Elements of the machine

Betriebsanleitung
ba_c500_50s2GB06IVZ.fm
Front view
2
1
1 Control panel, control unit
2 Main switch
3 Sealing bars
4 Cover seal
5 Counter-pressure bars
6 Inert gas nozzles
7 Compressed air connection
8 Inert gas connection
Back view
(back wall removed)
10
9
8
7
07.06.2005
ega
Elements of the machine
9 Water outlet
10 Water inlet
11 Electrical connection
12 Electrical connection
13 Vacuum pump oil filling screw
14 Vacuum pump oil inspection glass
15 Oil cooler drain screw
16 Vacuum pump oil drain screw
13
14
16 15
3
4
5
6
11
12
3/43
