AP-3064 Wi-Fi 6 AX3600 Dual-Band 4x4 Indoor Access Point
Quick Installation Guide
What's included
AP-3064 Wi-Fi 6 AX3600 dual-band 4x4 indoor access point
n
Mounting bracket
n
Hardware for drywall installation
n
n
T-rail mounting kit for suspended tile ceiling installation
Physical features
Status LED (front) – Shows whether the access point has power, and whether it is in
n
its normal operating state.
n
LAN PoE+ port (back) – Connect to the power and data out port of a PoE+ power
injector, or to a powered port on a PoE+ switch.
Reset button (back) – Press momentarily with a small object to reboot the device, or
n
press and hold for several seconds to restore factory default settings.
n
Information label (back) – Includes default DHCP failover IP address, administrative
password, and Wi-Fi passphrase.
Document 411-3101-01 Rev B January 2024
Advertisement
Table of Contents
Related Manuals for LEGRAND LUXUL AP-3064
Summary of Contents for LEGRAND LUXUL AP-3064
- Page 1 AP-3064 Wi-Fi 6 AX3600 Dual-Band 4x4 Indoor Access Point Quick Installation Guide What's included AP-3064 Wi-Fi 6 AX3600 dual-band 4x4 indoor access point Mounting bracket Hardware for drywall installation T-rail mounting kit for suspended tile ceiling installation Physical features Status LED (front) – Shows whether the access point has power, and whether it is in its normal operating state.
- Page 2 AP-3064Wi-Fi 6 AX3600 Dual-Band 4x4 Indoor Access Point Quick Installation Guide Placement Decide where to mount your access point(s). You may need to experiment to determine optimal placement; if so, connect the access point for service. Selecting a location The access point 's signal is omnidirectional. If you use only one access point, place it as close as possible to the center of the desired coverage area.
- Page 3 AP-3064Wi-Fi 6 AX3600 Dual-Band 4x4 Indoor Access Point Quick Installation Guide If mounting the access point to a suspended tile ceiling: Note All above-ceiling work must conform to local building codes and should be performed by qualified personnel. 1. Route the network cable. 2.
- Page 4 AP-3064Wi-Fi 6 AX3600 Dual-Band 4x4 Indoor Access Point Quick Installation Guide Configuring the access point You will need to do these things before you can use the access point: Open the admin interface Configure the device's SSID and preshared key Optional: Assign a new hostname Check for firmware updates Discovering the device's IP address...
- Page 5 AP-3064Wi-Fi 6 AX3600 Dual-Band 4x4 Indoor Access Point Quick Installation Guide Configuring wireless settings The admin interface lets you configure a 2.4 GHz network and a 5 GHz network on the Quick Setup page. You may want to do this if you want to keep your smart home devices on their own network, or if you want to set up a guest network that's separate from your main network.
- Page 6 AP-3064Wi-Fi 6 AX3600 Dual-Band 4x4 Indoor Access Point Quick Installation Guide Updating firmware 1. In the admin interface, go to Advanced > Update Firmware. 2. Select the firmware location. Normally, Auto is preferred, as it compares the device's current firmware with the latest version available in the specified repository. If necessary, download the firmware to your computer from legrandav.com/resources/firmware-updates/luxul-firmware and select "a file on your...
- Page 7 ...Discover the device's serial number and MAC address? Scan the QR code on the label..Respond appropriately to a volcano erupting? Run. And contact us afterward if you need new network equipment. Learn more about Luxul products at Legrand AV University!
- Page 8 · Phone +1 801 822 5450 · Email av.luxul.techsupport@legrand.com Luxul and the Luxul logo are registered trademarks of Legrand AV Inc. All other brand names or marks are used for identification purposes and are trademarks of their respective owners. All patents are protected under existing designations.
