CONSUMER: READ AND SAVE THESE IMPORTANT INSTRUCTIONS
Locating Your Serial Number:
Your serial number can be found on a blue label on the left side cover. It will begin with the letter "S"
followed by 9 digits. For Example: S160901126. Have your Serial Number ready before calling customer
service at 800-641-6996.
DANGER
THE HEATER. Be sure to comply with the instructions and warnings provided with this heater.
Failure to comply can result in fire or explosion that can cause property loss, bodily injury, or
loss of life. Only persons who can follow and understand these instructions should operate
or service this heater. Persons who are impaired or under the influence of alcohol or drugs
should not operate heater. If you need heater info; such as an operating manual, labels,
etcetera, contact Pinnacle Climate Technologies at 800-641-6996.
DANGER
NOT FOR USE WHERE EXPOSED TO THE WEATHER, AND INDOOR
USE ONLY IN WELL-VENTILATED AREAS. INDOOR USE PERMITTED
ONLY FOR: THE TEMPORARY HEATING OF ADEQUATELY VENTILATED
BUILDINGS OR STRUCTURES UNDER CONSTRUCTION, ALTERATION
OR REPAIR. This is an un-vented portable heater that uses air (Oxygen)
from within the area in which it is used. Failure to provide adequate
combustion and ventilation air will result in asphyxiation, carbon monoxide
poisoning, bodily injury or death. Refer to "Ventilation" on Page 6.
Master is a registered trademark of Pinnacle Climate Technologies, Inc.
MODEL NUMBERS:
MH-80TBOA-OFR
GENERAL HAZARD WARNING:
READ AND UNDERSTAND ALL OF THE INSTRUCTIONS IN THIS
MANUAL BEFORE ASSEMBLING, STARTING, OR SERVICING
NOT FOR USE IN RESIDENTIAL LIVING
AREAS OR IN ENCLOSED SPACES WITHOUT
ADEQUATE VENTILATION. THIS HEATER IS
Fax: 320-251-2922 • Web:
BATTERY OPERATED
KEROSENE RADIANT HEATER
User's Manual & Operating Instructions
Sauk Rapids, MN 56379 USA • Toll Free
www.masterindustrialproducts.com
© 2023 Pinnacle Climate Technologies, Inc.
Factory ID: 500
U.S. Patent No. 9,644,863
(800) 641-6996
• Email: info@pinnacleclimate.com
MARE-409
Advertisement
Table of Contents
Related Manuals for Master MH-80TBOA-OFR
Summary of Contents for Master MH-80TBOA-OFR
- Page 1 Refer to “Ventilation” on Page 6. U.S. Patent No. 9,644,863 Sauk Rapids, MN 56379 USA • Toll Free (800) 641-6996 Fax: 320-251-2922 • Web: www.masterindustrialproducts.com • Email: info@pinnacleclimate.com MARE-409 Master is a registered trademark of Pinnacle Climate Technologies, Inc. © 2023 Pinnacle Climate Technologies, Inc.
-
Page 2: Table Of Contents
NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE TABLE OF CONTENTS Safety Information ............2-3 Maintenance ..............9-10 Specifications ..............4 Wiring Diagram ..............11 Features ................4 Troubleshooting Guide ..........12 What’s in the Box ............4 Exploded View ..............13 Assembly ..............4-5 Parts List .................14 Operation ..............6-7... -
Page 3: Safety Information
Keep all combustible materials away from this heater. flu. Symptoms of improper ventilation/carbon Minimum Clearance From Combustibles monoxide poisoning are: MH-80TBOA-OFR Headache • Dizziness • Nausea • Dry Mouth 4 ft. (122 cm) Sore Throat • Burning of Nose and Eyes Sides 4 ft. -
Page 4: Specifications
NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE SPECIFICATIONS Model # MH-80TBOA-OFR Rating: BTU/Hr / kW 80,000 / 23.4 Fuel Consumption: Gal./Hr / L/Hr 0.63 / 2.38 Fuel Tank Capacity: Gal. / L 4 / 15... -
Page 5: Assembly
NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE SAFETY INFORMATION (CONT.) HEATER IS INTENDED FOR USE WITHOUT DUCTS. DO NOT WARNING CONNECT TO DUCTS. DO NOT TAMPER WITH THE UNIT. HAVE A COMPETENT SERVICEMAN MAKE ANY ADJUSTMENT OR REPAIR. -
Page 6: Operation
DO NOT USE GAS- used. OLINE OR CRANK- CASE DRAININGS. Minimum Ventilation Opening Needed MH-80TBOA-OFR - NEVER use fuel such as, benzene, alcohol, white gas, camp stove fuel, paint thinners, or 2.4 ft. other oil compounds in this heater. THESE ARE... - Page 7 DO NOT disconnect discharging. WARNING heater from power Use only Master CAUTION source before approved batteries cooling cycle has been completed. —CONTACT YOUR LOCAL SERVICE CENTER OR CALL 800-641-6996...
-
Page 8: Battery Operation Instructions
NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE BATTERY OPERATION INSTRUCTIONS Adapter Part Number ASM-00040 ASM-00040 ASM-00038 ASM-00038 ASM-00039 ASM-00071 Manufacturer DEWALT Milwaukee BLACK+DECKER Porter Cable Makita Mastercraft ® ® ® ® ® ® Model 20V Max. -
Page 9: Maintenance
NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE MAINTENANCE Long Term Storage: Never service heater WARNING while it is plugged in 1. Unscrew the fuel cap. or hot! 2. Using an approved siphon, remove the SPARK PLUG: Kerosene or diesel. - Page 10 NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE MAINTENANCE (CONT.) Service (Continued): Burner Body Diffusion Cap Blower Gasket FAN BLADES: Nozzle Assembly The fan blades should be cleaned at least once per heating season, depending on conditions. Remove all accumulated dust and dirt with a burst of condensed air (see Figure 13).
-
Page 11: Wiring Diagram
188 x 73 mm NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE Wiring Diagram / Sché WIRING DIAGRAM MH-80TBOA-OFR AC 120V (WHITE) BATTERY (WHITE) BATTERY 12V FAN (BLUE) (BLUE) PUMP VALVE IGNITION (WHITE) (WHITE) (BLUE) -
Page 12: Troubleshooting Guide
NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE TROUBLESHOOTING GUIDE Problem Possible Cause Solution 1. Dirty Fuel Filter. 1. Clean/replace Fuel Filter. 2. Nozzle Dirty. 2. Clean/replace Nozzle 3. Photocell Dirty. 3. Clean/replace Photocell . 4. -
Page 13: Exploded View
NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE EXPLODED VIEW MH-80TBOA-OFR Battery Connector © 2023 Pinnacle Climate Technologies, Inc. Kerosene Radiant Heater User’s Manual... -
Page 14: Parts List
NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE PARTS LIST: MH-80TBOA-OFR Item # Description Part Number BURNER BODY 75-036-0180 BURNER HEAD GASKET 72-035-0640 DIFFUSION CAP GASKET 01.03.75.007010043 SPARK PLUG ASSEMBLY 75-075-0200 FUEL PRESSURE GAUGE 70-028-0200... -
Page 15: Limited Warranty
NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE LIMITED WARRANTY Pinnacle Climate Technologies, Inc. warrants this product If Pinnacle Climate Technologies, Inc. finds the item to to the original retail purchaser only, to be free from defects be in normal operating condition, or not defective the item in material and workmanship for a period of one (1) year will be returned freight collect.
