Summary of Contents for HY-CLOR GLIDE
- Page 1 GLIDE POOL CLEANER INSTALLATION & OPERATION MANUAL HY-CLOR AUSTRALIA PTY LIMITED ABN: 81 000 655 381 178 Power Street Glendenning NSW 2761 Australia All enquiries AU: 1800 625 123 NZ: (09) 973 2477 or help@hyclor.com.au Visit us at hyclor.com.au...
- Page 2 PRODUCT HELPLINE help@hyclor.com.au AU: 1800 625 123 www.hyclor.com.au NZ: (09) 973 2477...
- Page 3 Glide Pool Cleaner Installation and Operation Manual SAFETY & WARNINGS ....................4 PRIOR TO INSTALLATION ..................... 5 PARTS LIST ........................6 INSTALLATION ......................7 CLEANER CARE ......................13 TROUBLESHOOTING ....................15 WARRANTY ........................17 PRODUCT HELPLINE help@hyclor.com.au AU: 1800 625 123 www.hyclor.com.au...
- Page 4 Unlike other cleaners, the Glide cleaner has an encased drive train to reduce the risk of the engine jamming on debris. Your Glide cleaner will do an excellent job of cleaning your entire pool.
- Page 5 PREPARING YOUR POOL Before installing your Glide Pool Cleaner, you need to prepare your pool as the Glide pool cleaner will not 1. Vacuum your pool using a manual vacuum cleaner. Your pool should be free of heavy debris & algae time.
- Page 6 3.0 INSTALLING YOUR GLIDE POOL CLEANER Your Glide Pool Cleaner is comes assembled, making installation quick and simple. STEP 1: CHECK CONTENTS Remove the cleaner body and all accessories from the box and check the contents. Refer to Figure 1.
- Page 7 Figure 2. FEMALE HOSE END MALE HOSE END Figure 2. 2. Connect the female cuff of the leader (shorter, softer) hose to Glide’s articulating swivel (on the top of the cleaner). See Figure 3. Figure 3. LEADER HOSE PRODUCT HELPLINE help@hyclor.com.au...
- Page 8 3. Add the 2 Hose Floats to the cleaner: • 1st Hose Float – About 30cm from Articulating Swivel (at top of Leader Hose). • 2nd Hose Float – About 50cm from the cleaner or 22cm from the first float. Figure 4.
- Page 9 Hose Adaptor attached to provide optimum fit with the hose. The Flow Control Valve will automatically regulate the flow to your Glide Cleaner. If the flow from the pump is too high, the spring loaded flap will open to bypass the excess, so only the correct amount of flow goes through the cleaner.* 4.
- Page 10 Your Glide Cleaner comes with standard setting, once you have it in the pool you need to adjust the wheel Revolutions Per Minute (RPM). The optimal RPM for your Glide Cleaner should be between 11 and 14.
- Page 11 Note: Due to the harsh conditions in which your cleaner operates, its color may fade or dull over time. High Chlorine levels also cause wear and tear on the GLIDE pool cleaner and will break down the tires. Ideal Chlorine levels are around between 2-3ppm and a PH of 7.4 PRODUCT HELPLINE help@hyclor.com.au...
- Page 12 Figure 8. When the control valve flow is adjusted to the surface area marked by the flowmeter When the control valve flow is adjusted to the wall area marked by the flowmeter PRODUCT HELPLINE help@hyclor.com.au AU: 1800 625 123 www.hyclor.com.au NZ: (09) 973 2477...
- Page 13 2. If you try to rotate the wheels and they don’t move, check if anything is clogged inside the cleaner. To open: a. Place Glide on a flat surface and gently loosen the buttons on the front and back sides of the cleaner to free the cover as shown in Figure 10.
- Page 14 1. Turn the pool pump off and remove Glide from the pool. 2. Disconnect the cleaner from the hose. 3. Place Glide on a flat work surface and, gently pull the tires out of the hub frame of the cleanerwheel until it leaves the hub frame.
- Page 15 5.0 TROUBLESHOOTING Due to the individual characteristics of your pool, some adjustment may be required to get the best performance from your Glide Pool Cleaner. The following tips will help you to optimize its performance. Problem Solution Glide does not move, or Make sure the main drain is closed.
- Page 16 Check that pump basket lid is fitted correctly, is not loose or cracked and that no O-rings are worn or missing. If necessary, contact your pool professional for assistance. Glide stays on the main Make sure the main drain is closed. You may need assistance from a drain.
- Page 17 178 POWER STREET All mechanical swimming pool products supplied GLENDENNING NSW 2761 to consumers by HY-CLOR are to be installed or used in the manner they are manufactured for only. FREE CALL NUMBER 5 DAYS A WEEK 1800 625 123.
- Page 18 HY-CLOR AUSTRALIA PTY LTD ABN: 81 000655 381 178 Power Street Glendenning, NSW 2761 Australia Australia: 1800 625 123 New Zealand: (09) 973 2477 PRODUCT HELPLINE help@hyclor.com.au help@hyclor.com.au AU: 1800 625 123 www.hyclor.com.au www.hyclor.com.au NZ: (09) 973 2477...
