EDIFIER WH700NB Pro (EDF200168) Manual

Power ON/OFF

Press and hold the power button to power on/off.

First pairing

1. Once powered on, the headphones will automatically enter Bluetooth pairing mode.
2. Select "EDIFIER WH700NB Pro" in your device settings to connect.

Pairing for new device

1. In ON state, press and hold the "" button for about 3 seconds to enter Bluetooth pairing mode.
2. Select "EDIFIER WH700NB Pro" in your device settings to connect.

Note: For subsequent use, the headphones will automatically connect to the device used last time.

Multipoint connection

1. Pair device A with the headphones successfully.

2. Press and hold the "" button for 3 seconds to re-enter Bluetooth pairing mode, and then select "EDIFIER WH700NB Pro" in device B settings to connect.

3. Select "EDIFIER WH700NB Pro" again in device A settings to connect.


Note: For subsequent use, the headphones will automatically reconnect to the two devices used last time.

Controls

• Call

• Music

• Mode


Note:

1. "x 1" Press, "x 2" Double press, "—" Press and hold;
2. Default sound control: High Noise Cancelation/Ambient Sound/Noise Cancelation Off.
3. Download EDIFIER ConneX App for more customizable control settings.

Reset

In ON state, press "+" and ''-'' buttons for 5s to finish reset, then headphones will automatically enter Bluetooth pairing mode if successful.

Charging

Connect the headphones to a power source via the USB-C cable for charging.

Input: 5V ⎓ 1A
Note:

1. Make sure the USB-C port is completely dry before charging.
2. When charging with a USB-C cable, the product is used as wired headphones and Bluetooth functions are unavailable.

Wired listening

Connect to the headphones via the USB-C cable. Wired listening will automatically disable Bluetooth mode.
