- Page 1 400.2D 400.4D 800.4D Owner's Manual English...
- Page 2 PACKAGE CONTENTS PACKAGE CONTENTS 1 EVO Amplifier 1 Owner’s Manual 1 Allen wrench 2.5mm 1 Allen wrench 4mm 1 Promotional Sticker...
-
Page 3: Important Info
Versatility of uses –The flat response of all the frequencies equipment on your vehicle, unplug the negative (-) of SounDigital amplifiers allows them to be used in all the terminal of the battery to avoid fires, injuries or kinds of systems: SPL, Sound Quality, Trio Eletrico and damages;... - Page 4 PANELS DESCRIPTION 400.2D EVO BRIDGE +12V FUSE GAIN X-OVER FULL Protection fuse 30A; Audio input RCA connector (CH1); Positive power supply connector (+12V); Audio input RCA connector (CH2). Negative power supply connector (GND); Gain control CH1 and CH2; Remote power supply connector (REM); Selector switch crossover CH1 and CH2.
- Page 5 PANELS DESCRIPTION 400.4D EVO BRIDGE BRIDGE +12V FUSE GAIN GAIN X-OVER X-OVER FULL FULL CONTROLS CONTROLS Protection Fuse 30A; Positive speaker connector (+) CH4; Positive power supply connector (+12V); Selector switch of crossover CH1 and CH2; Negative power supply connector (GND);...
- Page 6 PANELS DESCRIPTION 800.4D EVO GAIN GAIN X-OVER X-OVER FULL FULL CONTROLS CONTROLS Positive audio output connector (+) CH4; Negative audio output connector (-) CH1; Negative audio output connector (-) CH4; Positive audio output connector (+) CH1; Positive audio output connector (+) CH3; Selector switch of crossover CH1 and CH2;...
-
Page 7: Installation
INSTALLATION For proper operation, your Soundigital amplifier needs Securely mount the amplifier so thet it does not come loose in the event of a colision or sudden jolt to the the correct size of cables and electrical system. Refer to vehicle. - Page 8 INSTALLATION 400.2D EVO ATTENTION: Before proceeding with the installation of your SounDigital amplifier, unplug the negative (-) terminal of the battery. The versatility of the SounDigital multi-channel amplifiers, allows the installation in 1 or 2 channel mode. Below is the schematic for the 2-channel mode: Min.
- Page 9 INSTALLATION 400.4D EVO ATTENTION: Before proceeding with the installation of your SounDigital amplifier, unplug the negative (-) terminal of the battery. The versatility of the SounDigital multi-channel amplifiers, allows the installation in 1 or 2 channel mode. Below is the schematic for the 2-channel mode: Min.
- Page 10 INSTALLATION 800.4D EVO ATTENTION: Before proceeding with the installation of your SounDigital amplifier, unplug the negative (-) terminal of the battery. The versatility of the SounDigital multi-channel amplifiers, allows the installation in 4, 3 or 2 channel mode. Below is the schematic for the 3-channel mode: Min.
- Page 11 TECHNICAL SPECS 400.2D EVO RMS Power Channels 400.2D2 EVO 2Ω 400.4D4 EVO 2Ω 1Ω 2Ω 4Ω 2Ω 4Ω 8Ω Impedance 200W 110W 200W 110W Power @ 12.6V Bridge Power @ 12.6V 400W 220W 400W 220W 261W 144W 261W 144W Power @ 14.4V 522W 287W 522W...
- Page 12 TECHNICAL SPECS 400.4D EVO RMS Power Channels 400.4D EVO 4Ω 2Ω 4Ω 8Ω Impedance 100W Power @ 12.6V Bridge Power @ 12.6V 200W 110W 131W Power @ 14.4V 261W 144W Bridge Power @ 14.4V Audio Specs Power supply 9V to 16V...
- Page 13 TECHNICAL SPECS 800.4D EVO Channels 800.4D EVO 2Ω 800.4D EVO 4Ω RMS Power 4Ω 8Ω 1Ω 2Ω 2Ω 4Ω Impedance 200W 110W 200W 110W Power @ 12.6V 400W 220W 400W 220W Bridge Power @ 12.6V 261W 144W 261W 144W Power @ 14.4V 522W 287W 522W...
-
Page 14: Limited Warranty
LIMITED WARRANTY SounDigital warrants the original purchaser that this product shall be free of defects in materials an workmanship for a period of twelve (12) months from the original date of purchase. Some countries have extended warranty in case the product is installed by an authorized dealer. - Page 15 Manual SD400.4D EVO II Rev. 4.2...
