- Page 1 RSM Array 2000 ™ ™ Controller Module Installation Guide Sun Microsystems Computer Company A Sun Microsystems, Inc. Business 901 San Antonio Road Palo Alto, CA 94303-4900 USA 650 960-1300 fax 650 969-9131 Part No.: 802-7602-11 Revision A, October 1997...
- Page 2 AnswerBook, SunDocs, and Solaris are trademarks, registered trademarks, or service marks of Sun Microsystems, Inc. in the U.S. and other countries. All SPARC trademarks are used under license and are trademarks or registered trademarks of SPARC International, Inc. in the U.S. and other countries. Products bearing SPARC trademarks are based upon an architecture developed by Sun Microsystems, Inc.
- Page 3 FCC radio frequency emission limits. Networking connections can be made using unshielded twisted-pair (UTP) cables. Modifications: Any modifications made to this device that are not approved by Sun Microsystems, Inc. may void the authority granted to the user by the FCC to operate this equipment.
- Page 4 This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada. Sun RSM Array 2000 Controller Module Installation Guide • October 1997...
- Page 5 Standby – The On/Standby switch is in the standby chassis. position. Modifications to Equipment Do not make mechanical or electrical modifications to the equipment. Sun Microsystems is not responsible for regulatory compliance of a modified Sun product. Safety Agency Compliance Statements...
- Page 6 Stromquellen an. Ihr Betriebsleiter oder ein Achtung – Gefahr von Verletzung und qualifizierter Elektriker kann Ihnen die Daten zur Geräteschaden. Befolgen Sie die Anweisungen. Stromversorgung in Ihrem Gebäude geben. Sun RSM Array 2000 Controller Module Installation Guide • October 1997...
- Page 7 Achtung – Nicht alle Netzkabel haben die gleichen Nennwerte. Herkömmliche, im Haushalt verwendete Ce texte traite des mesures de sécurité qu’il convient de Verlängerungskabel besitzen keinen prendre pour l’installation d’un produit Sun Microsystems. Überlastungsschutz und sind daher für Mesures de sécurité Computersysteme nicht geeignet.
- Page 8 C’est la prise d’alimentation qui sert à mettre le produit hors tension. Veillez donc à installer le produit à proximité d’une prise murale viii Sun RSM Array 2000 Controller Module Installation Guide • October 1997...
- Page 9 No realice modificaciones de tipo mecánico o eléctrico en el Precaución – El interruptor de encendido de este equipo. Sun Microsystems no se hace responsable del producto funciona exclusivamente como un cumplimiento de las normativas de seguridad en los equipos dispositivo de puesta en espera.
- Page 10 Levér det brugte Z001 batteri tilbage til leverandøren. Suomi VAROITUS – Paristo voi räjähtää, jos se on virheellisesti asennettu. Vaihda paristo ainoastaan laitevalmistajan suosittelemaan tyyppiin. Hävitä käytetty paristo valmistajan ohjeiden mukaisesti. Sun RSM Array 2000 Controller Module Installation Guide • October 1997...
-
Page 11: Table Of Contents
Contents Installation 1 Before You Begin 1 Installation Worksheet 2 Preparing the Expansion Cabinet and Drive Trays 4 To Prepare the Expansion Cabinet 4 To Set the Drive Tray and SEN Card SCSI IDs 4 Installing the Power Cords and Support Rails 6 To Route the Power Cords 7 To Install the Support Rails 8 Preparing the Controller Module 11... - Page 12 Sun RSM Array 2000 Controller Module Installation Guide • October 1997...
-
Page 13: Installation
final connection to the controller module. The cabinet and installation site meet all area, environmental, power, and site requirements for the controller module. Refer to the Sun RSM Array 2000 System Manual for more information. The host is installed and contains two SBus Wide Intelligent Ultra™ SCSI (UDWIS/S) host adapters. -
Page 14: Installation Worksheet
(such as dates, serial numbers, SCSI ID settings, and so forth). Use this section to record information about the newly installed controller module and about changes you make to other devices in the cabinet during the installation. Sun RSM Array 2000 Controller Module Installation Guide • October 1997... - Page 15 Installation Worksheet INSTALLATION TASKS Prepare Cabinet Install Controller Module Remove front, back, and side panels Slide controller module onto rail support Turn off main circuit breakers Install the mounting screws Set SCSI IDs on drive trays Tighten the mounting clamp Connect controller module power cords to Replace canisters cabinet...
-
Page 16: Preparing The Expansion Cabinet And Drive Trays
If necessary, use the thumbscrews to pull the I/O board out far enough so that you can grip the outer casing with your left hand. Remove the I/O board from the drive tray. Sun RSM Array 2000 Controller Module Installation Guide • October 1997... - Page 17 4. Move the jumpers to the first and third sets of pins ( FIGURE 1-2 Holding the I/O board in your left hand, look in the upper right corner. There are eight pins (four pairs aligned vertically) below the J2 circuit and above three black chips.
-
Page 18: Installing The Power Cords And Support Rails
Used in Used in expansion expansion cabinets with cabinets with hinged front removable front door panels Plug Pattern on AC Power Sequencers FIGURE 1-3 Y-Shaped Power Cord FIGURE 1-4 Sun RSM Array 2000 Controller Module Installation Guide • October 1997... -
Page 19: To Route The Power Cords
To Route the Power Cords Tools: None Equipment: AC power cords (shipped with controller module) 1. Retrieve the power cords from the controller module shipping container. 2. Facing the back of the cabinet, plug the power cords into AC power sequencer outlets in the cabinet as follows: a. -
Page 20: To Install The Support Rails
Support rails (2 each) #10 Phillips-head screws #8 Phillips-head screws 1. Unpack the rackmounting hardware. You should have 2 support rails and at least 12 screws in two sizes (#8 and #10). Sun RSM Array 2000 Controller Module Installation Guide • October 1997... - Page 21 2. Identify the left support rail from the right one. There is a left support rail and a right support rail. They are not interchangeable and must be installed in the correct orientation inside the cabinet. To determine which rail is which: a.
- Page 22 Do not tighten the screws on the mounting clamps ( on page 20). FIGURE 1-16 Three #8 screws in holes 56, 59, and 62 Hole 55 Mark Attaching the Support Rail to the Front of Cabinet FIGURE 1-8 Sun RSM Array 2000 Controller Module Installation Guide • October 1997...
-
Page 23: Preparing The Controller Module
Preparing the Controller Module This procedure explains how to reduce the weight of the controller module (for lifting purposes), how to verify its host SCSI ID settings, and how to check the controller module before installation. It is easier to lift the controller module and set it onto the support rails if you first remove all the canisters. - Page 24 FIGURE 1-12 Be sure to keep track of which controller you remove from which location. You must replace the controller in the exact slot from which you removed it. Sun RSM Array 2000 Controller Module Installation Guide • October 1997...
- Page 25 See detail A See detail B See detail C See detail D See detail E Detail A Lift lever and remove both power supplies. Detail B Lift lever and remove power supply fan. Removing the Canisters—Power Supplies and Power Supply Fan FIGURE 1-10 Chapter 1 Installation...
- Page 26 B) belongs in each slot. To prevent data loss, you must replace both controllers to their original slots. Detail D Unlock and open handles, then pull out the controller. Removing the Canisters—Controller Fan and Controllers FIGURE 1-11 Sun RSM Array 2000 Controller Module Installation Guide • October 1997...
- Page 27 Caution – The battery unit weighs approximately 24 lbs. Be prepared to support its weight when you pull it out of the chassis. Detail E 1. Loosen thumbscrews. 2. Pull battery unit out a few inches by handles. 3. Grasp both sides and remove unit. Removing the Canisters—Battery FIGURE 1-12 Chapter 1...
-
Page 28: To Verify The Host Scsi Ids
If the date of manufacture listed is more than six months previous to the date you received the system, replace the battery. Refer to the Sun RSM Array 2000 System Manual for information on replacing a battery. 5. Write in the current date on the battery label for “Date of installation” and the date two years from now for “Replacement date.”... - Page 29 1. Locate the 16 pins on the back side of the controller module ( FIGURE 1-14 The eight pins on the left determine the host SCSI ID, or device identification number, for controller A; those on the right determine the SCSI ID for controller B. 2.
-
Page 30: Installing The Controller Module
2. Install two #10 screws in each side of the support rail and chassis FIGURE 1-15 There are two holes on each side of the controller module chassis that align with holes in the support rails. Sun RSM Array 2000 Controller Module Installation Guide • October 1997... - Page 31 Slots fit under mounting clamps Mounting screws (two on each side) Front of cabinet Installing the Controller Module Chassis FIGURE 1-15 3. Tighten the two screws in each mounting clamp, one on each side of the chassis FIGURE 1-16 Chapter 1 Installation...
-
Page 32: To Connect The Cables
Equipment: SCSI bus cables, SCSI drive cables, terminators, and tie wraps 1. Install 16-bit, differential terminators to both host SCSI OUT connectors on the back of the controller module ( FIGURE 1-18 Sun RSM Array 2000 Controller Module Installation Guide • October 1997... - Page 33 2. Connect both host SCSI bus cables to the HOST IN connectors (BD1 and BD2) on the back of the controller module. Route both host SCSI bus cables from the bottom of the cabinet ( ) and FIGURE 1-17 attach them to the HOST IN connectors on the back panel ( FIGURE 1-18 3.
- Page 34 Tray 2 Tray 1 Route SCSI cables to side of cabinet and secure with tie wraps Connecting SCSI Cables to the Controllers and Drive Trays FIGURE 1-18 Sun RSM Array 2000 Controller Module Installation Guide • October 1997...
- Page 35 5. Turn off both power switches and connect the power cords ( FIGURE 1-19 Make sure both power switches on the back of the controller module are turned off (0). Connect both power cords (that you routed from the power sequencers on page 7) to the power connectors on the controller module.
-
Page 36: Completing The Installation
Under normal startup conditions, the green Power LEDs will be lit and the amber Fault LEDs will be off. If an amber Fault LED comes on, refer to the troubleshooting section of the Sun RSM Array 2000 System Manual for instructions. Sun RSM Array 2000 Controller Module Installation Guide • October 1997... - Page 37 Fan power LED Power LED Power LED Fan fault LED LEDs on the Back of the Controller Module FIGURE 1-20 Power Power Battery LEDs Controller LEDs Supply Fault Power Fault Heartbeat Fault Fault-B Fault-A Full Charge-B Full Charge-A Controller Fault Status Fast Write LEDs on Front of Controller Module...
-
Page 38: To Configure The System
Refer to your software documentation for further instructions. For information about operating and servicing the controller module, refer to the Sun RSM Array 2000 System Manual. Sun RSM Array 2000 Controller Module Installation Guide • October 1997... -
Page 39: Index
