Sony XAV-W600BT Service Manual

XAV-W600/W650BT
SERVICE MANUAL
Ver. 1.0 2015.11
(US, CND)
FOR THE CUSTOMERS IN THE USA. NOT
APPLICABLE IN CANADA, INCLUDING IN THE
PROVINCE OF QUEBEC.
POUR LES CLIENTS AUX ÉTATS-UNIS. NON
APPLICABLE AU CANADA, Y COMPRIS LA
PROVINCE DE QUÉBEC.
AUDIO POWER SPECIFICATIONS
CEA2006 Standard
Power Output: 17 Watts RMS × 4 at 4
Ohms < 1% THD+N
SN Ratio: 80 dBA (reference: 1 Watt into
4 Ohms)
Monitor section
Display type: Wide LCD color monitor
Dimensions: 6.2 in
System: TFT active matrix
Number of pixels:
1,152,000 pixels (800 × 3 (RGB) × 480)
Color system:
PAL/NTSC/SECAM/PAL-M automatic select
Tuner section
FM
(US, CND)
Tuning range: 87.5 – 107.9 MHz
(E (NTSC))
Tuning range:
87.5 – 108.0 MHz (at 100 kHz step)
87.5 – 107.9 MHz (at 200 kHz step)
FM tuning step: 100 kHz/200 kHz switchable
(AEP, RU, UK, E (PAL), EA, IND, IND3, AUS)
Tuning range: 87.5 – 108.0 MHz
Antenna (aerial) terminal:
External antenna (aerial) connector
Intermediate frequency: 150 kHz
Usable sensitivity: 10 dBf
Selectivity: 70 dB at 400 kHz
Signal-to-noise ratio: 70 dB (mono)
Separation at 1 kHz: 30 dB
Frequency response: 20 – 15,000 Hz
9-896-214-01
Sony Video & Sound Products Inc.
2015K33-1
©
2015.11 Published by Sony Techno Create Corporation
Photo: XAV-W650BT
SPECIFICATIONS
AM
Tuning range:
530 – 1,710 kHz (US, CND, E (NTSC))
531 – 1,602 kHz
(AEP, RU, UK, E (PAL), EA, IND, IND3, AUS)
Antenna (aerial) terminal:
External antenna (aerial) connector
Intermediate frequency:
9,267.5 kHz or 9,257.5 kHz/5 kHz
(US, CND, E (NTSC))
9,267 kHz or 9,258 kHz/4.5 kHz
(AEP, RU, UK, E (PAL), EA, IND, IND3, AUS)
Sensitivity: 44 μV
DVD/CD Player section
Signal-to-noise ratio: 80 dB
Frequency response: 20 – 20,000 Hz
Wow and flutter: Below measurable limit
Harmonic distortion: 0.05%
Region code: Labeled on the bottom of the unit
USB Player section
Interface: USB (Full-speed)
Maximum current: 1 A
Wireless Communication (XAV-W650BT)
Communication System:
BLUETOOTH Standard version 3.0
Output:
BLUETOOTH Standard Power Class 2
(Max. +4 dBm)
Maximum communication range:
Line of sight approx. 10 m (33 ft)* 1
Frequency band:
2.4 GHz band (2.4000 – 2.4835 GHz)
Modulation method: FHSS
Compatible BLUETOOTH Profiles* 2 :
A2DP (Advanced Audio Distribution Profile) 1.2
AVRCP (Audio Video Remote Control Profile) 1.4
HFP (Handsfree Profile) 1.6
PBAP (Phone Book Access Profile)
OPP (Object Push Profile)
SPP (Serial Port Profile)
Corresponding codec: SBC (.sbc)
*1 The actual range will vary depending on factors such
as obstacles between devices, magnetic fields
around a microwave oven, static electricity,
reception sensitivity, antenna (aerial)'s performance,
operating system, software application, etc.
*2 BLUETOOTH standard profiles indicate the purpose
of BLUETOOTH communication between devices.
Canadian Model
Australian Model
Model Name Using Similar Mechanism
Mechanism Type
Power amplifier section
Outputs: Speaker outputs
Speaker impedance: 4 – 8 ohms
Maximum power output: 55 W × 4 (at 4 ohms)
General
Outputs:
Video output terminal (rear)
Audio output terminals (front, rear, sub)
Power antenna (aerial)/Power amplifier control
terminal (REM OUT)
Inputs:
Illumination control terminal
Steering control input terminal
Antenna (aerial) input terminal
Microphone input terminal (XAV-W650BT)
Parking brake control terminal
Reverse input terminal
Camera input terminal
AUX audio input terminal (Front)
AUX Audio/Video input terminal (Rear)
USB port
External input terminal (US, CND only)
Power requirements: 12 V DC car battery
(negative ground (earth))
Rated current consumption: 10 A
Dimensions: Approx. 178 mm × 101.5 mm × 176 mm
(7 1 / in × 4 in × 7 in) (w/h/d)
8
Mounting dimensions:
Approx. 170 mm × 100 mm × 162 mm
(6 3 / in × 4 in × 6 1 / in) (w/h/d)
4 2
Mass:
XAV-W650BT: 1.7 kg (3 lb 12 oz)
XAV-W600: 1.6 kg (3 lb 8 3 / oz)
8
Package contents:
Parts for installation and connections (1 set)
Remote Commander (1): RM-X170
(XAV-W600: E (NTSC), IND, IND3/W650BT only)
Microphone (1) (XAV-W650BT)
Design and specifications are subject to change
without notice.
US Model
AEP Model
UK Model
XAV-W650BT
E Model
XAV-W600/W650BT
Russian Model
XAV-W600
NEW
DR28N-ABB-YG
Region code
The region system is used to protect software
copyrights.
The region code is located on the bottom of the
unit, and only DVDs labeled with an identical region
code can be played on this unit.
DVDs labeled can also be played.
If you try to play any other DVD, the message
[Playback prohibited by region code.] will appear
on the monitor screen. Depending on the DVD, no
region code may be labeled even though playing
the DVD is prohibited by area restrictions.
AV CENTER
