14  Operation
Rev. 00 01/20
Select predefined operating mode (Preset mode)
1. Turn on the gun control unit with the ON key
2. Press the corresponding application key.
The arrow above the desired button lights up.
The pre-defined application modes have preset values for high
voltage and spray current:
Application mode
flat parts
complicated parts
overcoat
3. The air values for total air, powder output and electrode rinsing air
can be individually defined and are saved in the programs.
Starting the individual adjustable programs
1. Turn on the gun control unit with the ON key
2. Press the program key
3. Select the desired program (01-20)
4. Change the coating parameters as required
Programs 01-20 are preset at the factory but can be modified at
any time, after which they are automatically stored.
Description
Powder output
Total air
High voltage
Spray current
Electrode rinsing air
Fluidizing air
Preset kV Preset µA
100
100
100
Program 20 active
Presetting
60 %
4.0 Nm³/h
80 kV
20 µA
0.1 Nm³/h
1.0 Nm³/h (for device type F)
0.1 Nm³/h (for device type B and S)
OptiFlex Pro Base Kit
100
22
10
