Simplified Schematic; Basic Installation - Viking C-200 Technical Practice

F e a t u r e s O
F e a t u r e s O
Power Input
(13.8VAC @1.25A
adapter included)
DIP Switches
In-Use LED
* Optional
Earth Ground
C.O. / Phone Line Input
Line Out to Telephones
* Note: To increase surge protection, fasten a wire from the screw terminal to Earth Ground (grounding rod, water pipe, etc.)
I n s t a l l a t i o
I n s t a l l a t i o
IMPORTANT: Electronic devices are susceptible to lightning and power station electrical surges from both the AC outlet and the telephone line.
!
It is recommended that a surge protector be installed to protect against such surges. Contact Panamax at (800) 472-5555 or Electronic
Specialists Inc. at (800) 225-4876.
A. Basic Installation
120V AC
13.8V AC
Adapter
included
* Earth Ground
(optional)
Analog Trunk
Line Input of a
Phone System
v e r v i e w
v e r v i e w
VIKING
©
VIKING
ELECTRONICS
HUDSON, WI 54016
SINGLE ENTRY PHONE
CONTROLLER
1 2 3 4 5
ON
1 2 3
EARTH C.O. LINE
GND INPUT
n
n
VIKING
©
ELECTRONICS
HUDSON, WI 54016
SINGLE ENTRY PHONE
CONTROLLER
1 2 3 4 5
ON
1 2 3
EARTH
GND
C.O. / Phone
Line Input
or
Dedicated
Analog Phone(s)
MODEL C-200
6 7 8 9 10 11 12
OUT TO ENTRY N.O. COM N.C. AUX POWER
PHONES PHONE AUX CONTACTS OUTPUT
GND
+12VDC
N.C.
COM
N.O.
To Entry Door Phone
MODEL C-200
VIKING
6 7 8 9 10 11 12
C.O. LINE OUT TO ENTRY N.O. COM N.C. AUX POWER
INPUT PHONES PHONE AUX CONTACTS OUTPUT
N.O. contacts to doorbell
switch, camera control, etc.
Entry Door Phone
(not included)
or
E-40-PB E-50-SS
Note: All of these phones are equipped with an auto answer feature.

Simplified Schematic

Phone System
C.O.
Line
Line
Circuit
Entry Door Phone
Auxiliary
Power Output
Auxiliary
Relay Contacts
* Note: To increase surge protection, fasten
a wire from the screw terminal to Earth
Ground (grounding rod, water pipe, etc.)
or or or
E-10 E-20A
Phones or
or
E-30 E-35
3
