- Page 1 Creator Series Product Manual...
-
Page 2: Table Of Contents
Register your Creator Series speakers to ensure the best possible product and customer support Thank you for purchasing this Creator Series architectural speaker. In this product manual, you’ll find information about setting up Register your speakers using the QR code your system and how to maintain your speakers for a lifetime or visit monitoraudio.com/registration... -
Page 3: Preparing Your Installation
Draw around cut-out template Cut around traced lines CAUTION: The Creator Series loudspeakers can only be fixed into plasterboard (dry-lined) or suspended ceilings (in-ceiling models), with a thickness of up to 35mm (excluding the Super Slim series, which can be fixed up to 15mm) and walls (in-wall models), with a thickness of up to 30mm. -
Page 4: Installation - In-Wall Speaker
Installation - In-Wall speaker In-Wall mid-pod rotation You can rotate the mid-pod section of Creator Series In-Wall models (excluding W1-M) when using in a centre-channel configuration. Draw and cut around cut-out template Run cabling to the cut-out hole Connect cable to Quik-Link terminal... -
Page 5: Setting Up A Surround Sound System
Setting up a surround sound system AV positioning Please refer to the illustration on the right for the ideal angles and positions of each speaker in your surround system. If setting up a 5.1 system you should place your surrounds in position (A). If setting up a 7.1 surround system you should place your side speakers in position (B) and rear speakers in position (C) to create a full 360°... - Page 6 Setting up a surround sound system Dolby Atmos ® Please see the diagram on the right for ideal positioning of 2 or 4 Dolby Atmos speaker setups. ® Typically these would be in line with the front left and right speakers. 80°...
-
Page 7: Quik-Link Terminals
Quik-Link terminals Painting the grilles Quik-Link has been invented to make the installation of in ceiling and in wall speakers as safe and as quick as possible. You simply take the terminal off the speaker prior to installing (possibly even at first fix/ pre-installation stage) and connect the terminal to the speaker cables using the sprung terminals. -
Page 8: Speaker Controls
Speaker controls Switch Options Effect Usage Switch Options Effect Usage Corner. (On) / • (Off). -6dB cut at low frequency. Use when speaker is near - / • / +. Cut/boost C2S, C2M, C2M-CP, C2L, C2L-CP to a wall/corner or when high frequency HF - = 30x30º... -
Page 9: Warranty
Warranty Specifications In the unlikely event that there is a defect with this product, it is covered by Model Name C2 M C2M-T2X C2M-CP the Monitor Audio manufacturer’s warranty, provided that the product was Sensitivity 84dB 86dB 88dB 84dB 86dB... -
Page 10: Specifications
Specifications Model Name C2L-T2X C2L-CP C3L-CP C3L-A Model Name W1M-E W2M-CP Sensitivity 88dB 88dB 89dB 87dB 89dB 89dB 89dB Sensitivity 84dB 87dB 87dB 87dB 88dB (2.83Vrms@1m, (2.83Vrms@1m, Installed) Installed) Cutout Size Ø 248 mm (9 ”) Ø 248 mm (9 ”) Ø... - Page 11 Listen Again. Monitor Audio Ltd. 24 Brook Road Rayleigh, Essex SS6 7XJ England Tel: +44 (0)1268 740580 Email: info@monitoraudio.group monitoraudio.com ©Monitor Audio Ltd. | V1-2023 - Creator Series...
