Important!
When using equipment, a few safety precautions
must be observed to avoid injuries and damage.
Please read the complete operating manual with due
care. Keep this manual in a safe place, so that the
information is available at all times. If you give the
equipment to any other person, give them these
operating instructions as well.
We accept no liability for damage or accidents which
arise due to non-observance of these instructions
and the safety information.

1. Safety information

Please refer to the booklet included in delivery for the
safety instructions.
CAUTION!
Read all safety regulations and instructions.
Any errors made in following the safety regulations
and instructions may result in an electric shock, fire
and/or serious injury.
Keep all safety regulations and instructions in a
safe place for future use.
2. Layout and items supplied /
Installation tools / Assembly
material / Supplied package
(Fig. 1-2)
2.1 Layout
1. Saw bench
2. Stop rail for parallel stop
3. Parallel stop
4. Clamp lever for parallel stop
5. Guide rail for parallel stop
6. Push stick
7. Crank handle for saw blade height
8. Fixing handle for saw blade angle
9. ON/OFF/Emergency Stop switch
10. Clamp handle for cross stop
11. Cross stop
12. Saw blade
13. Stop rail for cross stop
14. Adjustable limit stop
15. Sliding table
16. Auxiliary edging plate
17. Splitter
18. Saw blade guard
19. Extraction hose
20. Rubber legs
21. Chassis
22. Legs
22
29.09.2010 8:57 Uhr Seite 22
23. Chip box
24. Push handles
25. Hook for tool
26. Mounting for extractor hose
27. Extractor adapter
28. Hose clips for extractor hose
2.2 Installation tools
29. Flange wrench
30. Wrench
31. Allen key
2.3 Assembly material
a 16 x Screws for legs (M10 x 20 mm)
b 16 x Washers for legs (M10)
c 16 x Spring rings for legs (M10)
d 16 x Nuts for legs (M10)
e 4 x Screws for chassis (M8 x 35 mm)
f 2 x Allen bolts for extractor hose holder (M8 x 20
mm)
g 4 x Screws for angle bracket (M8 x 20 mm)
h 14 x Washers (M8)
i 4 x Spring rings (M8)
j 8 x Nuts (M8)
k 4 x Metal brackets
l 4 x Spacers
2.4 Supplied package
Format circular saw
Parallel stop (3) with stop rail (2)
Push stick (6)
Cross stop (11)
Stop rail for cross stop (13)
Auxiliary edging plate (16)
Saw blade guard (18)
Extractor hose (19) with 2 hose clips (28)
4x Rubber feet (20)
Chassis (21)
4x Legs (22)
Mounting for extractor hose (26)
Installation tools (see point 2.2)
Assembly material (see point 2.3)

3. Proper use

The bench-type circular saw is designed for the
slitting and cross-cutting (only with the cross stop) of
timber, commensurate with the machine's size. The
machine is not to be used for cutting any type of
round wood.
