EDIFIER W220T - True Wireless Earbuds Headphones Manual

Power ON/OFF

1. Power ON when the case is opened.
2. Power OFF when placed in the case and the case is closed.

Note:
If there is no Bluetooth connection for 10 minutes after power on, the earbuds will turn off automatically.

Pairing

1. Earbuds placed in the case and keep the case open.
2. Press and hold the button on the case for about 3s. White and green LEDs will blink alternately.
3. Select "EDIFIER W220T" in your device setting to connect. White LED will blink once and then turn off when successfully.

1st Pairing

1. Earbuds placed in the case and keep the case open. White and green LEDs will blink alternately.
2. Select "EDIFIER W220T" in your device setting to connect. White LED will blink once and then turn off when successfull.

Note:
For subsequent use, the earbuds will automatically connect to the device used last time.

Reset

1. Earbuds placed in the case and keep the case open.
2. Press the button on the case 3 times to re-enter left & right connection and clear pairing records, white LED will blink slowly.
3. Select "EDIFIER W220T" in your device setting to connect. White and green LEDs will blink alternately, then white LED will blink once and turn off when successfully.

Charging case

1. Please connect the case to power source with the included Type-C charging cable for charging.
2. Orange LED is steady lit when charging and off when fully charged.

Note:
Please do not charge the earbuds when there is sweat or other liquids inside the charging port, which may damage the earbuds.


Input: 5V200mA(Earbuds)
5V 1A(Charging case)

Controls

1. Easily pinch the debossed area of earbuds stem to select functions.
2. Images are for illustrative purposes only and may differ from the actual product.
3. Download Edifier Connect App for more customizable control settings.

For more information, please visit our website:
www.edifier.com


@Edifierglobal

@Edifier_Global

@Edifier_Global

Model: EDF200042
Edifier International Limited
P.O. Box 6264
General Post Office
Hong Kong
www.edifier.com
© 2021 Edifier International Limited. All rights reserved. Printed in China

NOTICE:
For the need of technical improvement and system upgrade, information contained herein may be subject to change from time to time without prior notice.
Products of EDIFIER will be customized for different applications. Pictures and illustrations shown on this manual may be slightly different from actual product. If any difference is found, the actual product prevails.
