Control panel

Betriebsanleitung
ba_c500_50s2GB06IVZ.fm
0
1
2
1 Control panel, control unit
1.1 CONTROL UNIT ON/OFF key
1.2 Digital display
1.3 Display value in millibar
1.4 Display value in seconds
1.5 PROGRAM keys 1 to 6
1.6 INCREASE VALUE key
1.7 DECREASE VALUE key
1.8 SEALING key
1.9 INERT GAS key (optional)
1.10 VACUUM key
1.11 RAPID VACUUM STOP key
2 MACHINE ON/OFF main switch
07.06.2005
ega
1.1 1.2 1.4
1.3
I / O
mbar
s
STOP
1.11 1.10 1.9 1.8 1.7 1.6
Control panel
P1 P2
P3 P4
P5 P6
1.5
