Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small
parts, which may have come loose during shipment. Identify and count all items and compare with the
parts list shown below. It is recommended to have two people during assembling and to remove the
back and base of the furniture out from the box .
Please follow the drawings below to assemble the item
NO.
A
Seat
B
Left backrest
Mid backrest
C
Right Backrest
D
Left Wing
E
F
Power Cable
G
Small Round End Power Cable
ASSEMBLY INSTRUCTIONS
ORION COLLECTION
ITEM: U1769-30LP2
DESCRIPTION: ORION LAF SOFA W/PWR FR & HR
PARTS LIST
DESCRIPTION
Page 1 of 3
SKETCH
QTY
1PC
1PC
1PC
1PC
1PC
1PC
1PC
Advertisement
Table of Contents
Related Manuals for New Classic Furniture ORION U1769-30LP2
Summary of Contents for New Classic Furniture ORION U1769-30LP2
- Page 1 ASSEMBLY INSTRUCTIONS ORION COLLECTION ITEM: U1769-30LP2 DESCRIPTION: ORION LAF SOFA W/PWR FR & HR Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts, which may have come loose during shipment. Identify and count all items and compare with the parts list shown below.
- Page 2 STEP 1: Insert the KD backrests (B), (C), (D) to the seat (A) and make sure the backrests are secured in position STEP 2: Insert the left wing (E) into the backrest (B) and make sure it is secured in position Page 2 of 3...
- Page 3 STEP 3: Connect left and right seat to power via connector at the bottom of seat frame. Connect adaptor (G) to single circle connector which is fixed at the bottom of middle seat frame. At the other side, plug the connector of adaptor (F) to arm side.
