Ryobi CID183L Operator's Manual

13 mm 18 volt 3-speed hammer drill
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Your hammer drill has been engineered and manufactured to Ryobi's high standard for dependability, ease of operation and
operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.
WARNING:
To reduce the risk of injury, the user must read and understand the operator's manual before using
this product.
Thank you for buying a Ryobi product.
SAVE THIS MANUAL FOR FUTURE REFERENCE
OPERATOR'S MANUAL
13 mm 18 VOLT
3-SPEED HAMMER DRILL
CID183L
BATTERIES AND CHARGERS
SOLD SEPARATELY

Advertisement

Table of Contents
loading

Related Manuals for Ryobi CID183L

Summary of Contents for Ryobi CID183L

  • Page 1 CID183L BATTERIES AND CHARGERS SOLD SEPARATELY Your hammer drill has been engineered and manufactured to Ryobi’s high standard for dependability, ease of operation and operator safety. When properly cared for, it will give you years of rugged, trouble-free performance. WARNING: To reduce the risk of injury, the user must read and understand the operator's manual before using this product.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS n Introduction ..................................2 n General Safety Rules ..............................3-4 n Specific Safety Rules............................... 4 n Safety Rules for Charger ..............................5 n Symbols..................................6-7 n Features..................................8-9 n Assembly ..................................10 n Operation.................................. 10-16 n Maintenance ................................17-18 n Parts Ordering / Service ..............................

  • Page 3: General Safety Rules

    BATTERY PACK CHARGER untrained persons. Tools are dangerous in the hands of untrained users. CID183L ABP1801/1802/1803/1804 ACR1800 n When battery pack is not in use, keep it away from n Do not abuse the cord. Never use the cord to other metal objects like: paper clips, coins, keys, nails, carry the charger.

  • Page 4: Specific Safety Rules

    GENERAL SAFETY RULES SERVICE n When servicing a tool, use only identical replacement parts. Follow instructions in the Maintenance section n Tool service must be performed only by qualified re- of this manual. Use of unauthorised parts or failure to fol- pair personnel.

  • Page 5: Safety Rules For Charger

    SAFETY RULES FOR CHARGER n An extension cord should not be used unless WARNING! absolutely necessary. Use of improper extension READ AND UNDERSTAND ALL INSTRUCTIONS. cord could result in a risk of fire and electric shock. If Failure to follow all instructions listed below, may result in extension cord must be used, make sure: electric shock, fire and/or serious personal injury.

  • Page 6: Symbols

    SYMBOLS Some of the following symbols may be used on this tool. Please study them and learn their meaning. Proper interpreta- tion of these symbols will allow you to operate the tool better and safer. SYMBOL NAME DESIGNATION/EXPLANATION Volts Voltage Amperes Current Hertz...
  • Page 7 SYMBOLS The following signal words and meanings are intended to explain the levels of risk associated with this product. SYMBOL SIGNAL MEANING DANGER: Indicates an imminently hazardous situation, which, if not avoided, will result in death or serious injury. WARNING: Indicates a potentially hazardous situation, which, if not avoided, could result in death or serious injury.

  • Page 8: Features

    FEATURES PRODUCT SPECIFICATIONS Chuck ...................................13 mm Motor ..................................18 Volt DC Switch................................Variable Speed Gear Box ................................... 3-Speed No Load Speed ................Lo (0 - 370/min.), Hi (0-750/min.), Super-Hi (0 - 2200/min.) Hammer Speed ............Lo (0 - 5,920 BPM*), Hi (0-12,000 BPM*), Super Hi (0 - 35,200 BPM*) Charger Input ............................
  • Page 9 FEATURES KNOW YOUR HAMMER DRILL AUXILIARY HANDLE ASSEMBLY See Figure 1. An auxiliary handle is installed on the hammer drill. For ease Before attempting to use this product, familiarize yourself of operation, you may use the handle with either the left hand with all operating features and safety rules.

  • Page 10: Assembly

    ASSEMBLY UNPACKING WARNING: This product has been shipped completely assembled. If any parts are missing do not operate this tool until the n Carefully remove the tool and any accessories from the missing parts are replaced. Failure to do so could result box.

  • Page 11: Operation

    NOTE: If the charger does not charge the battery pack RED LED under normal circumstances, return both the battery pack and YELLOW LED charger to your nearest Ryobi Authorised Service Centre for electrical check. n Charge the battery pack only with a recommended charger. Fig. 2...
  • Page 12 LED. After 30 minutes, reinsert the battery pack in the charger. If the green LED continues to remain on, return battery pack to your nearest Ryobi Authorised Service Centre for checking or replacing. NOTE: This situation only occurs when continuous use of the tool causes the batteries to become hot.
  • Page 13 OPERATION INSERTING BITS See Figure 6. UNLOCK DRILL BIT n Lock the trigger switch by placing the rotation selector (Release) CHUCK SLEEVE in the centre position. n Position the chuck jaws so that the opening is slightly larger than the drill bit you intend to use. NOTE: To open the chuck jaws, turn the chuck sleeve counterclockwise.
  • Page 14 OPERATION WARNING: The hammer drill should never be connected to a power supply when you are assembling parts, making adjustments, cleaning, performing maintenance, or when the tool is not in use. Disconnecting the tool will prevent accidental starting that could cause serious injury. ADJUSTING THE AUXILIARY HANDLE ASSEMBLY See Figure 8.
  • Page 15 OPERATION ADJUSTING THE TORQUE See Figure 11. HAMMER MODE The hammer drill is equipped with an adjustable torque clutch for driving different types of screws into different materials. Adjust the torque as necessary. We recommend that you use TO DECREASE DRILLING MODE carbide-tipped bits and select hammer mode when drilling TORQUE...
  • Page 16 OPERATION USING THE LEVELS See Figure 13. Two levels are recessed in the motor housing of the hammer drill. One is located on top, while the other is located on the end. They can be used to keep drill bits level during both horizontal and vertical drilling operations.

  • Page 17: Maintenance

    Only the parts shown on the parts list are intended to be repaired or replaced by the customer. All other parts should be replaced at a Ryobi Authorised Service Centre. REMOVING THE CHUCK See Figures 14 - 16. n Lock the trigger switch by placing the rotation selector in the centre position.
  • Page 18 MAINTENANCE TIGHTENING THE CHUCK n Open the chuck jaws. See Figures 14 - 15. n Insert the hex key wrench into the chuck and tighten the chuck jaws securely. The chuck may become loose on the spindle and begin to shake when using the drill. Also, the chuck screw may n Tap the hex key wrench sharply with a mallet in a become loose causing the chuck jaws to bind and prevent clockwise direction.

  • Page 20: Parts Ordering / Service

    RYOBI NEW ZEALAND PTY. LTD. AUCKLAND: 27 Clemow Drive, Mt Wellington, N.Z. Tel: (09) 573 0230 - Free Call: 0800 279 624 - Fax: (09) 573 0231 - www.ryobi.co.nz Contact during normal business hours. This Guarantee Form Should Be Retained By The Customer At All Times For your record and to assist in establishing date of purchase (necessary for in-guarantee service) please keep your purchase docket and this form completed with the following particulars.
