Valcom V2924A User Manual page 3

FIGURE 2 - PUNCHDOWN BLOCK CONNECTIONS
Block P3 - Switch Inputs
Expansion
Unit #1
26 W/BL INA25
1 BL/W INB25
27 W/O INA26
2 O/W INB26
28 W/GR INA27
3 GR/W INB27
29 W/BR INA28
4 BR/W INB28
30 W/S INA29
5 S/W INB29
31 R/BL INA30
6 BL/R INB30
32 R/O INA31
7 O/R INB31
33 R/G INA32
8 G/R INB32
34 R/BR INA33
9 BR/R INB33
35 R/S INA34
10 S/R INB34
36 BK/BL INA35
11 BL/BK INB35
37 BK/O INA36
12 O/BK INB36
38 BK/G INA37
13 G/BK INB37
39 BK/BR INA38
14 BR/BK INB38
40 BK/S INA39
15 S/BK INB39
41 Y/BL INA40
16 BL/Y INB40
42 Y/O INA41
17 O/Y INB41
43 Y/G INA42
18 G/Y INB42
44 Y/BR INA43
19 BR/Y INB43
45 Y/S INA44
20 S/Y INB44
46 V/BL INA45
21 BL/V INB45
47 V/O INA46
22 O/V INB46
48 V/G INA47
23 G/V INB47
49 V/BR INA48
24 BR/V INB48
50 V/S N.C.
25 S/V N.C.
*Expansion *Expansion
Unit #2 Unit #3
INA49 INA73
INB49 INB73
INA50 INA74
INB50 INB74
INA51 INA75
INB51 INB75
INA52 INA76
INB52 INB76
INA53 INA77
INB53 INB77
INA54 INA78
INB54 INB78
INA55 INA79
INB55 INB79
INA56 INA80
INB56 INB80
INA57 INA81
INB57 INB81
INA58 INA82
INB58 INB82
INA59 INA83
INB59 INB83
INA60 INA84
INB60 INB84
INA61 INA85
INB61 INB85
INA62 INA86
INB62 INB86
INA63 INA87
INB63 INB87
INA64 INA88
INB64 INB88
INA65 INA89
INB65 INB89
INA66 INA90
INB66 INB90
INA67 INA91
INB67 INB91
INA68 INA92
INB68 INB92
INA69 INA93
INB69 INB93
INA70 INA94
INB70 INB94
INA71 INA95
INB71 INB95
INA72 INA96
INB72 INB96
N.C. N.C.
N.C. N.C.
Block P4 – Speaker Outputs
Expansion
Unit #1
26 W/BL T STA25
1 BL/W R STA25
27 W/O T STA26
2 O/W R STA26
28 W/GR T STA27
3 GR/W R STA27
29 W/BR T STA28
4 BR/W R STA28
30 W/S T STA29
5 S/W R STA29
31 R/BL T STA30
6 BL/R R STA30
32 R/O T STA31
7 O/R R STA31
33 R/G T STA32
8 G/R R STA32
34 R/BR T STA33
9 BR/R R STA33
35 R/S T STA34
10 S/R R STA34
36 BK/BL T STA35
11 BL/BK R STA35
37 BK/O T STA36
12 O/BK R STA36
38 BK/G T STA37
13 G/BK R STA37
39 BK/BR T STA38
14 BR/BK R STA38
40 BK/S T STA39
15 S/BK R STA39
41 Y/BL T STA40
16 BL/Y R STA40
42 Y/O T STA41
17 O/Y R STA41
43 Y/G T STA42
18 G/Y R STA42
44 Y/BR T STA43
19 BR/Y R STA43
45 Y/S T STA44
20 S/Y R STA44
46 V/BL T STA45
21 BL/V R STA45
47 V/O T STA46
22 O/V R STA46
48 V/G T STA47
23 G/V R STA47
49 V/BR T STA48
24 BR/V R STA48
50 V/S N.C.
25 S/V N.C.
3
*Expansion *Expansion
Unit #2 Unit #3
T STA49 T STA73
R STA49 R STA73
T STA50 T STA74
R STA50 R STA74
T STA51 T STA75
R STA51 R STA75
T STA52 T STA76
R STA52 R STA76
T STA53 T STA77
R STA53 R STA77
T STA54 T STA78
R STA54 R STA78
T STA55 T STA79
R STA55 R STA79
T STA56 T STA80
R STA56 R STA80
T STA57 T STA81
R STA57 R STA81
T STA58 T STA82
R STA58 R STA82
T STA59 T STA83
R STA59 R STA83
T STA60 T STA84
R STA60 R STA84
T STA61 T STA85
R STA61 R STA85
T STA62 T STA86
R STA62 R STA86
T STA63 T STA87
R STA63 R STA87
T STA64 T STA88
R STA64 R STA88
T STA65 T STA89
R STA65 R STA89
T STA66 T STA90
R STA66 R STA90
T STA67 T STA91
R STA67 R STA91
T STA68 T STA92
R STA68 R STA92
T STA69 T STA93
R STA69 R STA93
T STA70 T STA94
R STA70 R STA94
T STA71 T STA95
R STA71 R STA95
T STA72 T STA96
R STA72 T STA96
N.C. N.C.
N.C. N.C.
