- Page 1 GLIDE POOL CLEANER INSTALLATION & OPERATION MANUAL ABN: 81 000 655 381 178 Power Street Glendenning NSW 2761 Australia All enquiries AU: 1800 625 123 NZ: (09) 973 2477 or help@hyclor.com.au Visit us at hyclor.com.au Version 2.2...
- Page 2 PRODUCT HELPLINE help@hyclor.com.au AU: 1800 625 123 www.hyclor.com.au NZ: (09) 973 2477...
-
Page 3: Table Of Contents
RETURN EYEBALL POSITIONS: ................HOW TO USE THE FLOW-METER: ................. ROUTINE MAINTENANCE: ....................CARING FOR YOUR CLEANER: ..................USING THE BUMPERS (if required): .................. REPLACING TYRES: ......................TROUBLESHOOTING: ....................... 15-16 GLIDE BREAKDOWN: ......................WARRANTY: ........................599.2mm 480mm 299.9mm 465.9mm PRODUCT HELPLINE help@hyclor.com.au AU: 1800 625 123 www.hyclor.com.au... -
Page 4: Moving Parts
Congratulations on your purchase of the Glide pool cleaner. Your new cleaner can work in different types and sizes of swimming pools. It will be able to partially climb the walls. The Glide has an encased drive train to reduce the risk of the turbines jamming on debris. -
Page 5: Prior To Installation
PREPARING YOUR POOL Before installing your Glide Pool Cleaner, you need to prepare your pool as the Glide pool cleaner will not 1. Vacuum your pool using a manual vacuum cleaner. Your pool should be free of heavy debris & algae time. -
Page 6: Step 1: Check Contents
3.0 INSTALLING YOUR GLIDE POOL CLEANER Your Glide Pool Cleaner is comes assembled, making installation quick and simple. STEP 1: CHECK CONTENTS Remove the cleaner body and all accessories from the box and check the contents. Refer to Figure 1. - Page 7 Figure 2. FEMALE HOSE END MALE HOSE END Figure 2. 2. Connect the female cuff of the leader (shorter, softer) hose to Glide’s articulating swivel (on the top of the cleaner). See Figure 3. Figure 3. LEADER HOSE PRODUCT HELPLINE help@hyclor.com.au...
-
Page 8: Hose Floats
HOSE FLOATS The cleaner's hose floats are typically positioned as shown in Figure 4. The purpose of these floats is to maintain the cleaner in an upright position, preventing it from leaning too far forward or backward. Adjustments might be necessary at different suction levels to ensure the cleaner remains balanced. -
Page 9: Skimmer Connection
6 = maximum flow to the cleaner, hardest to open the-spring loaded flap. 5. Turn the pump ON, and the Glide pool cleaner will begin to automatically vacuum your pool. Note: The cleaner should operate between 11-14 RPM for optimal cleaning results. -
Page 10: Safety Instruction
Keep all body parts away from the suction port. Note: The Glide pool cleaner has a few different turning cycles, allow up to 5 - 10 min for the cleaner to turn out of difficult spots before changing the settings. The Glide is designed to clean the entire pool over 6+ hours using a random pattern. -
Page 11: Return Eyeball Positions
RETURN EYEBALL POSITIONS Position the return eyeballs to redirect the return water from the pool pump/filter system so it dose not interfere with the Glides movement. Try different position to see which works best in your pool: • Flow directed alongside the pool (the tile line). •... -
Page 12: How To Use The Flow-Meter
• When removed from the pool, make sure the hose is stored straight. Never coil the hose as this may cause the hose to develop a "memory" which may adversely affect the performance of your your Glide pool cleaner. • Remove your Glide (including hose) before chemical treatment. Wait a minimum of 24-48 hours hours after super chlorination (shock treatment) before re-installing the Glide pool cleaner. -
Page 13: Caring For Your Cleaner
CARING FOR YOUR GLIDE POOL CLEANER IF GLIDE STOPS RUNNING 1. Make sure the pool pump is off. Remove your Glide pool cleaner from the pool and disconnect the cleaner from the hose. 2. If you try to rotate the wheels and they don’t move, check if anything is clogged inside the cleaner. -
Page 14: Using The Bumpers (If Required)
1. Turn the pool pump off and remove Glide from the pool. 2. Disconnect the cleaner from the hose. 3. Place Glide on a flat work surface and, gently pull the tyres out of the hub fram of the cleaner wheel unit it leaves the hub frame. -
Page 15: Troubleshooting
TROUBLESHOOTING Due to the individual characteristics of your pool, some adjustment may be required to get the best performance from your Glide pool cleaner. The following tips will help you to optimise its performance. Problem Solution Glide does not move, or Make sure the main drain is closed. - Page 16 O-rings are worn or missing. If necessary, contact your pool professional for assistance. Glide stays on the main Make sure the main drain is closed. drain. Check to be sure main drain grate is installed.
-
Page 17: Glide Breakdown
GLIDE BREAKDOWN Name Top cover Handle Swivel assembly Turbine assembly Gear assembly Push button assembly (front and rear) Wheel hub Wheel axis Tyre with bumper inserts Tyre bumper Decorative wheel hub insert Wheel arch left Wheel arch right Flow gates... -
Page 18: Warranty
(refer to product table. All mechanical swimming pool products supplied FREE CALL NUMBER 5 DAYS A WEEK to consumers by HY-CLOR are to be installed or 1800 625 123. used in the manner they are manufactured for only. PRODUCT HELPLINE help@hyclor.com.au... - Page 19 PRODUCT HELPLINE help@hyclor.com.au AU: 1800 625 123 www.hyclor.com.au NZ: (09) 973 2477...
- Page 20 HY-CLOR AUSTRALIA PTY LTD ABN: 81 000655 381 178 Power Street Glendenning, NSW 2761 Australia Australia: 1800 625 123 New Zealand: (09) 973 2477 PRODUCT HELPLINE help@hyclor.com.au help@hyclor.com.au AU: 1800 625 123 www.hyclor.com.au www.hyclor.com.au NZ: (09) 973 2477...
