- Page 1 Quick Start Guide ENGLISH Clamp-On Ground Resistance Tester Model 6417 GROUND RESISTANCE TESTER WITH AEMC INSTRUMENTS ®...
- Page 2 Copyright Chauvin Arnoux , Inc. d.b.a. AEMC Instruments. All rights reserved. © ® ® No part of this documentation may be reproduced in any form or by any means (including electronic storage and retrieval or translation into any other language) without prior agreement and written consent from Chauvin Arnoux , Inc., as governed by United States and International copyright laws.
-
Page 3: Statement Of Compliance
For recalibration, please use our calibration services. Refer to our repair and calibration section at www.aemc.com/calibration. Serial #: Catalog #: 2141.02 Model #: 6417 Please fill in the appropriate date as indicated: Date Received: Date Calibration Due: Chauvin Arnoux , Inc. ®... -
Page 4: Product Packaging
Cat. #2141.51 Also Included: (4) 1.5 V AA Batteries (1) Wrist Strap (1) Safety Sheet (20 languages) (1) Quick Start Guide (1) USB Stick with User Manual & DataView Software ® Clamp-On Ground Resistance Tester Model 6417 - Quick Start Guide... -
Page 5: International Electrical Symbols
Example: hardwired equipment in fixed installation and circuit breakers. CAT II: Corresponds to measurements performed on circuits directly connected to the electrical distribution system. Example: measurements on household appliances and portable tools. Clamp-On Ground Resistance Tester Model 6417 - Quick Start Guide... -
Page 6: Precautions For Use
■ Use extreme caution when using the instrument around energized electrical equipment. ■ Never use the instrument to twist or pry the ground electrode or ground wire away from the grounded equipment. Clamp-On Ground Resistance Tester Model 6417 - Quick Start Guide... -
Page 7: Control Features
Instrument is powered OFF. Simultaneous selection of the Loop Impedance measurement and the Ω+A Leakage Current measurement. Current measurement. Memory Recall. SET-UP Access to the instrument’s configuration and deletion of stored measurements. Clamp-On Ground Resistance Tester Model 6417 - Quick Start Guide... -
Page 8: Button Functions
• Closing the clamp will automatically exit the AUTO-HOLD mode if the HOLD button is not pressed during this time. Clamp-On Ground Resistance Tester Model 6417 - Quick Start Guide... -
Page 9: Audible Signals
Moves down in the menu tree. ► Selects the menu displayed or return to the previous menu. ■ Refer to § 4.4 in the user manual for complete details on SET-UP menu items. Clamp-On Ground Resistance Tester Model 6417 - Quick Start Guide... -
Page 10: Inserting The Batteries
• All icons on the display will light up for approximately two seconds. 2. Enter the date and time of the device using the ▲, ▼, and ► buttons. The date and time can also be configured before a measurement in SET-UP. Clamp-On Ground Resistance Tester Model 6417 - Quick Start Guide... -
Page 11: Storing Measurements Into Memory
3. Double-click on Setup.exe to launch the Dataview setup program. ® You can retrieve and analyze measurement results with the DataView software ® or with an Android™ app through the Bluetooth communication port. Clamp-On Ground Resistance Tester Model 6417 - Quick Start Guide... -
Page 12: Repair And Calibration
Chauvin Arnoux , Inc. d.b.a. AEMC Instruments ® ® Phone: (800) 343-1391 (Ext. 351) Fax: (603) 742-2346 E-mail: techsupport@aemc.com www.aemc.com Clamp-On Ground Resistance Tester Model 6417 - Quick Start Guide... -
Page 13: Limited Warranty
Fax: (603) 742-2346 E-mail: repair@aemc.com Caution: To protect yourself against in-transit loss, we recommend that you insure your returned material. NOTE: You must obtain a CSA# before returning any instrument. Clamp-On Ground Resistance Tester Model 6417 - Quick Start Guide... - Page 14 NOTES:...
- Page 15 NOTES:...
- Page 16 04/24 99-MAN 100396 v09 AEMC Instruments ® 15 Faraday Drive • Dover, NH 03820 USA Phone: +1 (603) 749-6434 • +1 (800) 343-1391 • Fax: +1 (603) 742-2346 www.aemc.com © 2013 Chauvin Arnoux , Inc. d.b.a. AEMC Instruments. All Rights Reserved. ®...
