Thank you for purchasing this quality product. Be sure to check all packing materials
carefully for small parts, which may have come loose during shipment. Identify and count
all items and compare with the parts list shown below. It is recommended to have two
people during assembling and to remove the back and base of the furniture out from the box.
Please follow the drawings below to assemble the item
NO.
A
Seat
B
Left Backrest
C
Middle Backrest
D
Right Backrest
E
Left ear
F
Right ear
G
Plug
H
Transformer
I
Plug
ASSEMBLY INSTRUCTIONS
ORION COLLECTION
ITEM: U1769-30P2
DESCRIPTION :
Parts List
DESCRIPTION
A ll im ag es sh ow n are fo r illustration pu rpo se on ly.
A ctu al p rod u ct m ay v ary du e to p rod u ct enh an ce m en t.
Page 1 of 2
ORION SOFA W/PWR FR & HR
SKETCH
Q'TY
1 PC
1 PC
1 PC
1 PC
1 PC
1 PC
1 PC
1 PC
1 PC
Advertisement
Table of Contents
Related Manuals for New Classic Furniture ORION U1769-30P2
Summary of Contents for New Classic Furniture ORION U1769-30P2
- Page 1 ASSEMBLY INSTRUCTIONS ORION COLLECTION ITEM: U1769-30P2 DESCRIPTION : ORION SOFA W/PWR FR & HR Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts, which may have come loose during shipment. Identify and count all items and compare with the parts list shown below.
- Page 2 ASSEMBLY INSTRUCTIONS ORION COLLECTION ITEM: U1769-30P2 DESCRIPTION : ORION SOFA W/PWR FR & HR Step 1: Step 2: Attach the Left ear (E) and Right ear (F) to Attach Backrest (B/C/D) to the Seat (A) Left Backrest (B) and Right Backrest (D) Step 3: Connect the power supply and Open the footrest or move the headrest or turn on the light by pressing the button.
