Summary of Contents for AEMC instruments 6470

  • Page 1 6470 DIGITAL GROUND  RESISTANCE AND SOIL RESISTIVITY TESTER E N G L I S H User Manual...
  • Page 2 Owner’s Record The serial number for the Model 6470 is located on the instrument’s case. Please record this number and purchase date for your records. GROUND RESISTANCE TESTER MODEL 6470 CATALOG #: ____________________________________________________ SERIAL #: ______________________________________________________ PURCHASE DATE: _______________________________________________ DISTRIBUTOR: __________________________________________________...

  • Page 3: Table Of Contents

    Table of Contents 1. INTRODUCTION ................4 1.1 International Electrical Symbols ............5 1.2 Receiving Your Shipment ..............5 1.3 Ordering Information ................5 1.3.1 Kits, Accessories and Replacement Parts ......6 2. PRODUCT FEATURES ..............7 2.1 Description ...................7 2.2 Main Features ..................8 2.3 Control Features ..................9 2.4 Display ....................10 2.5 Button Functions ................12 2.5.1 START/STOP Button ............12 2.5.2 Button ................12 2.5.3 (SELECT) Button .............12 2.5.4 (CHANGE) Button ............13 2.5.5 MEM /MR Button .
  • Page 4 DISTANCE Button Results ............51 4.8 Saving Measurements into Memory...........52 4.9 Recalling Measurements from Memory ..........53 4.10 Erasing Measurements from Memory ..........53 4.10.1 Erasing All Measurements ............53 4.10.2 Erasing Selected Measurements ..........54 5. DATAVIEW SOFTWARE ..............55 ® 5.1 Introduction ..................55 5.2 Features .....................56 5.3 Dataview Software Installation ............56 5.4 Installing the USB drivers ..............61 5.5 Connecting the Model 6470 to your Computer ........62 5.6 Starting DataView ................62 ® 5.7 Configuring the Instrument ..............64 5.7.1 Configuration Functions ............65...
  • Page 5 5.7.2 DC Continuity Test ..............65 5.7.3 3-Pole Ground Resistance Test ..........66 5.7.4 4-Pole Soil Resistivity ............66 5.8 Downloading Data to Database ............67 5.8.1 Recordings ................68 5.8.2 Session Properties ..............69 6. MAINTENANCE ................71 6.1 Maintenance..................71 6.2 Power Supply and Recharging............71 APPENDIX A: TROUBLESHOOTING ............73 Repair and Calibration ..................74 Technical and Sales Assistance .................74 Limited Warranty ....................75 Warranty Repairs ....................75...

  • Page 6: Introduction

    Comply with the conditions for use: temperature, humidity, altitude, pollution level and place of use. • This instrument can be used on Category IV installations for maxi- mum differential voltages of 50Vrms across terminals and across the various terminals and earth (see EN 61010-1 and IEC 61557). • Use only connection accessories with overvoltage and working voltage category greater than or equal to that of the measurement instrument. Use only accessories complying with safety standards (EN 61010-2-031). • Set the switch to the OFF position when the instrument is not being used. • Check that no terminal is connected and the switch is set to OFF before opening the device. • Troubleshooting and metrological verification procedures must only be performed by qualified, approved personnel, or the factory. Ground Resistance Tester Model 6470...

  • Page 7: International Electrical Symbols

    ® meter, product warranty and registration card, and user manual. Ground Resistance Tester Model 6470 Kit (150 ft) ......Cat. #2135.02 Includes meter, rechargeable NiMH batteries, optical USB cable, power adapter 110/240V with power cord 115V US, two 150 ft color-coded leads on spools (red/blue), one 30 ft lead (green), two T-shaped auxiliary ground electrodes, set of five spaded lugs, one 100 ft AEMC ®...

  • Page 8: Kits, Accessories And Replacement Parts

    Ground Tester DVD/Workbook Set ...........Cat. #2130.64 Set of two, 14.5" T-shaped Auxiliary Ground Electrodes ....Cat. #2135.39 Carrying Bag - Replacement for Meter ..........Cat. #2135.40 Optical USB Cable................Cat. #2135.41 ..........Cat. #2135.42 12V Battery Adapter (for vehicle use) Rechargeable NiMH 9.6V Battery Pack ...........Cat. #2960.21 Order Accessories and Replacement Parts Directly Online Check our Storefront at www.aemc.com for availability Ground Resistance Tester Model 6470...

  • Page 9: Product Features

    The Model 6470 is Cat IV rated to 50V and is over voltage protected to more than 250V against accidental connection to live circuits. The voltage is also displayed on screen. In the event of a system fault, the Model 6470 can withstand 250V Additional features of the Model 6470 include a heavy-duty field case sealed against dust and water when closed (the test button is also sealed against the elements); manual and automatic test frequency selection from 40 to 513Hz; user selectable 3-Pole (3-Point) Fall of Potential or 4-Pole (4-Point) Soil Resistivity test methods and user selectable 2-Wire or 4-Wire Bond Resistance test method. The Model 6470 is powered by 9.6V, 3.5 Ah NiMH rechargeable batteries. An ex- ternal recharger powered from 120/230V 50/60Hz is included and provides for testing while recharging. The Model 6470 can also be vehicle powered from an...

  • Page 10: Main Features

    4-Pole (4-Point) soil resistivity measurement with automatic calculation of Rho (r) and user selection of the Wenner or Schlumberger test method • 3-Pole (3-Point) earth coupling measurement • Manual and automatic frequency scan from 40 to 513Hz for optimum test ac- curacy in electrically noisy environments • Selectable test voltage of 16 or 32V up to 250mA of test current • Auto-off power management • Automatic recognition of all electrode connections and their resistance value • Stores up to 512 complete test results in internal memory • Optically isolated USB communication • Remote set up and operation of all measurements using DataView software ® supplied • Automatic report generation • Rechargeable NiMH batteries from wall charger or vehicle power • Rugged dustproof and rainproof field case – IP54 rated in closed position • Grounding standards IEC 61557 parts 4 and 5 compliant • Includes DataView software for data storage, real-time display, analysis, re- ® port generation and system configuration Ground Resistance Tester Model 6470...

  • Page 11: Control Features

    2.3 Control Features Figure 2-1 1. Backlit LCD Display (see §2.4) 2. Battery charging connector 3. Input terminal H (Z) - auxiliary electrode 4. Input terminal S (Y) - auxiliary electrode 5. Input terminal ES (Xv) - auxiliary electrode 6. Input terminal E (X) - grounding electrode under test 7. Six program / function buttons (see §2.5) 8. Optical interface connector for connection to a computer 9. Range selection switch 10. Start/Stop button Ground Resistance Tester Model 6470...

  • Page 12: Display

    Indicates the battery charge condition; the segments represent the energy Indicates that the secondary function of a button will be used External voltage present - this symbol is activated when the instrument measures voltages above 60Vp Ground Resistance Tester Model 6470...
  • Page 13 In AUTO mode, the measurement frequency is automatically adjusted to the best available disturbance voltage rejection. Symbol not used in Model 6470 Indicates the 2-Wire DC resistance; calculates the offset of the cable resistance into the result (5W max for offset value)

  • Page 14: Button Functions

     button is activated. In this case, it only disappears when the button is pressed again, or if other function buttons are pressed. This allows you to rapidly decrease parameters with the  button, without having to press the button every time. 2.5.3 (SELECT) Button  - Increases the value of the flashing parameter displayed or selects the next parameter up. Press the button for a longer time to increase the change of value speed at a faster rate. - Decreases the value of the flashing parameter displayed or selects the next parameter down. Press the button for a longer time to increase the change of value speed at a faster rate. Ground Resistance Tester Model 6470...

  • Page 15: Change) Button

    OBJ:TEST address together with the main result in the big display. The OBJ:TEST address in A2 (see § 2.4) can be modified with the arrow buttons. NOTE: The following functions have special requirements: MR for Resistivity Measurement: If more than one measurement belongs to an OBJ:TEST number, it is possible to modify the DISTANCE to select each measurement. The stored records with different distances are selected with the arrow buttons. DISPLAY scrolls through all results. MR for Earth Coupling Measurement: If MR shows a coupling record measurement under OBJ:TEST address, then it is the 4th record of that measurement that represents the earth coupling value. Other results can be obtained with the selection of 1, 2, 3 or 4 by using the arrow buttons. To exit, move the main switch or press the MR button. Ground Resistance Tester Model 6470...

  • Page 16: Display / Smooth Button

    In State 1 and 3: • AUTO / MANUAL mode • Test frequency • Test voltage • Current direction (polarity) in Bond Resistance/Continuity Measurement Pushing this button causes the associated symbol to blink. Modifications can be performed with the arrow buttons. Previously measured results are lost if any pa- rameter that influences the measurement result is altered. In State 2: During the measurement in MANUAL mode, the Hz button directly /OPTIONS enables the modification of frequency (in 3-Pole and Resistivity Measure- ments), or the current direction (polarity) in Bond Resistance/Continuity Mea- surement. Ground Resistance Tester Model 6470...
  • Page 17 (current direction for resistance measurement). When the Hz button is active, the CONFIG symbol is displayed. /OPTIONS After finishing the queue, the symbol disappears. Exit from CONFIG mode occurs: • By pushing the DISPLAY button • At the end of queue in the CONFIG menu • By starting a measurement with START button • By turning the main rotary switch DISTANCE This function is only available for ground resistivity measurements. It allows the setting of values of distances used for Rho (ρ) calculation. It is accessible in States 1 and 3 only (see § 2.5.6). Ground Resistance Tester Model 6470...

  • Page 18: Specifications

    0.00 to 9.99mV 0.01mV Nominal: 10.0 to 99.9mV 0.1mV 2% of Reading ± 3cts 100 to 999mV 41 to 513Hz AC/DC Field: 1.00 to 9.99V 10mV 5% of Reading ± 5cts 10.0 to 99.9V 100mV Ground Resistance Tester Model 6470...

  • Page 19: Frequency Measurement

    “>”or “<” 1 to 999W on 3 digits 2-Wire: Range Resolution Accuracy 0.01 to 9.99W 0.01W Nominal: 10.0 to 99.9W 0.1W 2% of Reading ± 2cts 100 to 999W Field: 1.00 to 9.99kW 5% of Reading ± 3cts 10.0 to 99.9kW 100W Ground Resistance Tester Model 6470...

  • Page 20: Ground/Earth Measurement - 3-Pole (3-Point)

    RH/RE and/or RS/RE ≤ 5000 • Test frequency: 41 to 300Hz ± ( 5% of Reading + 2ct ) • No disturbance voltage or • Disturbance voltage ≤ 60V peak with (f meas.- f dist.)/f meas. > 0.2 Ground Resistance Tester Model 6470...

  • Page 21: Soil Resistivity 4-Pole (4-Point) Measurement

    10Ω 10.0 to 99.9Ω 100Ω Test Frequency Selection Table: Frequency Table / Hz for 6470 3-Pole (3-Point) 101 110 119 122 128 134 137 146 159 165 171 183 195 201 220 238 244 256 269 275 293 317 330 342 366 391 403 439 476 488 513 3.2.5 Soil Resistivity 4-Pole (4-Point) Measurement...
  • Page 22 • Auxiliary ground rod resistance/R ≤ 20,000 S-ES • Measurement frequency: 41 to 128Hz ± ( 20% + 1ct ) • No disturbance voltage or • Disturbance voltage ≤ 60V peak with (f meas.- f dist.)/f meas. > 0.2 Ground Resistance Tester Model 6470...

  • Page 23: Data Storage

    (1) With 5 sec (or the time defined by the instrument) measurement and 25 sec pause at normal load. (2) With R = 1W (3) With R = 10W and R = 1kW (4) With R = 100W and R = 1kW S-ES Power Supply: 110/220, 50/60Hz external charger with 18V , 1.9A output or vehicle power Fuse: 0.63A, 250V, 5x20mm, 1.5kA Ground Resistance Tester Model 6470...

  • Page 24: Mechanical

    Storage Temperature: -40° to 158°F (-40° to 70°C); 0 to 90% RH 3.5 Safety EN 61010-1 / EN61326-1 and IEC 61557-1-4-5 50V Cat IV, Pollution Degree 2 *All specifications are subject to change without notice Ground Resistance Tester Model 6470...

  • Page 25: Operation

    9.6k / 19.2k / 38.4k 9.6 k bits press) Default configuration Hz/OPTIONS yes / no press) Memory used 000 to 512 (total 000 on 512 press) number of locations) *International format date and time only Ground Resistance Tester Model 6470...

  • Page 26: Operation Mode

    • Automatic earth coupling calculation • Manual measurement frequency adjustment 4-Pole (4-Point) • Manual end of measurement • Not allowed Soil Resistivity (Press on the START/STOP button) Measurement • Automatic calculation by setting of distances of the rods Frequency settings have a default value in each function after rotary switch chang- Ground Resistance Tester Model 6470...

  • Page 27: Voltage Check

    22.50V S-ES 60.02Hz Y-Xv) • If a detected voltage exceeds the value level > 60V peak, the measurement is not allowed and the display switches to external voltage indication with blink- ing attention symbol. • After the voltage check, the instrument checks the connected leads and can- cels the measurement if a missing connection is detected. The instrument turns to the initial screen and the input symbols in the display blink for faulty or missing leads. • If an external voltage exists and it influences the stability, the NOISE symbol blinks to signal the condition. • In 3-Pole (3-Point) and resistivity measurements, the auxiliary rod resistances will now be measured together with the earth / ground resistance if the START button has been pressed for more than 2s. (Note that this test takes a longer time). • If the START button is pressed shortly (<2s), then the functional measurement omits the rod resistance measurement. Ground Resistance Tester Model 6470...

  • Page 28: General Operating Rules

    This means that an FFT analysis of a disturbance voltage searches the best available test frequency for a stable measurement. This automatic selected frequency is at least ±20% out of the detected disturbance frequency value. If no suitable frequency Ground Resistance Tester Model 6470...
  • Page 29 • Start of the functional measurement. STOP is only active in MANUAL mode and when the measurement is running. If no main measurement result has occurred and the START/STOP button is pressed, the instrument returns to the initial screen and State 1. The Model 6470 can be operated via the USB interface (complete remote mode) in all measurement functions except the SET-UP position. In the SET-UP position there is no interface communication allowed. NOTE: In the following sections A1, A2 and A3 refer to the following: A1 = Top Display A2 = Middle Display A3 = Bottom Display Figure 4-1 Ground Resistance Tester Model 6470...

  • Page 30: Bond Resistance/Continuity Measurement (Mw Position)

    Sensing method. It uses 4 test leads and the test lead resistance is automatically “eliminated” from the measurement. Users concerned by the lead resistance (and don’t want it in the measurement) use this method. All four terminals are used. 2-Pole/Wire Connection 4-Pole/Wire Connection (Xv) Figure 4-2 4.4.1 Configuration Settings By default, the instrument is in MANUAL mode and will perform a 2-Pole measure- ment. To change the configuration before making the measurement, use the Hz /OPTIONS and ► buttons to: • Select the measurement mode (MANUAL or AUTO). • Select the number of wires for the measurement (2- or 4-Wire). • In MANUAL mode, select the measurement current polarity. Ground Resistance Tester Model 6470...

  • Page 31: Lead Compensation Measurement (2-Wire Mode Only)

    During the measurement: • In MANUAL mode only, the Hz button is used to change the polarity /OPTIONS of the measurement current. NOTE: If the measurement is unstable or if the measurement results are incon- sistent, trigger the measurement again to check that the problem is not a faulty connection. Ground Resistance Tester Model 6470...
  • Page 32 A1= R --- W +DC or -DC A1= R --- W +DC or -DC A2= U --- V DC A2= U A2= U --- V DC A3= I --- mA A3= Hz A3= I --- mA Ground Resistance Tester Model 6470...
  • Page 33 A1= R XXX W +DC A2= U XXX V DC A2= U XXX V DC A2= U XXX V DC A3= I XXX mA A3= I XXX mA A3= I XXX mA DISPLAY button 2-Wire without compensation: No effect. DISPLAY button 2-Wire with compensation: No effect. DISPLAY button 4-Wire: No effect. Ground Resistance Tester Model 6470...
  • Page 34 A3= I XXX mA A3=I XXX mA A3= Hz (1) Fourth push Fifth push A1= R XXX W ±DC A2= R+ XXX W A2= U A3= R - XXX W A3= Hz (1) Note: example with +DC direction (1) external voltage measurement. Ground Resistance Tester Model 6470...
  • Page 35 (1) external voltage measurement. NOTE: In 4-Wire measurement there is no compensation allowed. NOTE: In both MANUAL and AUTO mode, if there is a DC disturbance voltage or an AC voltage > 42V eff, the measurement is cancelled. A compensation measurement erases previous measurement results. The START button is always active. Ground Resistance Tester Model 6470...

  • Page 36: Ground Resistance Measurement - 3-Pole (3-Point)

    Model 6470 can also measure the resistance of the auxiliary rods. The nominal test frequency is 128Hz (Square Wave) which is typical for ground testers. In certain cases measurements, at nominal test frequency may be affected by stray signals in the ground. The Model 6470 automatically scans the stray volt- age noise and internally selects the best test frequency between 41Hz, 55Hz, 92Hz, 110Hz, 119Hz, 128Hz, 476Hz for the optimum measurement. For advanced users, the test frequency can be manually selected between 41Hz and 513Hz. Details on ground resistance measurements and rod distances are available in the AEMC Understanding Ground Resistance Testing Workbook CD that was ® included with the instrument. Please note that the AEMC ground kits include color-coded leads which match the ® terminals to facilitate connections and to ensure that adequate test lead lengths are provided. Ground Resistance Tester Model 6470...

  • Page 37: Measuring Ground Resistance

    NOISE will be displayed and blinking. If a stray voltage >60Vpeak appears the measurement will stop. • If the measurement is unstable or seems not coherent, check the connections and measure again. • The Ground Resistance value is displayed at the top of the display - (e.g. R = 16.60W). NOTE: The actual test time is dependant on the test conditions and longer when the Model 6470 searches for the optimum test frequency. Ground Resistance Tester Model 6470...

  • Page 38: Auto And Manual Modes

    SELECT Button /OPTIONS AUTO-MANUAL Mode (before and after functional measurement) When pushing the Hz button, the display shows the CONFIG symbol and /OPTION the parameter that is configurable will blink. The Hz button selects the parameter, that can be modified. Validation of /OPTIONS a parameter is made: • By pushing the Hz button to the next step /OPTIONS • By starting a measurement pushing the START button (short push or long (>2s) push - see § 4.5.1) • By turning the rotary switch • By pushing DISPLAY For measurement frequency selection in MANUAL mode, the SELECT button enables the modification of the numerical value (blinking number). The CHANGE button ► only modifies the user defined frequencies using the table contained in the instrument. Ground Resistance Tester Model 6470...
  • Page 39 ► button for any value out of a table in XXX Hz. First push Second push A1= R A1= R A2= U XXX V A2= U XXX V A3= XXX Hz modification with edit keys A3= XXX Hz Second push on Hz button: the display does not change but the blinking /OPTIONS frequency is then stable. Pushing the DISPLAY button stores the last frequency value and moves the dis- play indication to the initial state. Ground Resistance Tester Model 6470...
  • Page 40 A3= I XXX mA A3= Hz (1) A3= F Hz (1) First Push Second Push Third Push XXX W AC A1= R A2= U A2= U A2= U A3= Hz (2) A3= F Hz (2) A3= I XXX mA Ground Resistance Tester Model 6470...

  • Page 41: Earth Coupling Measurement - 3-Pole (3-Point)

    (1) If NOISE was blinking during the measurement, in State 3 NOISE is stable and the values that had been measured during the measurement, are shown. (2) Display shows actual readings of the external voltage and frequency. 4.6 Earth Coupling Measurement - 3-Pole (3-Point) 4.6.1 Measurement Figure 4-5 Coupling Coefficient: k = (RH + RL - RHL) / 2RH Ground Resistance Tester Model 6470...
  • Page 42 • Use the Hz button to select MANUAL mode, then EARTH COU- /OPTION PLING. • Press the Hz button again to change the measurement frequency /OPTION or the voltage applied, if desired. The earth coupling calculation requires three successive ground resistance mea- surements to be performed and stored one-by-one. First measurement: 3-Pole (3-Point) earth measurement that will give R = Ra + Rc with: = first ground earth resistance Rc = coupling resistance between R and R Second measurement: 3-Pole (3-Point) earth measurement that will give R = Rb + Rc with: = second ground earth resistance Rc = coupling resistance between R and R Ground Resistance Tester Model 6470...
  • Page 43 The results are stored under the same OBJ-TEST number that has been select- ed after the first measurement; no selection is possible after storage of the first measurement. The three different measurements are distinguished by the sample number (1, 2 and 3 indicated on the display). When the results of measurement #1 have been stored, #2 is blinking on the display and so on. After the START of the first measurement, no change is possible with the Hz /OP- button until the 3rd measurement has been stored. TION The measurements, before reaching the final calculation, can only be stopped by switching of the main function switch. The arrangement of the auxiliary H (Z) and probe S (Y) electrode should not be removed during the three measurements. Frequency change, if needed, is only possible for the first measurement; the same measurement frequency is used for all 3 measurements. After the results of the third measurement have been stored, the instrument cal- culates all coupling results and stores them into extended location 4 automatically and displays R , C1 and C2. Each result can be recalled using the MR button. Ground Resistance Tester Model 6470...

  • Page 44: Measurement Results

    (before 2-Point measurement #3) The display shows EARTH COUPLING 3 ( 3 = blinking ) Without compensation: Initial First Push Second Push (1) --- W AC --- W AC A1= R A1= R A2= U A2= U A2= U A3= 96 Hz A3= Hz A3= 96 Hz Ground Resistance Tester Model 6470...
  • Page 45 NOISE A2= U NOISE A2= U A3= I XXX mA A3= Hz A3= Hz A3= Hz Second Push Third Push XXX W AC A1= R A2= U A2= U XXX V A3= Hz A3= I XXX mA Ground Resistance Tester Model 6470...
  • Page 46 A1= R c XXX W A1= R c XXX W A2= R a XXX W A2= C1 XXX A2= U A2= C1 XXX A3= R b XXX W A3= C2 XXX A3= F 96 Hz A3= C2 XXX Ground Resistance Tester Model 6470...

  • Page 47: Soil Resistivity Measurements (Ρ Position)

    NOTE: That the two center auxiliary rods are the current electrodes, and their spacing corresponds to the depth of the resistivity measured. A four-electrode piece of equipment, which can be made available in the physics laboratory, was designed and fabricated for measuring current and potential val- ues so as to obtain the resistivity values. Readings taken from our chosen location using both Wenner and Schlumberger arrays were analyzed. In the resistivity method, the Wenner configuration discriminates between resistivi- ties of different geoelectric lateral layers, while the Schlumberger configuration is used for the ‘depth sounding’. The theory behind the resistivity method was intro- duced with some degree of sophistication. Experimentally determined values of depth to surface were correlated with the values determined from the excavated site and this gave a good correlation. It was observed that the resistivity value in the chosen location increases with the depth and the Schlumberger method was seen to have a greater penetration than the Wenner. Ground Resistance Tester Model 6470...

  • Page 48: Advantages/Disadvantages Of Wenner And Schlumberger

    In general, interpretations In general, interpretations based on DC soundings based on DC soundings will be limited to simple, will be limited to simple, horizontal; layered horizontal; layered structures structure. Source: DC Resistivity - T. Boyd Ground Resistance Tester Model 6470...

  • Page 49: Measuring Soil Resistivity - 4-Pole (4-Point)

    128, 119, 110, 92, 55Hz UsrXXX (128Hz per default) 3rd Push 4th Push EXIT Figure 4-6 Wenner Method: ρ = 2 x Π x d x R S-ES S-ES Schlumberger Method: ρ = (Π x (d /4)/A) x R S-ES S-ES Ground Resistance Tester Model 6470...
  • Page 50 NOTE: The distances “A” and “d” cannot be modified during the measurement. During the measurement, you can use the Hz/OPTIONS and buttons to modify ► the measurement frequency, between 41 and 128 Hz only. If the measurement is unstable and results are inconsistent, trigger the measure- ment again to check that the problem is not a faulty connection. Any change to the “A” or “d” distance parameters after the measurement will auto- matically result in a new resistivity calculation by the instrument. Several measurements can be saved for different distances in a single OBJ:TEST test location. In this way, the resistivity can be determined as a function of the dis- tance, and therefore of the depth of the measurement location. Ground Resistance Tester Model 6470...

  • Page 51: Measurement Results

    Initial First Push Second Push A1= r A1= r A1= r XXXWm XXXWm XXXWm XXX W XXX W A2=R A2= U XXX V A2=R S-ES S-ES S-ES A3= d= 1.0 m A3= I A3= d= 1.0 m Ground Resistance Tester Model 6470...
  • Page 52 Fourth Push A1= r XXXWm XXX W A2= U A2= U A2= R S-ES S-ES A3= Hz A3= Hz A3= d= 1.0 m (1) distance “A” can be seen instead of RS-ES using the DISTANCE button Ground Resistance Tester Model 6470...

  • Page 53: Distance Button Results

    S-ES S-ES S-ES A3= d= 001.0 m blinking of A3= d = 001.0 m stops A3= d = 001.0 m blinking of the most significant digit blinking the most significant digit SELECT moves the blinking digit, the last two digits are accessed together. CHANGE ► moves the value up and down. Ground Resistance Tester Model 6470...

  • Page 54: Saving Measurements Into Memory

    ρ. If no distance is set, R is displayed. If the S-ES distance is set, the variable distance value is another storage parameter and all subsequent measurements use the same voltage and frequency except the dis- tance. Therefore, the Hz button is locked after the first stored measure- /OPTIONS ment. A new distance is set with the DISTANCE and arrow buttons. Each distance is combined with the available measurement results. When storing, the instrument always takes the last measurement into account, and overwrites previous mea- sured records with the same distance. Ground Resistance Tester Model 6470...

  • Page 55: Recalling Measurements From Memory

    In the DISPLAY queue the recording time and date is shown right after the first screen. Another OBJ:TEST and DISTANCE (record number in earth coupling) can be re- called by modifying the OBJ:TEST and DISTANCE values. 4.10 Erasing Measurements from Memory 4.10.1 Erasing All Measurements • Push once on the MEM button. • The A2 display will show the number of free records. The A3 display will show the number of available records. • Push a second time on the MEM button. • The display will show “dELete ALL” records. Select either NO or YES with the ► button. NOTE: If YES is selected, all saved measurements will be deleted. Ground Resistance Tester Model 6470...

  • Page 56: Erasing Selected Measurements

    4.10.2 Erasing Selected Measurements • Hold down the button, then press the MR button. • The A1 display will show the main result, in A2 the OBJ:TEST number, and if necessary, in A3 the DISTANCE “d”. In this state, the DISPLAY button steps through the rest of the records result. This queue is extended by the time and date information which is shown by the first DISPLAY push. • When the desired measurement to erase is displayed, press a second time on the MR button. Use the ► button to change the blinking NO into YES. • A final push on the MR button erases the selected record. • To exit this mode, press the MEM button. Ground Resistance Tester Model 6470...

  • Page 57: Dataview ® Software

    This chapter will give you the information you need to know to use this program. More extensive information on specific functions available in DataView is avail- ® able in the online help system included with the software. The DataView software supplied with the Model 6470 ® provides four main functions: 1. The ability to configure the 6470 from the computer. 2. The ability to initiate a recording test from the computer. 3. The ability to store test results and print out reports of any test.

  • Page 58: Features

    The user does not need administrative access rights when using Data- View ® DataView must be reinstalled for each user in a multi-user system (e.g. ® Windows 2000 and XP). ® Minimum Computer Requirements: • Windows 98SE/2000/XP ® • 128MB (256MB-Windows XP) of RAM (256MB or more recommended) ® • 80MB of hard disk space (200MB recommended) • CD-ROM drive Ground Resistance Tester Model 6470...
  • Page 59 • *Software Updates - Links to the AEMC Software Update web site to check for ® new software version releases. • *Firmware Upgrades - Links to the AEMC Firmware Upgrade web site to ® check for new firmware version releases. • Documents - Shows a list of instrument related documents that you can view. Adobe Reader is required for viewing PDF documents supplied with Data- ® View ® Ground Resistance Tester Model 6470...
  • Page 60 3. Select the DataView, Version 2.xx.xxxx option from the list, then click on Install. 4. The Installation Wizard window will appear. Click Next. Figure 5-2 5. In the Customer Information window, enter a Name and Company, then click Next. Figure 5-3 Ground Resistance Tester Model 6470...
  • Page 61 6. In the next window, select “Complete”, then click Next. Figure 5-4 7. The Select Features window appears allowing features for all instruments compatible with DataView to be selected or not selected to install. ® Select only the instrument(s) that you want to use. You can update the soft- ware for other instruments later, if necessary. Figure 5-5 Ground Resistance Tester Model 6470...
  • Page 62 8. In the Ready to Install the Program window, click on Install. Figure 5-6 9. Read the next dialog box, then click OK. Figure 5-7 10. If the instrument selected for installation (see Figure 5-5) requires the use of a USB port, the Install Driver dialog box will appear. Click on Install. Figure 5-8 11. The Installation was Successful dialog box will appear. Click on OK. 12. Next, the Installation Wizard Complete window will appear. Click on Finish. Ground Resistance Tester Model 6470...

  • Page 63: Installing The Usb Drivers

    DataView’s installa- tion. • Second Level: This level is for communication between the DataView application and the USB port. This is done when the instrument is connected to the computer. Upon the Second Level installation, the Found New Hardware dialog box will be displayed. Windows will complete the driver installation process automatically. Ground Resistance Tester Model 6470...

  • Page 64: Connecting The Model 6470 To Your Computer

    If you connected your instrument to the computer before installing the software and drivers you may need to use the Add/Remove Hardware utility to remove the instrument driver before repeating the process. 5.5 Connecting the Model 6470 to your Computer The Model 6470 is supplied with an optically isolated USB interface cable re- quired for connecting the instrument to the computer. This cable (Cat. #2135.41) is equipped with a USB type A on one end, and an optical connector on the other end. To connect the Model 6470 to your computer: 1. Connect the optical connector end of the cable to the serial port on the front panel of the Model 6470 (see § 2.3, Item #8).
  • Page 65 • Download Data: Opens an instrument control panel and begins the download of recorded data. • Open Data File: Displays the Create View from Template dialog box allowing you to open an existing database using a user customized or predefined template. Ground Resistance Tester Model 6470...

  • Page 66: Configuring The Instrument

    NOTE: The communication rate needs to be the same as the instrument. Select Set-up from the rotary switch to check the rate. When a communication link is established, DataView will automatically identify ® the instrument that it is connected to. Figure 5-12 Ground Resistance Tester Model 6470...

  • Page 67: Configuration Functions

    OK: Closes the dialog boxes and brings up the control panel. • Cancel: Exits without saving configuration. • Buzzer Enabled: When selected, buzzer is ON. • Set Instrument Clock: Updates the clock to the PC clock. • Drop-down Indicators: Indicates the configuration available for each mea- surement range. 5.7.2 DC Continuity Test (see Figure 5-12) When DC Continuity is selected from the tool bar, you can: • Select a 2- or 4-Wire test • Select a current test (positive, negative or Auto +/-) • Enter and activate an alarm from 1 to 999W (2-Wire only), if desired. For very low resistance measurement, a lead compensation value (see § 4.4.2) may be entered. Input noise status at the input of the meter is always displayed. Ground Resistance Tester Model 6470...

  • Page 68: 3-Pole Ground Resistance Test

    Selecting a sweep frequency test from the drop-down list will bring you to the sweep table selection. The sweep function is available only with the PC connected to the meter. Figure 5-13 5.7.4 4-Pole Soil Resistivity When 4-Pole Test Resistivity is selected from the tool bar, you can select: • With or without Auxiliary Rod Resistance • Test voltage 16 or 32V • Test frequency from the drop-down frequency list (selecting this will bring you to the sweep table selection, which is only available with the meter con- nected to a PC) • Test Method - Wenner or Schlumberger Ground Resistance Tester Model 6470...

  • Page 69: Downloading Data To Database

    2. Select “Save”. 3. Type a name for the downloaded file. In the Save as type drop-down menu (see Figure 5-15b), select either .dvb (saves it as a database to be viewed in DataView) or .csv (saves it as a comma delimited file to be viewed in as a spreadsheet), then and click “Save”. 4. Alternatively, select “View”. After the download is complete, a window will appear with a graph of the data, and some viewing or channel options. In that window, you can select “Save”, or “Print”. Ground Resistance Tester Model 6470...

  • Page 70: Recordings

    5. Also, from the Instrument tree view, expand the sections under “Record- ed Data from the instrument”, then click on a line that describes the recorded data. It will bring up a window with a graph of the data. 5.8.1 Recordings Figure 5-15a Figure 5-15b Ground Resistance Tester Model 6470...

  • Page 71: Session Properties

    Figure 5-19 1. After filling in the appropriate information, close the Session Properties dialog box by clicking on the “X” at the top right hand corner. 2. To open the database just downloaded, click the “Yes” button. A dialog box labeled Create View from Template will open. 3. In the Groups window of this dialog box, click on “6470” and in the Templates window click on “6470 Summary Report”. 4. A window named Step 2: Specify Database(s) will appear. The file just saved and named should be visible. To generate a report, click the “OK” button. The report will now be available on the screen including graph, individual data points and all statistical data. Ground Resistance Tester Model 6470...
  • Page 72 5. To print this report, either click on the Print icon or click on File from the top menu and then Print. This completes the process of configuring, running, retrieving data, and printing a report using DataView with your Model 6470. ® In addition to the pre-designed report templates, DataView allows you to totally ® configure reports to your needs. Refer to the DataView HELP file on “Tem- ® plates” to learn more about templates. Ground Resistance Tester Model 6470...

  • Page 73: Maintenance

    The instrument can measure when charging from the AC Line Voltage, as the adapter provides a double insulation for 240V Cat II. NOTE: Do not use the Model 6470 when charging on a DC source. This can result in an incorrect measurement under certain conditions. Low Battery: •...
  • Page 74 (3 to 5 times). Discharge cycle (15 H) can be made with the instrument in MANUAL mode, DC 2-Pole (2-Point) resistance mea- surement and a short-circuit between H (Z) and E (X) plugs. Ground Resistance Tester Model 6470...

  • Page 75: Appendix A: Troubleshooting

    Accu zero calibration Recoverable Measurement stop: NMI Recoverable Measurement stop: high voltage on inputs Recoverable Measurement stop: voltage overrange Recoverable Measurement stop: current overrange *Deleting the user memory (stored data records) in Set-up should help. Ground Resistance Tester Model 6470...

  • Page 76: Repair And Calibration

    NOTE: You must obtain a CSA# before returning any instrument. Technical and Sales Assistance If you are experiencing any technical problems, or require any assistance with the proper operation or application of your instrument, please call, mail, fax or e-mail our technical support team: Chauvin Arnoux , Inc. d.b.a. AEMC Instruments ® ® 200 Foxborough Boulevard Foxborough, MA 02035 USA Phone: (800) 343-1391 (508) 698-2115 Fax: (508) 698-2118 E-mail: techsupport@aemc.com www.aemc.com NOTE: Do not ship Instruments to our Foxborough, MA address. Ground Resistance Tester Model 6470...

  • Page 77: Limited Warranty

    CSA Form. Please write the CSA# on the outside of the shipping container. Return the instrument, postage or shipment pre-paid to: Ship To: Chauvin Arnoux , Inc. d.b.a. AEMC Instruments ® ® 15 Faraday Drive • Dover, NH 03820 USA Phone: (800) 945-2362 (Ext. 360) (603) 749-6434 (Ext. 360) Fax: (603) 742-2346 or (603) 749-6309 E-mail: repair@aemc.com Caution: To protect yourself against in-transit loss, we recommend you insure your returned material. NOTE: You must obtain a CSA# before returning any instrument. Ground Resistance Tester Model 6470...
  • Page 78 Notes: Ground Resistance Tester Model 6470...
  • Page 80 11/06 99-MAN 100298 v5 Chauvin Arnoux , Inc. d.b.a. AEMC Instruments ® ® 15 Faraday Drive • Dover, NH 03820 USA • Phone: (603) 749-6434 • Fax: (603) 742-2346 www.aemc.com...
