Press Up to activate Voice Activated Dialing (VAD).
Also used as an upper arrow key. Press to activate
and deactivate speakerphone during call.
Press Down to directly access Quick Search for
Phone Book entries. Also used as a down arrow key.
Press Right to enter "My Menu". Also used as a
right arrow key.
Press Left to enter the Message menu. Also used
as a left arrow key.
11. End (Power) to terminate a call. Press and hold to turn
the phone ON/OFF.
12. OK selects the highlighted choice when navigating
through a menu.
13. Display Screen displays all the information needed to
operate your phone, such as the call status, the
internal phone book's contact list, the date and time,
the signal and battery strength, etc.
14. Battery Strength Indicator represents the amount of
remaining battery charge currently available in your
phone. When all bars are displayed in the battery icon,
the phone's battery is fully charged. When no bars are
displayed, the phone's battery is completely
discharged or empty.
15. Earpiece lets you hear the caller and automated prompts.

Viewing the Display Screen

Your phone's display screen provides a wealth of information
about your phone's status and options. This list identifies the
symbols you'll see on your phone's display screen:
Tip:
To view a list of your phone's icons and descriptions, from the
main menu select Settings > Phone Info > Help.
10
