Abilize Ranger Instruction Booklet page 19

Malfunction Messages
1. Operation Feature - Take the connector pin (KEY) of controller as determinant signal, then
converts it into digital codes.
2. Usage Condition -
Key On Display
1. Initial Status - When scooter power is on, the back light and all LCD segments will be tuned
on for 3 seconds, then switch to the default working mode automatically.
Battery needs charging soon.
Low voltage, needs charging now
Over voltage
Over current
Park Brake is lost or faulty
Accelerator Others
Accelerator is broken or faulty
Motor is broken or faulty
Others
19
