- Page 1 ITEM #: SM100 SUCTION MACHINE...
-
Page 2: Table Of Contents
TABLE OF CONTENTS: Safety Precautions Setup Parts/Components 4, 5 Setup Warnings Operation Cleaning and Maintenance Troubleshooting... -
Page 3: Safety Precautions
SAFETY PRECAUTIONS: READ BEFORE USE Before utilizing this product, it is essential to carefully review all safety guidelines and instructions. Pay special attention to the recurring statements used throughout this manual, along with their significance. You will also find additional safety instructions in other sections, which may resemble the following or pertain to specific operations. -
Page 4: Setup
Verify the compatibility of attachments or accessories with the supplied tubing before use to ensure a proper fit. AC Power Source: The Rhythm SM100 operates on AC voltage (115V AC, 60Hz). Always use the correct power source for connecting to adaptable wall power. Before use, verify that the voltage and current indicated on the unit's specification label match the available power. - Page 5 Info - Aspirator Compressor Motor: The aspirator's compressor motor includes a thermal overload protector. If the motor overheats, the protector will shut it off. In such cases, turn the unit OFF and allow the motor to cool for approximately 5 minutes. Restart the aspirator.
-
Page 6: Parts/Components
Parts/Components Connect both sections of tubing: a. Attach one end of tubing A to the top of the collection bottle connector and the other end to the bacteria HEPA filter, as illustrated in Figure 1. b. Connect one end of tubing B to the open end of the bacteria HEPA filter and the other end to the vacuum gauge, as shown in Figure 1. -
Page 7: Operation
Operation: ⚠ WARNING: Prior to use, carefully read the safety guidelines in the subsequent operations section. Always unplug the aspirator when it's not in use. Ensure that you have followed all instructions in the previous setup section before proceeding. Figure 2 Figure 3 On/Off switch. -
Page 8: Cleaning And Maintenance
Adjust the vacuum level from 0 to 560 mmHg by turning the vacuum adjust knob clockwise to increase vacuum and counterclockwise to decrease vacuum (Figure 3). To precisely read the gauge and set the desired vacuum level, refer to the vacuum gauge. Block the patient end of the hose or cap off the collection bottle and allow the gauge to stabilize. - Page 9 Info: Empty the collection bottle immediately after each use. Clean the collection bottle after each use using one of the following three methods: Wash it in hot water and a mild detergent solution, rinse with clean, hot tap water, then wash it in a solution of one part vinegar to three parts hot water. Rinse again with hot tap water and allow it to air dry.
- Page 10 Changing the Bacteria HEPA filter: Replace the bacteria HEPA filter when either of the following two conditions occurs: a. The filter is dirty, and the aspirator has lost suction, or b. There is liquid in the filter assembly due to prolonged use or overflow. In case of overflow, replace the filter immediately.
-
Page 11: Troubleshooting
TROUBLESHOOTING ⚠ WARNING: The aspirator contains no user serviceable parts. If you believe your unit is not working properly, before you contact your provider for service, take a few moments to check for these possible causes: PROBLEM ACTION Unit does not turn on 1. - Page 12 RHYTHM HEALTHCARE Clearwater, FL 33762 Email: contactus rhythmhc.com Website: www.rhythmhc.com V1: 9/25/23...
