THANK YOU FOR BUYING A RYOBI CORDLESS DRILL-DRIVER.
Your new cordless drill-driver has been engineered and manufactured to Ryobi's high standard for dependability, ease of
operation, and operator safety. Properly cared for, it will give you years of rugged, trouble-free performance.
CAUTION: Carefully read through this entire operator's manual before using your new cordless drill-driver.
Pay close attention to the Rules for Safe Operation, Warnings, and Cautions. If you use your cordless drill-driver properly
and only for what it is intended, you will enjoy years of safe, reliable service.
Thank you again for buying Ryobi tools.
SAVE THIS MANUAL FOR FUTURE REFERENCE
OPERATOR'S MANUAL
CORDLESS DRILL-DRIVER
MODEL NOS. CTH1202K2/CTH1442K2/CTH1802

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CTH1202K2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ryobi CTH1202K2

Summary of Contents for Ryobi CTH1202K2

  • Page 1 THANK YOU FOR BUYING A RYOBI CORDLESS DRILL-DRIVER. Your new cordless drill-driver has been engineered and manufactured to Ryobi’s high standard for dependability, ease of operation, and operator safety. Properly cared for, it will give you years of rugged, trouble-free performance.

  • Page 2: Table Of Contents

    Operation ...17-12 Maintenance ... 13 Service Information ... 14 CAUTION: Carefully read through this entire manual before using your new drill-driver. Look for this symbol to point out important safety precautions. It means attention!!! Your safety is involved. TYPICAL APPLICATIONS...

  • Page 3: Rules For Safe Operation

    For service we suggest you return the tool to your nearest RYOBI AUTHORIZED SERVICE CENTER for repair. When servicing, use only identical Ryobi replacement parts. WARNING: Do not attempt to operate this tool until you have read thoroughly and understand completely all instructions, safety rules, etc.

  • Page 4: Precautions On Using Your Cordless Tool

    19. DO NOT USE TOOL IF SWITCH DOES NOT TURN IT ON AND OFF. Have defective switches replaced by an authorized Ryobi Service Center. 20. DRUGS, ALCOHOL, MEDICATION. Do not operate tool while under the influence of drugs, alcohol, or any medication.

  • Page 5: Precautions Regarding The Use Of Charger And Battery

    RYOBI AUTHORIZED SERVICE CENTER. Do not disassemble charger; take it to a RYOBI AUTHORIZED SERVICE CENTER when service or repair is required. Incorrect reassembly may result in a risk of electric shock or fire.

  • Page 6: Specifications

    Your Drill-Driver" for normal recharging of batteries. If the charger does not charge your battery pack under normal circumstances, return both the battery pack and charger to your nearest RYOBI AUTHORIZED SERVICE CENTER for electrical check. BATTERY PACK PREPARATION FOR...

  • Page 7: Operation

    KNOW YOUR DRILL-DRIVER See Figures 1 and 2. Before attempting to use any tool, familiarize yourself with all operating features and safety requirements. WARNING: Do not allow familiarity with tools to make you careless. Remember that a careless fraction of a second is sufficient to inflict severe injury.
  • Page 8 Your drill has a two-speed gear train designed for drilling or driving at LO (1) or HI (2) speeds. A slide switch is located on top of your drill to select either LO (1) or HI (2) speed. When using drill in the LO (1) speed range, speed will decrease and unit will have more power and torque.

  • Page 9: To Install Battery Pack

    KEYLESS CHUCK See Figure 7. A keyless chuck has been provided with your drill to allow for easy installation and removal of bits. As the name implies, you can hand tighten or release drill bits in the chuck jaws.

  • Page 10: Installing And Removing Bits

    Open or close the chuck jaws to a point where the opening is slightly larger than the bit size you intend to use. Also, raise the front of your drill slightly to keep the bit from falling out of the chuck jaws.

  • Page 11: Torque Adjustment

    If you are not prepared, this loss of control can result in possible serious injury. When drilling metals, use a light oil on the drill bit to keep it from overheating. The oil will prolong the life of the bit and increase the drilling action.

  • Page 12: Chuck Removal

    Lock the switch trigger by placing the direction of rotation selector in center position. Insert a 5/16 inch or larger allen wrench (hex key wrench) into the chuck of your drill and tighten the chuck jaws securely. Tap the allen wrench sharply with a mallet in a clockwise direction.

  • Page 13: Maintenance

    WARNING: When servicing use only identical Ryobi replacement parts. Use of any other parts may create a hazard or cause product damage. Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to damage from various types of commercial solvents and may be damaged by their use. Use a clean cloth to remove dirt, oil, grease, etc.

  • Page 14: Service Information

    Please refer to the Service Center insert or call 1-800- 525-2579 in the United States or 1-800-265-6778 in Canada for your nearest Ryobi Authorized Service Center. You can also check our web site at www.ryobi.com for a complete list of Authorized Service Centers.

This manual is also suitable for:

Cth1802Cth1442k2
