TimeTrax™ Sync Clock System
Quick Start Guide
SET UP SOFTWARE
Contact Pyramid Time Systems for software access via download at:
1
Phone: 888.479.7264 Ext. 267 or Ext. 802
Email: WirelessSales@ptitime.com
Install TimeTrax Sync™ Software into a networked computer or one that is
2
able to be directly connected to transmitter via ethernet
Installation should automatically run once the software is downloaded and you open
3
the file.The software will self-guide you through initial stages of installation.
After software is successfully installed, run program by double clicking
4
Pyramid icon on your desktop. The Pyramid TimeTrax™ Sync Login
Screen will appear. You are now ready to sign in.
"User Account Control", press "YES".
5
6 Enter the following User Name and Password (password is case sensitive):
User Name: ADMIN
7 Click the LOGIN button. TimeTrax Sync™ security is independent of Windows
Security, therefore user accounts need to be created for all users.
For security purposes, users of TimeTrax Sync™ are required to Login
to use software every time. In addition, it is advisable to change the
password for ADMIN user account to prevent unauthorized use of the
software to manipulate transmitter configuration settings.
8
The software will automatically discover & list any Pyramid Ethernet
device on network.
*Note
The firewall ports required are TCP Ports 3330, 3331, and 3333. The
direction of the firewall access is both inbound and outbound which is needed
for communication between clock to/from software.
6

SOFTWARE SET UP

Password: PTI
