Viking C-200 Technical Practice page 4

B. Wiring the E-35 Phone Board
Optional C-2000A Advanced Door
Entry Controller (not included)
Fax Back Number 156
VIKING
MODEL C-2000A
©
VIKING
ELECTRONICS
HUDSON, WI 54016
ADVANCED DOOR/GATE AND
ENTRY PHONE CONTROLLER
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30
* Note: When installing a line powered phone on a low voltage and/or low loop
current phone system extension, a TBB-1 Talk Battery Booster may be required.
** Note: The gel-filled (water-tight) butt connectors are designed for insulation displacement on 19-26 gauge wire with a maximum insulation of 0.082
inches. Cut off bare wire ends prior to terminating.
*** Note: To increase surge protection, loosen the PCB mounting screw labeled
from the mounting screw to Earth Ground (grounding rod, water pipe, etc.)
C. Wiring the E-35 Camera
1. Using RG59 for Video and CAT5 for Camera Power and Phone Board Audio (Recommended)
Back View of the E-35
ON
1 2
IMPORTANT: Electronic devices are susceptible to lightning and power station electrical surges from both the AC outlet
!
and the telephone line. It is recommended that a surge protector be installed to protect against such surges. Contact
Panamax at (800) 472-5555 or Electronic Specialists Inc. at (800) 225-4876.
4
Optional C-200 Basic Single Entry
Phone Interface (not included)
Fax Back Number 169
VIKING
MODEL C-200
©
VIKING
ELECTRONICS
HUDSON, WI 54016
* C.O. Line
SINGLE ENTRY PHONE
CONTROLLER
or Analog
PABX/KSU
1 2 3 4 5 6 7 8 9 10 11 12
ON
1 2 3
EARTH C.O. LINE OUT TO ENTRY N.O. COM N.C. AUX POWER
GND INPUT PHONES PHONE AUX CONTACTS OUTPUT
or
3-Wire Gel-Filled Butt Connectors
included (3M Scotchlok UR2)
Center conductor
stripped back 5/8"
Yellow (Video)
Twisted foil and
braided shield
** Camera GND (-)
- Black (GND)
+ Red (6VDC) ** Camera Pwr (+)
Phone Board Audio In/Out (Tip)
Phone Board Audio In/Out (Ring)
Rear View of
the E-35
Station
** Gel-Filled
Butt Connectors
Red (Ring)
or
Green (Tip)
Need More Information on the TBB-1?
?
Call (715) 386-4345 and select 630.
(as shown above) and fasten a wire with spade terminal (included)
*** RG59 or RG6
Shielded
Video Cable
Up to 1000 ft
CAT5 Cable
W/O
O/W
** Up to 500 ft
W/BL
BL/W
5.0"
3.63"
ON
1 2
"F" to Phono Plug
"F"
Adapter
(Radio
To unused input on TV,
Connector
Shack part #278-252)
VHF modulator, whole
house video distribution
equipment, etc.
6V DC Adapter
(included)
Black
Camera GND (-)
W/O
O/W
Camera Power (+)
Crimp-on Splice
Connectors (not included)
BL/W W/BL
See page 4, section E
Wiring Phone Board
5.0"
Ring
3.63"
Terminal
(included)
*** Earth
Ground
(optional)
!
120V AC
(-)
( + )
Black with
White Stripe
