Wireless Noise Cancelling Over-Ear Headphones
EN 1. Power ON/OFF
Press and hold the power button to power on/off.
2. First pairing
1. Once powered on, the headphones will automatically enter
Bluetooth pairing mode.
2. Select "EDIFIER W80" from your device list to connect.
3. Pairing for new device
1. In ON state, press and hold the "
enter Bluetooth pairing mode.
2. Select "EDIFIER W80" from your device list to connect.
Note: For subsequent use, the headphones will automatically connect to the device used last time.
4. Controls
Call
Music
Mode
Note:
1. "x 1" Press, "x 2" Double press, "—" Press and hold.
2. Default sound control: High Noise Cancellation / Ambient Sound / Noise Cancellation off.
3. Default sound mode: Music Mode/ Game Mode/ Spatial Sound.
4. Download EDIFIER ConneX App to customize more control settings.
5. Multipoint connection
Bluetooth
EDIFIER W80
1. Pair device A with the headphones successfully.
2. Press and hold the "
pairing mode, and then select "EDIFIER W80" in device B settings
to connect.
3. Select "EDIFIER W80" again in device A settings to complete the
multipoint connection.
Note: For subsequent use, the headphones will automatically reconnect to the two devices used
last time.
6. Wired listening
Connect the AUX audio cable to the headphones.
The wired connection will automatically disable Bluetooth mode.
7. Reset
1. In ON state, press the "+" and "-" buttons for 5 seconds, LED will
blink white until the reset is complete.
2. Then the headphones will automatically enter Bluetooth pairing mode.
8. Charging
Connect the headphones to a power source via the USB-C cable for
charging.
Note: Make sure the USB-C port is completely dry before charging.
W80
Model: EDF200206
Manual
x1
x1
x2
x1
x1
x2
x1
x1
x2
A
" button for 3 seconds to re-enter Bluetooth
1s
ON
-
OFF
-
1s
Bluetooth
EDIFIER W80
Bluetooth
EDIFIER W80
" button for about 3 seconds to
Bluetooth
EDIFIER W80
A
B
5s
Input: 5V
1A
