TECHNICAL
TECHNICAL
E-1600-60A
announcement to identify the location of the emergency call. Alternatively, a DTMF Touch Tone code may also be delivered. A
"Call Connected" LED can be initiated manually or automatically. All programming parameters, including phone numbers and
location numbers, are stored in non-volatile E
and are compatible with common Central Station Monitoring equipment.
For outdoor or harsh environments, select 1600A Series phones are available with Enhanced Weather Protection (EWP). EWP
products feature rubber gaskets and boots, hand soldered silicon sealed connections, gel-filled butt connectors, as well as ure-
thane potted circuit boards with weather sealed, field-adjustable trim pots and DIP switches for easy on-site programming.
• Meets ADA requirements for Emergency Phones:
- Can automatically light the "Call Connected" LED for the
hearing impaired
- Transmits a unique location I.D. code or voice announcement
- Grade 2 Braille label for the visually impaired
• Non-volatile digital voice announcer with 16 seconds of voice
memory
• Advanced call progress detection
• Handsfree operation
• Phone line powered
• Non-volatile memory (no batteries required)
• Touch Tone or pulse dialing
• Dials up to 5 emergency numbers
• E-1600-20A and E-1600-52A dial up to 3 non-emergency "INFO"
numbers
• Cycles through backup emergency and non-emergency numbers
on busy or no-answer
• Optional Enhanced
Weather Protection (EWP)
• Hangs up on CPC, silence, busy signal, dial tone, time-out or Touch
Tone command
• Programmable to auto-answer on incoming calls
• Remotely programmable
• Extended temperature range (-15°F to 130°F)
• 9 different chassis or board only available
• Available in a 42" tall tower phone model E-1600A-BLT-EWP
• Central Station Monitoring capability (dials 2 numbers)
• Separate central station voice speed dial number
• Optional PB-100 Polling System available
• Optional BLK-3-EWP strobe light kit available
E-1600-02A
K-1600-EHFA
E-1600A
E-1600-45A
?
Call (715) 386-4345 and select 859.
P
r
a
c
P
r
a
c
The 1600A Series ADA Compliant Emergency Phones are
designed to provide quick and reliable handsfree communi-
cation for any standard analog telephone line or analog
E-1600-03B
E-1600-30A
E-1600-55A
E-1600-20A
2
memory. All units are phone line powered, requiring no batteries or external power
• Elevators
• Parking ramps/lots
• ATM machines
• Area of refuge locations
• Lobbies
• Entryways
• Campus emergency stations
• Roadside emergency stations
• Stadiums
• Convention centers
* Americans with Disabilities Act of 1992 contains federal reg-
ulations regarding elevator telephones (Public Law 101-336).
Power: Telephone line powered. Minimum 24V DC talk battery voltage,
with a minimum loop current of 20mA loop. Loop current may be boosted
on low current lines with a Viking Model TBB-1A talk battery booster (Fax
Back # 630).
Dimensions: See Installation and Specifications
Operating Temperature: -26° C to 54° C (-15° F to 130° F)
Humidity - Standard Products: 5% to 95% non-condensing
Humidity - EWP Products: Up to 100%
Some phone systems do not conform to analog telecom standards and might
not be compatible with the 1600A Series emergency phones. For a detailed
description of the telephone line specifications required for any of the 1600A
Series phones, retrieve Fax Back Document 869.
1600A Series
1600A Series
t
i
c
e
t
i
c
e
January 5, 2009
phone system station port.
phones meet ADA requirements for elevator/ emer-
gency telephones, and can be programmed from
any Touch Tone phone. The phones can dial up to 5
programmable emergency numbers, as
well as 2 central station numbers. In addi-
tion, the E-1600-20A and E-1600-52A
feature a second "INFO" button that will
dial up to 3 non-emergency numbers.
The 1600A Series phones can be pro-
grammed to automatically deliver a digital
All 1600A Series

Advertisement

Table of Contents

   Related Manuals for Viking BLK-3-EWP

   Summary of Contents for Viking BLK-3-EWP

  • Page 1 Power: Telephone line powered. Minimum 24V DC talk battery voltage, with a minimum loop current of 20mA loop. Loop current may be boosted on low current lines with a Viking Model TBB-1A talk battery booster (Fax Back # 630). Dimensions: See Installation and Specifications Operating Temperature: -26°...
  • Page 2 For more information on the When wires are routed from above, a “drip loop” is recommended to keep water away from the circuit board. Viking Electronics, Inc., 1531 Industrial Street, Hudson, WI 54016 (715) 386-8666 Rear View of a...
  • Page 3 CONNECTED Red Call PUSH FOR Connected LED HELP Push to Call Button VIKING © Grade 2 (Front View) Braille Label Dimensions: 330mm x 267mm x 51mm (13” x 10.5” x 2”) Shipping Weight: 3.18 kg (7 lbs.) Connections: 2-position terminal block Material: .125”...
  • Page 4 Mounting with Plastic Rough-In Box (included): Flush into walls, mounts to side of wall stud Mounting with Optional VE-5x5: Surface mount to walls, single gang boxes, dou- ble gang boxes, posts, or to a Viking VE-GNP Gooseneck pedestal (see options below). 2.1”...
  • Page 5 For greater weather resistance, apply a bead of clear silicon caulking around the top edge and sides of the chassis Front View 5.36 EMERGENCY PHONE PUSH FOR Grade 2 HELP Braille Label VIKING © CALL CONNECTED Call Connected LED Push To Call Button VIKING MODEL E-1600-03B ©...
  • Page 6 The E-1600-55A is a universal emergency phone kit for installing behind elevator panels, or an installation requiring a custom panel. The finished panel should provide: (4) studs (#6 diameter minimum) for mounting plate, audio holes for speaker and microphone, a momentary SPST push button switch and a 0.25”...
  • Page 7 C. Quick Programming Features First emergency speed dial number ... Second emergency speed dial number ... Third emergency speed dial number ... Fourth emergency speed dial number ... Fifth emergency speed dial number ... Central station receiver number ... Central station voice number ... First “Info”...
  • Page 8 F. Timing/Dialing Options (memory location #18) There are six positions in the timing/dialing options. To program these options, enter the six desired timing/dialing num- bers followed by #18. The six available timing/dialing options are defined as follows: Dial: A + B + C + D + E + F + # + 1 + 8 Factory Default Setting: 2 + 3 + 4 + 1 + 1 + 1 Talk/Listen Delay Call Length...
  • Page 9 G. Voice Announcer/Miscellaneous Options The 1600A series phones have a built-in non-volatile digital voice announcer that may be used to identify the location of the emer- gency phone call. The 16 seconds of digital record time is recorded remotely from a Touch Tone phone. Programming options are as follows: Factory Default Setting: 0 + 0 + 0 + 2 + 1 + 0 Two Digit Announcement Delay {...
  • Page 10 I. Automating the Call Connected LED There are two methods of turning on the Call Connected LED. The LED will turn on after a Touch Tone , is detected from the distant party or after the voice announcer is finished playing a programmed number of times. If you want the Call Connected LED to light automatically when the call has been answered, but you don’t want a voice announcement to be played, follow these programming steps: Step 1:...
  • Page 11 d. Speed Dial Numbers The 1600A Series phone can be programmed to dial a central station receiver only, or dial up to 5 voice numbers first, and if no answer, then dial the central station receiver. When calling the first numbers (memory positions #00-#04 (see Programming section D), the phone stays in “two-way talk mode”...
  • Page 12 Due to the dynamic nature of the product design, the information contained in this document is subject to change without notice. Viking Electronics, and its affiliates and/or subsidiaries assume no responsibility for errors and omissions contained in this information. Revisions of this document or new editions of it may be issued to incorporate such changes.
