- Page 1 Product Instruction Manual Aquila IN96T Instantaneous Inline Water Heater v23.10.9...
-
Page 2: Important Safety Points
Overview Thank you for purchasing an Aquila Instantaneous Inline Water Heater. This 9.6 kW appliance is to be used for hand washing at up to 2 basins, or for a single light shower, or light dish washing. Instantaneous water heaters are energy efficient as they only consume energy when in use, so have no standing losses. - Page 3 The appliance must be earthed. Only connect this appliance to a water supply that meets the min/ max pressures specified in the specifications section of this manual. This appliance is intended to be permanently connected to the water mains and should not be connected by a detachable hose-set.
-
Page 4: Installation
1. Installation Wall Mounting Do not locate the appliance where the consequences of a water leak could be unusually serious. This appliance should not be installed in a location where freezing can occur. This appliance is not designed for outdoor use or use in damp environments. •... -
Page 5: Plumbing Connection
• Remove the front cover from the appliance by means of the single screw located between the inlet and outlet fittings. The cover will lift first from the bottom and then unhook from the top. Carefully release the PCB lead from the main unit to completely uncouple the cover. - Page 6 Flush supply pipes to remove any debris before connecting the appliance to the water supply. All pipework should be adequately earthed. • Make the plumbing connections as indicated on the front cover of the appliance: Inlet (cold mains) Outlet (hot tap/ outlet) •...
-
Page 7: Electrical Connection
3. Electrical Connection Do not commence electrical installation before connecting the appliance to the water supply and verifying there are no leaks or air gaps. The appliance must be permanently connected to the electrical supply through an appropriately rated isolating switch with a separation in all poles. Only connect the appliance to an electrical supply that meets the specification detailed on the rating label. -
Page 8: Operation
4. Operation • Once installed and connected to the electrical supply the appliance is ready for use. • Once turned on the appliance will automatically power up when it detects a flow of water through it (min 2.5 l/m). • Due to the nature of instantaneous heaters, water is only heated as it passes through the tank. -
Page 9: Cleaning And Maintenance
5. Cleaning and Maintenance Never remove the cover of the appliance without first isolating from the electrical power supply. The appliance should only be installed and maintained by a competent person in accordance with any local electrical and plumbing regulations. Do not use abrasive chemicals or cloths to clean this appliance. -
Page 10: Temperature Performance
6. Temperature Performance Temperature/ Flow Rate Maximum temperature increase from ambient incoming water supply temperature at a flow rate of: Flow rate (l/m) IN96T 55°C 45°C 34°C 27°C Table 1 Examples Maximum water temperature Incoming water temperature Flow rate IN96T 13 °C - Winter 4.0 l/m 47°C... -
Page 11: Troubleshooting
8. Troubleshooting If problems persist contact Hyco Technical Department on 01924 225200. - Page 12 In order to underline the duty to dispose of this equipment separately, the product is marked with a crossed out dustbin. Hyco Manufacturing Ltd Normandy Court Express Way...
