600 Multi-Point Lockset 5) Wiring Diagrams Product 8 PIN CONNECTOR 4 PIN CONNECTOR 1-Black 2-Red 3-White 4-Green 5-Orange 6-Blue 7-Brown 8-Yellow 1-Violet 2-Gray 3-Pink 4-Tan ACCESS CONTROL DEVICES: SN200/210 Lockset, ElectroLynx wire Color / Function assignments SN200 (UL294) TAMPER WIEGAND- WIEGAND-... - Page 8 Installation Instructions SN200/210 FE6600 Multi-Point Lockset 5) Wiring Diagrams (Continued) SN200 Wiegand UL294/TAMPER Configuration Application Diagram #1 Tamper will trigger when reader is removed from door and tamper wiring is connected at the panel. 12/24VDC System Average Peak Average Peak Reader* 75mA 250mA...
- Page 9 Installation Instructions SN200/210 FE6600 Multi-Point Lockset 5) Wiring Diagrams (Continued) SN200 Wiegand Non-UL294 Configuration Application Diagram #2 Connect GREEN_LED input to switch controlled by panel. Shorting GREEN_LED to READER_ NEG (Black) with panel switch will override reader LED to keep it green 12/24VDC System Average Peak...
- Page 10 Installation Instructions SN200/210 FE6600 Multi-Point Lockset 5) Wiring Diagrams (Continued) SN210 OSDP Application Diagram #3 (12/24VDC System) OSDP Operation Mode*: *LED/Sounder control and Tamper status communicated over OSDP serial protocol PIN 8 (Yellow – n/a) PIN 6 (Blue – RX COM) PIN 4 (Green –...
-
Page 11: Installation Instructions
Installation Instructions SN200/210 FE6600 Multi-Point Lockset 6) Installation Instructions Verify Hand and Bevel of Door Stand on outside of locked door when determining door hand. Fig. 1A LHRB RHRB Left Hand Left Hand Right Hand Right Hand Hinges Left Reverse Bevel Hinges Right Reverse Bevel Open Inward... - Page 12 Installation Instructions SN200/210 FE6600 Multi-Point Lockset Prepare Lock Body (if necessary) A. Reverse Lock Hand Red surface of locking piece must face the out- side/locked side of door. To rotate locking piece (Fig. 2a): a. Position lock body with red Right Hand surface of locking piece visible.
- Page 13 Installation Instructions SN200/210 FE6600 Multi-Point Lockset Install Lock Body Note: Do not pull the lock into the pocket using the harness alone. Ensure that the wire harness is not pinched between the lock and the mortise pocket. a. Feed the wire harness into the mortise pocket and through inside preparation hole as depicted in Figure 4a.
- Page 14 Installation Instructions SN200/210 FE6600 Multi-Point Lockset Install Inside Mounting Plate Inside of NOTE: Feed mortise connectors and door harness through the Door corresponding hole on the mounting plate. a. Attach the mounting plate using two (2) #8 x 1/2” lower screws (Fig.
- Page 15 Installation Instructions SN200/210 FE6600 Multi-Point Lockset Installation of SN200/210 Reader 1. Feed reader harness through door (Fig. 7a, c) 2. Hook the top of the reader on the top of the mounting plate. 3. Align the bottom of the reader with the bottom of the mounting plate. 4.
- Page 16 Installation Instructions SN200/210 FE6600 Multi-Point Lockset Wire Connections Do not offset connectors and ensure that they are completely seated. a. Connect 6-pin connector from lock body to 6-pin connector on reader harness (Fig. 8a). b. Connect 2-pin connector from lock body to 2-pin connector on reader harness (Fig. 8a). Fig.
- Page 17 Withdraw the key about 25% out of the cylinder before inserting into the escutcheon (Fig. 10B). c. Use the key to rotate the cylinder clockwise until it is flush at the bottom and the Corbin Russwin logo is right-side up.
- Page 18 Installation Instructions SN200/210 FE6600 Multi-Point Lockset Inside Outside Lever & Inside Adapter Plate Assembly a. With outside lever horizontal, insert mounting posts through outside of door and lock body. Make certain the lever spindle is properly engaged inside the lock body (Fig 11A). b.
- Page 19 Installation Instructions SN200/210 FE6600 Multi-Point Lockset Install Inside Rose and Inside Lever Assembly a. Rotate the inside rose - first counter clockwise to seat the threads, then clockwise to securely tighten. b. Slide lever handle onto spindle until fully seated. Be sure handle is horizontal and facing the hinge side of the door.
-
Page 20: Operational Check
Installation Instructions SN200/210 FE6600 Multi-Point Lockset 7) Operational Check The ASSA ABLOY Wiegand Test Unit verifies your installation in the field*. Feature The test unit checks for: • proper wiring 12 or 24VDC solenoid lock voltage adjustable • card reader data integrity Operates as Fail Safe or Fail •... - Page 21 Installation Instructions SN200/210 FE6600 Multi-Point Lockset 7) Operational Check (Continued) For mortise locks with cylinders: a. Insert key into cylinder and rotate: There should be no friction against lock case, wire harness or any other obstructions. b. The key will retract the latch: Key should rotate freely. c.
- Page 22 Installation Instructions SN200/210 FE6600 Multi-Point Lockset Copyright © 2020-2023 ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
- Page 23 Installation Instructions SN200/210 FE6600 Multi-Point Lockset Copyright © 2020-2023 ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
- Page 24 Reproduction in whole or in part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent - www.assaabloydss.com/patents. HID, iCLASS, and Edge are trademarks or registered trademarks of HID Global Corporation. For installation assistance contact Corbin Russwin 1-800-810-WIRE (9473) • techsupport.corbinrusswin@assaabloy.com FM565 01/23...
