Valcom V-1080 FLEXHORN Technical Specifications
Valcom V-1080 FLEXHORN Technical Specifications

Valcom V-1080 FLEXHORN Technical Specifications

One-way flexhorn

Advertisement

Quick Links

FEATURES:

WEATHER-PROOF
ALL STAINLESS STEEL HARDWARE
FLEXIBLE MOUNTING: RECESSED & SURFACE
MOUNTING BRACKET INCLUDED
FACEPLATE AND VANDAL RESISTANT
MOUNTING BOX AVAILABLE SEPARATELY

DESCRIPTION:

The Flexhorn is a one-way amplified horn speaker. Complete with speaker amplifier, built-in volume control
and mounting bracket. The horn is weather proof and can be used indoors or outdoors in environments ranging from
-4 to +131 °F (-20 to +55 °C). The Flexhorn may be mounted to walls using the supplied universal bracket, mounts to
steel "I" beams using the supplied "C" clamp or flush mounted in a wall.

SPEAKER

3.5" (8.9 cm)
FREQUENCY RESPONSE
400 Hz - 10 kHz
VOICE COIL
.75 dia. (1.9 cm), 45 Ohm
DISPERSION ANGLE
120° Horizontal
90° Vertical
INPUT
Impedance: > 600 Ohms nominal
Signal Level: -10 dBm line level
OUTPUT
Rating: 108 dB @ 4' (1.22m)
Signal/noise ratio: -70 dB
5614 Hollins Road
Roanoke, Virginia 24019
E-Mail: support@valcom.com
ONE-WAY FLEXHORN
MODEL V-1080

SPECIFICATIONS:

Phone: 540-563-2000
TECHNICAL
SPECIFICATIONS
TM

POWER REQUIREMENTS

200 mA @ 24 Vdc

HOUSING AND FINISH

Constructed with filled polypropylene
Available in White (W), Gray (GY) Beige (BG)
Bracket fabricated with 16 AWG CRS and finished with
black weather resistant E-Coat.
All hardware is stainless steel.

ENVIRONMENT

Temperature: -4 to +131 °F (-20 to +55 °C)
Humidity: 0 to 95%

DIMENSIONS AND WEIGHT

6.8" (17.3 cm) H x 8.3" (21.1 cm) W x 3.3" (8.4 cm) D
Weight: 2.75 lbs (1.25 kg)

ACCESSORY PRODUCTS

V-9805 Vandal Resistant Mounting Box and Faceplate
V-9806 Faceplate
Fax: 540-362-9800
www.valcom.com
