New Classic Furniture ORION U1769-30L Assembly Instructions

Laf sofa w/dual recliner

Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small

parts, which may have come loose during shipment. Identify and count all items and compare with the

parts list shown below. It is recommended to have two people during assembling and to remove the

back and base of the furniture out from the box .

Please follow the drawings below to assemble the item

NO.

Seat

Left backrest

Mid backrest

Right Backrest

Left Wing

Power Cable 12V

Small Round End Power Cable 9V

ASSEMBLY INSTRUCTIONS

ORION COLLECTION

ITEM: U1769-30L

DESCRITION: ORION LAF SOFA W/DUAL RECLINER

PARTS LIST

DESCRIPTION

Page 1 of 3

SKETCH

QTY

1PC

Table of Contents

Do you have a question about the ORION U1769-30L and is the answer not in the manual?

Page 1 ASSEMBLY INSTRUCTIONS ORION COLLECTION ITEM: U1769-30L DESCRITION: ORION LAF SOFA W/DUAL RECLINER Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts, which may have come loose during shipment. Identify and count all items and compare with the parts list shown below.
Page 2 STEP 1: Insert the KD backrests (B), (C), (D) to the seat (A) and make sure the backrests are secured in position STEP 2: Insert the left wing (E) into the backrest (B) and make sure it is secured in position Page 2 of 3...
Page 3 STEP 3: There is two-one circle power connector under back of middle seat. #1 connect to connector which is fixed under middle seat frame, #2 connect to adaptor (G). At the other side, connect another adaptor (F) to cable which is fixed under arm side frame. STEP 4: Completed as picture below Page 3 of 3...
