Abilize Ranger Instruction Booklet page 15

5. Quit Setup Mode - The user could quit the setup mode with the following conditions.
(1) Leave or
stored and return to normal clock mode.
Thermometer:
1. Operation Feature - Use thermistor (NTC) to detect the signal and transfers to related
temperature.
2. Display Errors - + 2ºC
3. Operational Mode of Thermometer -
thermometer mode. Display range:
Centigrade -20 - 50ºC or Fahrenheit -4 - 122ºF.
4. Setup Mode (Unit Change) - Press
º
5. Quit Setup Mode - The user could quit the setup mode with the following conditions.
(1) Leave or
stored and return to normal thermometer mode.
Speedometer:
1. Operation Feature - Use optical coupler to detect the signal and transfer to related speed.
2. Display Errors - +15~20%.
3. Display Range / Operational Mode of Speedometer -
0.0 ~ 30.0, display resolution: 0.5
When "km/h" is displayed, speed will be indicated in km per hour. When "MPH" is displayed,
speed will be indicated in miles per hour. When "/h" is displayed, the function of speedometer
will be disable. (This display will be applied to the model that is not equipped with optical
coupler) And the display will be replaced to WIP (accelerator) operation indicator as follows:
Standby Indication
buttons alone for 15 seconds.
+
buttons alone for 15 seconds.
Forward Indication
together for 3 seconds to enter setup mode. While
º
Backward Indication
15
