Specifications
Input and
Inputs
output
channels
Output
Inputs
XLR/TS inputs
Built-in mic input
Output
Headphones
Recorder
Display
USB
Connector
Built-in mic (mono)
XLR/TS inputs (mono)
Headphones
Connectors
Input gain
Input impedance
Maximum input level
Phantom power
Equivalent input noise
Frequency response
Directionality
Input gain
Maximum sound pressure
input
Connector
Output impedance
Maximum output level
Maximum simultaneous
recording tracks
Recording format
Recording media
98
1
2
1
2 XLR/TS combo jacks
(Balanced, XLR: 2 HOT)
No adjustment required (dual A/D converter
circuit used)
XLR: 2.3 kΩ
TS: 1 MΩ
XLR: +4 dBu
TS: +10 dBu
+48 V (switchable separately for INPUTS A and B)
XLR: −120 dBu or less (IHF-A)
TS: −107 dBu or less (IHF-A)
XLR: −0.5/+0.0 dB, 20 Hz – 20 kHz
TS: −0.2/+0.0 dB, 20 Hz – 20 kHz
Omnidirectional
No adjustment required (dual A/D converter
circuit used)
115 dB SPL
1 stereo 3.5mm mini jack
10 Ω
20 mW + 20 mW (into 32Ω load)
2
WAV: 48kHz, 32-bit float, mono
Cards compatible with microSDHC specifications
4 GB – 32 GB
Cards compatible with microSDXC specifications
64 GB – 1 TB
2" full-color LCD (240 × 320)
USB Type-C
Note: Use a USB cable that supports data
transfer. USB bus power is supported.
