Corbin Russwin CL3550 Installation Instructions

Installation Instructions
Grade 1 Key-In-Lever
Cylindrical Lockset
CL3500 Series
IMPORTANT: The accuracy of the door preparation is critical for the proper functioning and security of this lever
handle lock. Misalignment can cause premature wear and a lessening of security.
A
B
FM237 (07/12)
BHMA
C E R T I F I E D
TEST OPERATION: Rotate levers to see that latchbolt moves freely.
DO NOT FORCE.
If lockset does not operate properly, remove lockset from door and check door preparation.
Copyright © 2012 Corbin Russwin Inc., an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the express written
Permission of Corbin Russwin, Inc. is prohibited.
In U.S.: In Canada:
Corbin Russwin, Inc. ASSA ABLOY Door Security Solutions Canada
225 Episcopal Road 160 Four Valley Drive
Berlin, CT 06037 USA Vaughan, Ontario, Canada L4K4T9
www.corbinrusswin.com www.assaabloy.ca
Technical Product Support: Phone: 888-607-5703
Attention Installer
Please read these instructions carefully to prevent
missing important steps.
Please note: Improper installation may result in
damage to the lock and void the factory warranty.
A

Install Latchbolt

B

Install Lockbody

C

Install Inside Trim

C
®
ASSA ABLOY
1
2
3
4
5 6
mlw - 07/25/08
1 of 4
