Reolink Argus 3 Ultra Operational Instruction page 5

Install the Camera
Notes on Camera
Installation Position
• Install the camera 2-3 meters
(7-10 ft) above ground. This
height maximizes the detection
range of the PIR motion sensor.
• For effective detection, please
install the camera angularly.
NOTE: If a moving object approaches
the PIR sensor vertically, the camera
may fail to detect motion.
7 English
Mounting Height:
2-3 Meters
PIR Detection Distance:
2-10 Meters
Mount the Camera
1
2
Drill holes in accordance with the mounting template and screw the base of the bracket to the
wall. Next, attach the other part of the bracket to the base.
NOTE: Use the drywall anchors included in the package if needed.
Rotate to separate the base from
the bracket.
English 8
