16.12.2015 General The input and output cards of the Nokeval 2000 panel meter series can be used in some field displays too. This manual covers the field display “575F5”. Mounting the display, connecting the power supply, and other chassis related things are covered by this manual. About connecting the cards and setting them up, refer to the corresponding panel meter manual. -
Page 3: Mounting
Mounting To mount the device, use the four holes in the corners. Power supply connection The unit has wide power supply range of 85...265 VAC or 20...28 VAC/VDC depending on the model. To access the power supply and other connectors, open the front cover by unscrewing the four Phillips screws in the corners. - Page 4 display unit. Programming and input/output connections are explained in the corresponding 2000 series panel meter manual for each different device type. Power supply Electronics unit SLOT C See corresponding 2000-series panel meter manual for input and SLOT B output connections SLOT A Jumper configurations If the corresponding 2000-series manual informs that jumpers need to be moved, see below instructions to...
-
Page 5: Specifications
Regulations Electrical safety EN 61010-1 Classification Fixed equipment, permanently connected equipment, reinforced insulation. See additional input and output card specifications from the corresponding 2000 series manual. Nokeval Nokeval Oy, Rounionkatu 107, 37150 Nokia, Finland, Tel. +358 3 3424800, sales@nokeval.com, www.nokeval.com...
