EDIFIER WH700NB Manual

W H 700 NB
Wirele s s N o is e Ca n ce lla ti o n Over -Ea r He adpho ne s
EN 1. Power ON/OFF
1. Power ON: press and hold the "
the green LED blinks.
2. Power OFF: press and hold the "
the red LED blinks.
Note:
1. lf there is no Bluetooth connection when the headphones are powered on but
not in noise cancellation mode, the headphones are will power off automatically
in 5 minutes.
2. lf there is no Bluetooth connection when the headphones are powered on and
in noise cancellation mode, the headphones will power off automatically in 4
hours.

2. Pairing

Pairing for the first time
1. Press and hold the "
LEDs will blink alternately.
2. Select "EDIFIER WH700NB" in Bluetooth device setting to connect. Green LED
will blink twice in 5 seconds when successfully.
Pairing for new device
1. Press and hold the "
connected device and pair with the new Bluetooth device. Red and green LEDs
will blink alternately.
2. Select "EDIFIER WH700NB" in Bluetooth device setting to connect. Green LED
will blink twice in 5 seconds when successfully.
Note:
For subsequent use, the headphones will automatically connect to the device
used last time.

3. Reset

Press and hold the "
powered on. Wait for the green LED blinks 6 times to clear the Bluetooth pairing
records and re-enter Bluetooth pairing mode. The red and green LED will then
blink alternately.

4. Dual-device connection

1. Pair Bluetooth device A with the headphones. Upon the pairing is successful,
keep the headphones powered on, then press and hold the "
3s to re-enter the Bluetooth pairing mode, red and green LED will blink
alternately, meanwhile, device A is disconnected from the headphones.
2. Select "EDIFIER WH700NB" in Bluetooth device B's setting to connect
successfully.
3. Select "EDIFIER WH700NB" in Bluetooth device A's setting to connect manually.
Note:
1. When a call comes, the headphones will automatically switch to the calling
device. After the call ends, the headphones can switch back to the original
device.
2. Voice assistant can be enabled on the latest active smartphone if two
smartphones are paired with the headphones simultaneously.
3. Switching from device to device: pause music on the current device, and start
playing audio on the second device you would like to switch to.
4. Each time when powered on, the headphones will automatically reconnect
with the two most recently-connected devices if available within the effective
Bluetooth range.

5. Charging

1. Please connect the headphones to power source with the included Type-C
charging cable for charging.
2. Red LED is steady lit when charging and off when fully charged.
Note:
Please do not charge the headphones when there is sweat or other liquids inside
the charging port, which may damage the headphones.
Input: 5V 1A

6. Controls

Note:
1. : Press and hold.
2. Default sound control: noise cancellation & ambient sound & noise cancellation
off.
3. Images are for illustrative purposes only and may differ from the actual product.
4. Download Edifier Connect App for more customizable control settings.
For more information, please visit our website:
@Edifierglobal
Model: EDF200126
Edifier International Limited
P.O. Box 6264
General Post Office
Hong Kong
www.edifier.com
2023 Edifier International Limited. All rights reserved.
Printed in China
NOTICE:
For the need of technical improvement and system upgrade, information
contained herein may be subject to change from time to time without prior
notice.
Products of EDIFIER will be customized for different applications. Pictures and
illustrations shown on this manual may be slightly different from actual product.
If any difference is found, the actual product prevails.
Manual
" key for about 3s when powered OFF until
" key for about 3s when powered ON until
" key for about 3s when powered off. Red and green
" key for about 3s when powered on to skip the latest
" and " " keys simultaneously for about 5s when
www.edifier.com
@Edifier_Global
3s
Indicator
3s
Indicator
5s
Indicator
Indicator
x1
3s
x1
x1
x1
x1
x1
x1
3s x2
@Edifier_Global
" key for about
x2
x2
x1
