QUICK REFERENCE GUIDE
EN
Mounting
Before mounting this product, read the Safety Notes. Make sure the mounting clamps are capable of supporting the
weight of the product. For the Chauvet line of mounting clamps, go to http://trusst.com/productcategory/truss-clamps.
Mounting Diagram
Safety Mounting Omega Safety Mounting
cable clamp bracket cable clamp
Driver Mounting Diagram
Omega Mounting Safety Mounting Omega Safety
bracket clamp cable clamp bracket cable
3
