STÛV 16-COMBO
INSTALLATION MANUAL
Keep these instructions for future reference
REQUIRED TOOLS
REQUIRED MATERIAL
!
IMPORTANT
This document is an additional manual to the
Impact drill
Measuring
Crowbar
Wall and floor
Metal
Stûv handle
Stûv 16-Z installation manual. For a successful
finishing
framing
tape
installation, it is important to follow these
5
mm
instructions carefully. Look for
this symbol in the Stûv 16-Z
5 mm
Level
Wood screw #8
installation manual to know
hex bit
when to refer to this manual.
