  • Page 1 Network Indoor Station User Manual...
  • Page 2 WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL HIKVISION BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES,...
  • Page 3 During the use of device, personal data will be collected, stored and processed. To protect data, the development of Hikvision devices incorporates privacy by design principles. For example, for device with facial recognition features, biometrics data is stored in your device with encryption method;...
  • Page 4 Network Indoor Station User Manual Symbol Conventions The symbols that may be found in this document are defined as follows. Symbol Description Indicates a hazardous situation which, if not avoided, will or could Danger result in death or serious injury. Indicates a potentially hazardous situation which, if not avoided, could Caution result in equipment damage, data loss, performance degradation, or...
  • Page 5 Network Indoor Station User Manual Regulatory Information EU Conformity Statement This product and - if applicable - the supplied accessories too are marked with "CE" and comply therefore with the applicable harmonized European standards listed under the EMC Directive 2014/30/EU, RE Directive 2014/53/EU,the RoHS Directive 2011/65/EU 2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union.
  • Page 6 Network Indoor Station User Manual Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique à l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité...
  • Page 7 Network Indoor Station User Manual About this Manual Get the manual and related software from or the official website (http://www.hikvision.com). Product Model Network Indoor Station DS-KH6110-WE1...

  • Page 8: Table Of Contents

    Network Indoor Station User Manual Contents Chapter 1 Introduction of Touch Buttons ..................1 Chapter 2 Activation ........................3 2.1 Activate Indoor Station ......................3 2.2 Activate via iVMS-4200 Client Software ................. 4 Chapter 3 Local Configuration ..................... 6 3.1 Quick Operation ........................6 3.2 Basic Settings ........................
  • Page 9 Network Indoor Station User Manual 3.10.2 Unlink the Account ....................32 Chapter 4 Local Operation ......................34 4.1 Call Settings .......................... 34 4.1.1 Add Contact ........................ 34 4.1.2 Call Resident ....................... 35 4.1.3 Call Indoor Extension/Indoor Station ................35 4.1.4 Receive Call ......................... 36 4.1.5 View Call Logs ......................
  • Page 10 Network Indoor Station User Manual 5.9.2 Search Notice ......................65...

  • Page 11: Chapter 1 Introduction Of Touch Buttons

    Network Indoor Station User Manual Chapter 1 Introduction of Touch Buttons You can operate the device locally via touch buttons. You can answer or hang up the call on the calling page, unlock the door and view the live videos of the door station on the live view page and mute the device via touch buttons.
  • Page 12 Network Indoor Station User Manual Figure 1-2 Touch Buttons Function 2...

  • Page 13: Chapter 2 Activation

    Network Indoor Station User Manual Chapter 2 Activation 2.1 Activate Indoor Station You can configure and operate the indoor station after creating a password for the device activation. Steps 1. Power on the device. It will enter the page of language settings. Figure 2-1 Language Settings 2.

  • Page 14: Activate Via Ivms-4200 Client Software

    Network Indoor Station User Manual Figure 2-2 Activation Page 3. Create a password and confirm it. Note You can click to enable or disable password reveal. 4. Tap OK to activate the indoor station. Note We highly recommend you to create a strong password of your own choosing (using a minimum of 8 characters, including at least three kinds of following categories: upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
  • Page 15 Network Indoor Station User Manual Default IP Address: 192.0.0.64. ● Default Port No.: 8000. ● Default User Name: admin. ● Steps 1. Run the client software, enter Device Management, check the Online Device area. 2. Select an inactivated device and click the Activate. 3.

  • Page 16: Chapter 3 Local Configuration

    Network Indoor Station User Manual Chapter 3 Local Configuration 3.1 Quick Operation After device activation, the wizard page will pop up. If you activate you device via Client Software, there will not be wizard for quick operation. Steps 1. Set password reset methods and tap Next. Figure 3-1 Set reserved E-mail...
  • Page 17 Network Indoor Station User Manual Figure 3-2 Set Security Questions - Bind an email address. If you forget your admin and activation password, you can change the password via the reserved email address. - Tap Change to Security Question to select security questions and enter the answers. If you forget your admin and activation password, you can change the password via answering the questions.
  • Page 18 Network Indoor Station User Manual Figure 3-3 Network Settings - Edit Local IP, Subnet Mask and Gateway parameters manually. - Enable Auto Get IP address, the device will get network parameters automatically. 3. Configure the indoor station.
  • Page 19 Network Indoor Station User Manual Figure 3-4 Indoor Station Settings 1) Select Device Type as Indoor Station or Indoor Extension. 2) Set Room No.. 3) Configure advanced settings. Set Community No., Building No., Unit No. and Floor No. 4) Set Registration Password. 5) Tap Next.
  • Page 20 Network Indoor Station User Manual Figure 3-5 Wi-Fi Settings Note The device should support Wi-Fi. 5. Set time and tap Next.
  • Page 21 Network Indoor Station User Manual Figure 3-6 Time Settings Note The time can be synchronized to door stations. 1) Tap Date Format and Time Format to set the time format. 2) Tap Time to set time manually. 3) Tap Sync Time to select Time Zone and enable NTP function. 4) Tap to enable Synchronize Time to Door Station to synchronize indoor station time to linked door station.
  • Page 22 Network Indoor Station User Manual Figure 3-7 Call Mobile Phone 1) Enable Hik-Connect service. 2) Edit verification code or use the activation password by default. 3) View Hik-Connect Server Status. 4) Scan the first QR Code to download the APP of Hik-Connect. Scan the second QR Code to add your device to the APP.
  • Page 23 Network Indoor Station User Manual Figure 3-8 Door Station Settings Note If the door station is inactive, the system will activate the door station automatically and assign the network parameters to the door station. 2) Tap Next. 8. Optional: Enable Indoor Extension and link related indoor extension devices. Tap Finish. If the indoor extension and the indoor station are in the same LAN, the device will be displayed in the list.

  • Page 24: Basic Settings

    Network Indoor Station User Manual Figure 3-9 Indoor Extension Settings 1) Tap the indoor extension in the list to link. Note If the indoor extension is inactive, the system will activate the indoor station automatically and assign the network parameters to the indoor station. 9.

  • Page 25: Connect To Wi-Fi

    Network Indoor Station User Manual Figure 3-10 Network Information Two ways are available for you to set IP address: DHCP, and set IP address manually. 1. Tap Settings → → Configuration , and enter admin (activation) password. 2. Tap to enter the network settings page. 3.

  • Page 26: Set Linked Device Ip

    Network Indoor Station User Manual Figure 3-11 Wi-Fi Settings Select an Wi-Fi and connect. 3.2.3 Set Linked Device IP Linked network parameters refers to network parameters of devices (such as door station, doorphone, main station, center, etc.), to which the indoor station is linked. Linked devices for indoor station refer to door station, center, main station, and doorphone.
  • Page 27 Network Indoor Station User Manual Figure 3-12 Device Management Set the parameters of the linked door station. Tap to set parameters of the door station. 3. Select a device to link. Edit following parameters. Name You can edit the name of the device. Language Select a language from the drop-down list for the device.

  • Page 28: Set Local Information

    Network Indoor Station User Manual Restore to Default Settings Restore Default Settings Tap Restore Default Settings to restore parameters except network parameters and activation password to factory settings. And the system will reboot automatically. Restore All All parameters will be restored to the factory settings. The system will reboot to take effect.

  • Page 29: Sip Settings

    Network Indoor Station User Manual 2. Select Indoor Station to set the room information, live view duration, SIP parameters and password. Room Information You can set room name, room No. and in which way the room No. will be displayed. Tap Advanced Settings to set community No., building No., unit No.
  • Page 30 Network Indoor Station User Manual Steps 1. Tap Settings → → Configuration , and enter admin (activation) password. 2. Tap SIP Settings in Local Information page. Figure 3-14 SIP Settings 3. Set SIP registration password. 1) Tap Registration Password. 2) Create a new SIP registration password and confirm the password. 3) Tap OK.

  • Page 31: Add Camera

    Network Indoor Station User Manual Figure 3-15 VOIP Account Settings Note Up to 32 characters are allowed in the user name. 3.2.6 Add Camera Steps 1. Tap Settings → → Configuration , and enter admin (activation) password. 2. Tap to enter the device management page. 3.

  • Page 32: Password Settings

    Network Indoor Station User Manual Exit the page to save the settings. 3.3 Password Settings 3.3.1 Security Settings If you forgot the admin password, you can change your password via the reserved email address or the security questions. Steps 1. Tap Settings → →...

  • Page 33: General Settings

    Network Indoor Station User Manual Steps 1. Tap Settings → → Device Information to enter the Device Information page. Figure 3-16 Device Information 2. View the device version, module, and serial No. 3. Optional: Tap Open Source Disclaimer to view the OSS statement. 3.5 General Settings You can set time and date, system language and adjust the screen brightness on this page.
  • Page 34 Network Indoor Station User Manual Figure 3-17 General Settings Time and Date Set the displayed time and date format, current time. Tap Sync Time to synchronize the device time. Tap to enable Synchronize Time to Door Station to synchronize the device time to the linked door station.

  • Page 35: Preference

    Network Indoor Station User Manual 3.6 Preference You can configure shortcut settings and customizable buttons on the preference page. Tap Settings → to enter the preference page. Shortcut Settings You can enable Call Elevator, Call Management Center, Leave Message and Snapshot function, and the icons will be displayed on the home page.

  • Page 36: System Settings

    Network Indoor Station User Manual Figure 3-19 DIY Button 3.7 System Settings You can restore the device, unlink the APP, set mobile client services,etc. Tap Settings → → Configuration , and enter the admin (activation) password. to enter the system maintenance page.
  • Page 37 Network Indoor Station User Manual Figure 3-20 System Maintenance Restore Restore Default Settings Tap Restore Default Settings to restore parameters except network parameters and activation password to factory settings. And the system will reboot automatically. Restore All Tap Restore All to restore all parameters to factory settings and the system will reboot automatically.

  • Page 38: Synchronize Time

    Network Indoor Station User Manual Hik-Connect Service Settings For more details, please refer to Link to the Mobile Client . Security Settings Email Address Tap Email Address. Enter or edit the address. Security Question Tap Security Question. Select questions and enter the answers. 3.8 Synchronize Time Steps 1.

  • Page 39: Sound Settings

    Network Indoor Station User Manual Note The default unit of synchronizing interval is minute. ● The time zone can be configured as well if the NTP is not enabled. ● 3.9 Sound Settings 3.9.1 Call Settings You can set the ringtone, ring duration, call forwarding time on call settings page. Steps 1.
  • Page 40 Network Indoor Station User Manual The call will end automatically when the actual calling duration is longer than the configured one. Calling duration ranges from 30 s to 60 s. Call Forwarding Duration The ring duration limit beyond which the call is automatically forwarded to the mobile phone designated by the resident.

  • Page 41: Volume Settings

    Network Indoor Station User Manual Set the do not disturb schedule. Select Close and the do not disturb function will not be enabled. Select All Day and this device will not be disturbed all day. Select Schedule and you can set the do not disturb time duration. Within the configured time, this device will not be disturbed.

  • Page 42: Unlink The Account

    Network Indoor Station User Manual Figure 3-24 Enable Guarding Vision Service 3. Edit LBS server and Verification Code. Note Verification code is used to add the device to mobile client. 4. Optional: Scan the QR code on the screen. Note Scan the left QR code on the screen to access Hik-Connect.
  • Page 43 Network Indoor Station User Manual Figure 3-25 System Maintenance 3. Tap Unlink App Account, and follow the steps on the page.

  • Page 44: Chapter 4 Local Operation

    Network Indoor Station User Manual Chapter 4 Local Operation 4.1 Call Settings 4.1.1 Add Contact Steps 1. Tap Call → to enter the contact list page. Figure 4-1 Contact List 2. Tap to pop up the contact adding dialog. 3. Enter the contact name and the room No. 4.

  • Page 45: Call Resident

    Network Indoor Station User Manual 4.1.2 Call Resident Steps Note Only when the Call Management Center function is enabled, should the call center button be displayed. For details, see the configuration guide. 1. Tap Call → to enter the residents calling page. Figure 4-2 Call Resident 2.

  • Page 46: Receive Call

    Network Indoor Station User Manual Enter 【0-indoor extension No.】 on the indoor station to start calling. Enter 【0-0】 to call the indoor station from the indoor extension. 4.1.4 Receive Call The indoor station and indoor extension can receive calls from the analog doorphone, the door station, the main station or iVMS-4200 Client.

  • Page 47: Leave Message

    Network Indoor Station User Manual Note Indoor extension does not support this function. ● The indoor station saves call logs from analog doorphones, door stations, outer door stations, ● management center and other indoor stations. Hold a piece of call logs to open the call logs handling menu. Tap Delete to delete the piece of ●...

  • Page 48: Call Elevator

    Network Indoor Station User Manual Figure 4-4 Live View 2. Tap to enter the live view page of the door station. Note On the Call from Door Station page, there are 2 unlock buttons: Unlock 1, and Unlock 2. When ●...

  • Page 49: Information Management

    Network Indoor Station User Manual Figure 4-5 Call Elevator 2. Tap on the home page of the indoor station to start calling the elevator. 3. When the device communicates with door station, tap unlock icon to start calling the elevator. 4.5 Information Management You can view public notice, visitor message, and capture log on information management page.

  • Page 50: Chapter 5 Client Software Configuration

    Network Indoor Station User Manual Chapter 5 Client Software Configuration 5.1 Device Management Device management includes device activation, adding device, editing device, and deleting device, and so on. After running the iVMS-4200, video intercom devices should be added to the client software for remote configuration and management.
  • Page 51 Network Indoor Station User Manual Figure 5-1 Add the Device 4. Optional: Click Online Device, the active online devices in the same local subnet with the client software will be displayed on the Online Device area.

  • Page 52: Modify Network Information

    Network Indoor Station User Manual Note To add online devices to the software, you are required to change the device IP address to the same subnet with your computer first. 1) You can click Refresh Every 60s to refresh the information of the online devices. 2) Select the devices to be added from the list.

  • Page 53: System Configuration

    Network Indoor Station User Manual Note You should enter the admin password of the device in the Password field of the pop-up window to modify the parameters. 5.2 System Configuration You can configure the video intercom parameters accordingly. Steps 1. Click Maintenance and Management → System Configuration → ACS & Video Intercom to enter the system configuration page.
  • Page 54 Network Indoor Station User Manual Device Information Click Device Information to enter device basic information page. You can view basic information (the device type, and serial No.), and version information of the device. Figure 5-2 Device Information General Click General to enter device general parameters settings page. You can view and edit the device name and device ID, and select overwrite record file.
  • Page 55 Network Indoor Station User Manual Figure 5-4 Time Settings Page Select Time Zone, Enable NTP, Enable DST, or SDK Synchronization. Click Save to save the time settings. Time Zone: Select a time zone from the drop-down list menu. ● NTP: Click Enable NTP, and enter the server address, NTP port, and synchronization interval. ●...
  • Page 56 Network Indoor Station User Manual Figure 5-5 System Maintenance Reboot: Click Reboot and the system reboot dialog box pops up. Click Yes to reboot the system. ● Restore Default Settings: Click Restore Default Settings to restore the default parameters. All ●...
  • Page 57 Network Indoor Station User Manual Note The device supports 19 languages: English, French, Brazilian Portuguese, Spanish, Russian, ○ German, Italian, Polish, Arabic, Turkish, Vietnamese, Ukrainian, Hungarian, Dutch, Romanian, Czech, Bulgarian, Croatian, Serbian. Rebooting the device is required after you change the system language. ○...

  • Page 58: Video Intercom

    Network Indoor Station User Manual Security Click Security to enter the page. You can enable SSH or enable HTTPS on this page. Click Save after configuration. 5.3.2 Video Intercom Click Video Intercom on the remote configuration page to enter the video intercom parameters settings: Time Parameters, Password, Zone Configuration, IP Camera Information, Volume Input and Output Configuration, Ring, Arming Information, Calling Linkage, Relay, and SIP No.
  • Page 59 Network Indoor Station User Manual Note Calling duration is the maximum duration of indoor station when it is called without being ● received. The range of maximum ring duration varies from 30s to 60s. Live view duration is the maximum time of playing live view of the indoor station. The range of ●...
  • Page 60 Network Indoor Station User Manual Figure 5-9 Ring Import 2. Click + to add the ring, and click x to delete the imported ring. Note The ring to be imported should be in the wav format, and the size of the ring cannot be larger ●...
  • Page 61 Network Indoor Station User Manual Figure 5-11 Extension Settings 2. Click Add.
  • Page 62 Network Indoor Station User Manual Figure 5-12 Add SIP Info 3. Select Device Type as Indoor Extension.
  • Page 63 Network Indoor Station User Manual 4. Enter the required information. Serial No. Enter the device's serial No.. The serial No. is on the rear panel of the device (A fixed-length number with 9 digits). IP Address Enter the device's IP address. Gateway Enter the device's gateway.

  • Page 64: Network

    Network Indoor Station User Manual 5.3.3 Network Local Network Configuration Steps 1. Click Local Network Configuration to enter the configuring the local network parameters page. Figure 5-13 Local Network Configuration 2. Enter the Local IP Address, IP Address Subnet Mask, Gateway, Port No. and HTTP Port No. 3.
  • Page 65 Network Indoor Station User Manual Figure 5-14 SIP Server Configuration 2. Click Enable. 3. Set the parameters according to your needs. Note Up to 32 characters are allowed in the Register User Name field. ● Registration password should be 1 to 16 characters in length. ●...
  • Page 66 Network Indoor Station User Manual Figure 5-15 DNS Settings Configure Mobile Client Connection Configure Hik-Connect server parameters before viewing videos via mobile client. Before You Start Make sure the indoor station connects to the network. Steps 1. Click Hik-Connect to enter the configuring the settings page. 2.

  • Page 67: Call Indoor Station Via Client Software

    Network Indoor Station User Manual Note Device type can be set as indoor station or indoor extension. ● When you select indoor extension as device type, the device No. can be set from 1 to 5. ● Click Save to enable the settings. Linked Device Network Settings Enter Registration Password and set the corresponding information.

  • Page 68: Receive Call From Indoor Station/Door Station

    Network Indoor Station User Manual Note One indoor station can only connect with one client software. ● You can set the maximum ring duration ranging from 15s to 60s, and the maximum speaking ● duration ranging from 120s to 600s via the Remote Configuration of indoor station. 5.5 Receive Call from Indoor Station/Door Station Steps 1.

  • Page 69: View Live Video Of Door Station And Outer Door Station

    Network Indoor Station User Manual The maximum speaking duration between indoor station and client can be set from 120s to ● 600s via the Remote Configuration of indoor station. The maximum speaking duration between door station and client can be set from 90s to 120s ●...

  • Page 70: Release Notice

    Network Indoor Station User Manual Figure 5-18 Call Log 3. Optional: Click the icon in the Operation column to re-dial the resident. 5.8 Release Notice You can create different types of notices and send them to the residents. Four notice types are available, including Advertising, Property, Alarm and Notice Information.
  • Page 71 Network Indoor Station User Manual Figure 5-19 Release Notice 3. Click Add on the left panel to create a new notice.
  • Page 72 Network Indoor Station User Manual Figure 5-20 Create a Notice 4. Edit the notice on the right panel. 1) Click ... on the Send To field to pop up the Select Resident dialog. 2) Check the checkbox(es) to select the resident(s). Or you can check the All checkbox to select all the added residents.

  • Page 73: Search Video Intercom Information

    Network Indoor Station User Manual 5) Click in the Type field to unfold the drop-down list and select the notice type. 6) Optional: Click View to add a local picture to the notice. Note Up to 6 pictures in the JPGE format can be added to one notice. And the maximum size of one picture is 512KB.
  • Page 74 Network Indoor Station User Manual Figure 5-21 Search Call Logs 3. Set the search conditions, including call status, device type, start time and end time. Call Status Click to unfold the drop-down list and select the call status as Dialed, Received or Missed. Or select All to search logs with all statuses.
  • Page 75 Network Indoor Station User Manual 5.9.2 Search Notice Steps 1. On the main page, click Access Control → Video Intercom to enter the Video Intercom page. 2. Click Notice to enter the Notice page. Figure 5-22 Search Notice 3. Set the search conditions, including notice type, subject, recipient, start time and end time. Recipient Input the recipient information in the Recipient field to search the specified notice.
  • Page 76 Network Indoor Station User Manual 6. You can view and edit the notice details, check the sending failed/sent succeeded/unread users, and resend the notice to sending failed/unread users. 7. Optional: Click Export to export the notices to your PC.
  • Page 77 UD34110B...
